Operation
FT600 Electric Airless Sprayer
IMPORTANT SAFETY INSTRUCTIONS
Read all warnings and instructions in this
manual. Save these instructions.
Model 278680
3300 psi (227 bar, 22.7 MPa) Maximum Working Pressure
- For the application of architectural paints and coatings -
- For professional use only -
332255A
ti21026a
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FT600 278680 and is the answer not in the manual?

Questions and answers

Summary of Contents for Graco FT600 278680

  • Page 1 Operation 332255A FT600 Electric Airless Sprayer - For the application of architectural paints and coatings - - For professional use only - IMPORTANT SAFETY INSTRUCTIONS Read all warnings and instructions in this manual. Save these instructions. Model 278680 3300 psi (227 bar, 22.7 MPa) Maximum Working Pressure ti21026a...
  • Page 2: Table Of Contents

    Technical Data ......17 Graco Standard Warranty ....18...
  • Page 3: Warnings

    All parts of the spray system, including the pump, hose assembly, spray gun, and objects in and around the spray area shall be properly grounded to protect against static discharge and sparks. Use Graco conductive or grounded high-pres- sure airless paint sprayer hoses.
  • Page 4 Warnings WARNING WARNING WARNING WARNING SKIN INJECTION HAZARD High-pressure fluid from gun, hose leaks, or ruptured components will pierce skin. This may look like just a cut, but it is a serious injury that can result in amputation. Get immediate surgical treatment. •...
  • Page 5: Component Identification

    Component Identification Component Identification Drain tube Pressure control Pump Power Cord Hose ON/OFF switch Spray Gun Digital Display Switch Tip Prime/Spray valve Tip Guard Filter Trigger lock Fluid outlet Serial Tag Siphon tube 332255A...
  • Page 6: Grounding

    Grounding Grounding The equipment must be grounded to reduce the risk The plug must be plugged into an outlet that is prop- of static sparking. Static sparking can cause fumes to erly installed and grounded in accordance with all ignite or explode. Grounding provides an escape wire local codes and ordinances.
  • Page 7: Pails

    Grounding Pails Solvent and oil/based fluids: follow local code. Use To maintain grounding continuity when flushing or only conductive metal pails, placed on a grounded sur- relieving pressure: hold metal part of spray gun firmly face. Do not place the pail on a nonconductive surface, to side of a grounded metal pail.
  • Page 8: Pressure Relief Procedure

    Pressure Relief Procedure Pressure Relief Procedure Follow the Pressure Relief Procedure whenever 2. Turn pressure to lowest setting. Trigger gun to you see this symbol. relieve pressure. Turn prime valve down. ti2719a This equipment stays pressurized until pressure is manually relieved. To help prevent serious injury from WASTE WASTE pressurized fluid, such as skin injection, splashing...
  • Page 9: Setup

    Setup Setup 1. Connect Graco airless hose to sprayer. 6. Fill throat packing nut with TSL to prevent Tighten securely. premature packing wear. Do this each time you spray. Approximate Fill Level ti21030a 7. Turn power OFF. 2. Connect other end of hose to gun.
  • Page 10: Startup

    Startup Startup 5. Hold gun against grounded metal flushing pail. Trigger gun and increase fluid pressure to 1/2. Flush 1 minute. 599a Do not operate or spray near children. Do not aim the sprayer at, or spray any person or animal. Keep hands and other body parts away from discharge.
  • Page 11: Tip And Guard Assembly

    Tip and Guard Assembly Tip and Guard Assembly Spraying 1. Spray test pattern. Start with pressure turned to its lowest setting, then gradually increase pressure gradually until you achieve a consistent spray pat- tern without heavy edges. Use smaller tip size if Do not operate or spray near children.
  • Page 12: Clearing Clog

    Clearing Clog Clearing Clog 4. Trigger gun to clear clog. Never point gun at your hand or into a rag! 5. Put safety ON. 1. Release trigger, put safety ON. ti10166a 6. Return Switch to original position. ti10166a 2. Rotate SwitchTip. 7.
  • Page 13: Cleanup

    Cleanup Cleanup 6. Plug in sprayer. Turn power ON. Turn prime valve horizontal. ti2712a 1. Turn power OFF and unplug sprayer. ti2707a ti11730a 7. Hold gun against paint pail. Take trigger safety OFF. Trigger gun and increase pressure until flushing fluid appears ti2707a ti11730a...
  • Page 14 Cleanup 10. Raise siphon tube above flushing fluid and run 14. If flushing with water, flush again with mineral spir- sprayer for 15 to 30 seconds to drain fluid. Turn its, or Pump Armor, to leave a protective coating to power OFF prevent freezing or corrosion.
  • Page 15: Digital Display

    Digital Display Digital Display 1. Follow Pressure Relief Procedure, page 8. 4. Press display button to display Data Point 2, motor on time in hours. 2. Plug sprayer in to grounded outlet. Turn power ON. 5. Press display button to display Data Point 3, last error code.
  • Page 16: Main Menu Operation

    Digital Display Main Menu Operation Secondary Menu Short press moves to next display. Press and hold 1. Follow Pressure Relief Procedure, page 8. (5 seconds) changes units or resets data. 2. Press DTS button and turn power switch ON. ti7484a 1.
  • Page 17: Technical Data

    Technical Data Technical Data FT600 (Model 278680) Metric Maximum fluid working pressure 3300 psi 22.7 MPa, 227 bar Maximum free-flow delivery 0.68 gpm 2.6 lpm Recommended cycle rate for continuous duty 540 cycles per gallon 143 cycles per liter Generator Minimum W 4000 4000 Motor Power...
  • Page 18: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
