CHAPTER 4 | SPECIFICATIONS
AUDIO
Total Output Zones
Rated Power /
Channel
Power / Channel
Total Harmonic
Distortion
@20W/8ohm
Total Harmonic
Distortion @1W/8ohm
S/N @ Rated power,
IEC A-wtd, Source
input shorted
Frequency Response
20Hz to 20KHz @
1W/8ohms
Input Overload
Input Impedance
Channel Separation
@1KHz
Crosstalk Between
Sources @ Rated
Power /1KHz
Crosstalk Between
Zones @ Rated Power
/1KHz
Treble Control
@10KHz
Bass Control Range
@100Hz
Four zones, two channels each
>20 Watts, 20Hz to 20KHz
(RMS, 2 channels driven into 8 ohms)
>25 Watts @ 1KHz
(RMS, 2 channels driven into 8 ohms)
0.05%
<0.05%
92dB (mute +1)
1.5+/-0.5dB
2.5V
>22K ohms
>60dB
>75dB
80dB
10dB +/- 0.5dB
10dB +/- 0.5dB
All specifications subject to change without notice.
