Summary of Contents for Lanzar Lanzar Vibe VBD1800
- Page 1 VBD 1800 OWNER’S MANUAL Mobile Audio System • PLL Synthesizer Stereo Radio • Digital Compact Disc Player • Automatically Memory Storing • Turn Upside Down Detachable Panel • Preset Equalization...
-
Page 2: Table Of Contents
CONTENTS Installation ...3 DIN Front-Mount (Method A) ...3 Installing the unit ...3 Removing the unit ...4 DIN Rear-Mount (Method B) ...4 Using the Detachable Front Panel ...5 To Detach the Front Panel ...5 To Reinstall the Front Panel ...6 Precautions when Handling ...6 Panel Angle Adjustment (Optional) ...6 Wiring Connection ...7 Operation ...8... -
Page 3: Installation
INSTALLATION Notes: • Choose the mounting location where the unit will not interfere with the normal driving function of the driver. • Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. -
Page 4: Removing The Unit
INSTALLATION Removing the unit 1. Frame 2. Insert fingers into the groove in the right side of the frame and pull out to remove the frame. (You can also remove the frame from the left side.) 3. Lever After removing the frame and when the front panel is hidden, then insert the levers supplied with the unit into the grooves at both sides of the unit... -
Page 5: Using The Detachable Front Panel
USING THE DETACHABLE FRONT PANEL To Detach the Front Panel 1. Press the left-top inside button of the back of the front panel, the front panel will turn upside down from State 1 to State 2 to State 3. Inside Button Back of the Front Panel State 1 Button... -
Page 6: To Reinstall The Front Panel
USING THE DETACHABLE FRONT PANEL To Reinstall the Front Panel 1. When the panel bracket is in slide up position, insert left side of the front panel to its proper position and push right side into the panel bracket, a ‘click’... -
Page 7: Wiring Connection
WIRING CONNECTION ANTENNA CONNECTOR IGNITION SWITCH (B+) YELLOW MEMORY CHOKE BACK-UP BLACK GROUND (B–) BLUE POWER ANTENNA FRONT Lch SPEAKER WHITE/BLACK REAR Lch SPEAKER GREEN/BLACK MAIN UNIT WHITE GREEN (GREEN) SUBWOOFER CABLE (BROWN) Rch RED FRONT RCA CABLE Lch WHITE (GREY) Rch RED REAR RCA CABLE... -
Page 8: Operation
OPERATION 15 26 GENERAL OPERATION • ON/OFF Switch on the unit by pressing the left- top inside button of the back of them front panel. And the front panel will turn upside down from State 1 to State 2 to State 3. When system is on, press POWER button (9) to turn off the unit. -
Page 9: Radio Operation
OPERATION • LOUDNESS Press BND/LOUD button (13) for several seconds to increase bass output and display will show “LOUD ON”. Press it again for several seconds to release this function. • SET THE CLOCK Press the DSP button (15), and the clock is shown on the display. -
Page 10: Cd Operation
OPERATION You can sometimes improve reception of distant stations by selecting mono operation. • SCAN Press SCAN button (25) to set function to scan mode, which scanning to higher frequency station with receivable signal and keep on each station for several seconds. •... - Page 11 OPERATION • PREVIEW ALL TRACKS Press SCN button (20) to play first several seconds of each track on the current disc. Press again to stop intro and listen to track. • PLAY ALL TRACKS Press SHF button (22) to play all tracks on CD in random order.
-
Page 12: Remote Control
REMOTE CONTROL HANDSET FUNCTION KEYS & CONTROL TUNE/SEEK TUNE/SEEK 10. AMS 11. M1 - M6 12. PAU 13. SCN 14. RPT 15. SHF = Power ON/OFF Button = Display Button = Select Button = Volume Up Button = Volume Down Button = Band Select Button = Mode Button = Tune/Seek Down Button... -
Page 13: Specification
SPECIFICATION GENERAL Power Supply Requirements Chassis Dimensions Tone Controls - Bass (at 100 Hz) - Treble (at 10 KHz) Maximum Output Power Current Drain CD PLAYER Signal to Noise Ratio Channel Separation Frequency Response RADIO Frequency Coverage Sensitivity (S/N = 30 dB) Stereo Separation Frequency Coverage Sensitivity (S/N = 20 dB) -
Page 14: Trouble Shooting
TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. Symptom No power. The car ignition switch is not on. The fuse is blown. Disc cannot be Presence of CD disc inside loaded or ejected. - Page 16 www.lanzar.com 88-C1580-09...
