AD-4x
WEB INTERFACE - ZONES PAGE
The Zones page of the web interface is used during AD-4x setup, allowing you
to adjust the source, power, mute, volume and the assigned group from a
device with a web browser such as a PC, tablet or smartphone.
View this page by clicking "Zones" tab at the bottom of the web interface.
ZONE CONFIGURATION
Click the "+" next to the zone you wish to configure and test.
• Sources: Select the audio input source for this zone.
• Power: Click on this button to power the zone on and off.
• Mute: Click on this button to mute the zone on and off.
• Volume: Current volume level is displayed on volume slider bar. To adjust
the volume level, use the raise and lower buttons or click on the volume
slider bar to jump to a level.
CAUTION: Clicking on the volume level bar will cause the volume to
JUMP to that level - be VERY careful where you click to
prevent accidently raising the volume to a high level.
• Group: Select the group that this zone will be a member of, or select "None".
Grouped zones will be controlled together, allowing volume levels to be
adjusted simultaneously in multiple zones.
NOTE: Zones can only be a member of one group.
