Page 1: Operating Instructions
KERN & Sohn GmbH Ziegelei 1 Phone: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 email: info@kern-sohn.com Internet: www.kern-sohn.com Operating instructions Electronic height-measuring rod KERN MSA 80 Version 1.0 10/2009 MSA_80-BA-e-0910... -
Page 2: Table Of Contents
Technical Data ....................4 Declaration of conformity ................5 Basic instructions..................6 Unpacking / Scope of delivery ..............7 How to insert the batteries................8 Assembly on baby scales KERN MBB ............9 Operation...................... 11 Cleaning, Maintenance, Disposal ............... 14 MSA_80-BA-e-0910... -
Page 3: Device Overview
1 Device overview 1. Measuring rod 2. Display unit 3. Caliper gauge/Heel stop 4. Head stop MSA_80-BA-e-0910... -
Page 4: Technical Data
Technical Data ´ KERN MSA 80 Measuring range 35 – 80 cm Readability 1 mm tolerance 5 mm Units ft/inch inch Battery 2 x 1.5 V AAA Operating period 600 h Automatic cutout after 60 s Measurements (W x H x D) mm,... -
Page 5: Declaration Of Conformity
IEC61000-4-2: 1995+A1 : 1998+A2: 2000 IEC61000-4-3: 2008 IEC61000-4-8 : 1993+A1 : 2000 2006/95/EC LVD EN 60950 : 2006 Date: 22.09.2009 Signature: Gottl. KERN & Sohn GmbH Management Gottl. KERN & Sohn GmbH, Ziegelei 1, D-72336 Balingen, Tel. +49-[0]7433/9933-0,Fax +49-[0]7433/9933-149 MSA_80-BA-e-0910... -
Page 6: Basic Instructions
4 Basic instructions Carefully read this operation manual before setup and commissioning, even if you are already familiar with KERN products. The medical staff must apply and follow the operating Staff training instructions for proper use and care of the product. -
Page 7: Unpacking / Scope Of Delivery
5 Unpacking / Scope of delivery Testing upon Please check packaging as well as the device on receipt for possibly visible external damages. acceptance Packaging/ Keep all parts of the original packaging for a possibly required return. Return Only use original packaging for returning. Scope of supply For height measuring rod, see chapter 1 Batteries, 2 x 1.5 V AAA... -
Page 8: How To Insert The Batteries
6 How to insert the batteries Prior to initial use, insert the batteries as follows: 1. Remove the battery cover as shown on the illustration 2. Insert 2 x 1.5 V AAA batteries. Pay attention to correct polarity. 3. Reattach the battery cover. To save battery power, the device auto-disconnects automatically after 60 seconds have passed without a change of display. -
Page 9: Assembly On Baby Scales Kern Mbb
7 Assembly on baby scales KERN MBB 1. Turn-over the balance. If assembled, remove weighing plate by loosening the screws. 2. Apply assembly plate acc. to fig. on the height measuring rod. Ensure that the fixing point engages. 3. Fasten the assembly plate using screws [A]. Screw height measuring rod on the weighing plate [B]. - Page 10 4. Assemble again weighing plate (see item 1.). 5. Turn over, balance and height measuring rod are ready for operation. MSA_80-BA-e-0910...
-
Page 11: Operation
8 Operation Keyboard overview Button Function Turn on/off Switching between units UNIT ft/inch inch) “Freeze” measurement result HOLD Reset scale (35 cm) RESET Turn on/ Reset scale 1. Turn on height measuring rod are ready by pressing the key. 2. Push right caliper gauge till to the stop. 3. - Page 12 Length measuring 1. With KERN MBB Turn on the device and reset the scale, see chapter “How to turn on / reset the scale“. Put the baby into the weighing pan. The head has to touch gently the head stop.
- Page 13 2. Without KERN MBB Turn on the device and reset the scale, see chapter “How to turn on / reset the scale“. Lay down the baby in a way that the head touches gently the head stop. Shift caliper gauge acc. to fig. till the heel stop. Read the body height at the visual display or the measuring rod.
-
Page 14: Cleaning, Maintenance, Disposal
Service, The appliance may only be opened by trained service maintenance technicians who are authorized by KERN. Disposal of packaging and appliance must be carried out by operator according to valid national or regional law of the Disposal location where the appliance is used.
