LITEMAX SLD1968 V1 User Manual

Smart panel design monitor which is wide color tft?lcd module
Hide thumbs
Table of Contents

Advertisement

Quick Links





All information is subject to change without notice.


Approved by




LITEMAX SLD/SLO1968 V1
19" Sunlight Readable Smart Panel
Powered By Durapixel™ Technology
(3rd Edition 2013/6/25)
Checked by

Page 1
Prepared by










LITEMAX Electronics Inc.
8F‐2, No.137, Lane 235, Bau‐Chiau Rd.,
Shin‐Dian City, Taipei County, Taiwan R.O.C.
Tel : 886‐2‐8919‐1858
Fax: 886‐2‐8919‐1300
Homepage: http://www.litemax.com/





Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLD1968 V1 and is the answer not in the manual?

Questions and answers

Related Manuals for LITEMAX SLD1968 V1

Summary of Contents for LITEMAX SLD1968 V1

  • Page 1               LITEMAX SLD/SLO1968 V1    19” Sunlight Readable Smart Panel  Powered By Durapixel™ Technology    (3rd Edition 2013/6/25)  All information is subject to change without notice.      Approved by  Checked by  Prepared by                              LITEMAX Electronics Inc.  8F‐2, No.137, Lane 235, Bau‐Chiau Rd.,    Shin‐Dian City, Taipei County, Taiwan R.O.C.  Tel : 886‐2‐8919‐1858  Fax: 886‐2‐8919‐1300  Homepage: http://www.litemax.com/ ...

  • Page 2: Record Of Revision

    Record of Revision  Version and Date  Page  Old Description  New Description  Remark    Dec,22,2012  All    Initial Release      Mar,26,2013  4/13/15   Update Data    Power Consumption from    Jun,25,2013  4      26w to 31W                                   ...

  • Page 3: Table Of Contents

    Contents Record of Revision ..........................2 1.0 GENERAL DESCRIPTION ......................4 1.1 OVERVIEW ..........................4 1.2 FEATURES ..........................4 1.3 APPLICATION ........................4 1.4 GENERAL SPECIFICATI0NS ....................4 1.5 ABSOLUTE MAXIMUM RATINGS ..................5 2.0 Electrical characteristics ........................6 3.0 SIGNAL Characteristic ........................8 4.0 TIMING Characteristics ........................

  • Page 4: General Description

    1.0 GENERAL DESCRIPTION    1.1 OVERVIEW    SLD/SLO1968 V1 is a smart panel design monitor which is wide color TFT‐LCD module as  active switching devices with 1,600nits LED backlight powered by Durapixel™ technology.  This module has a 19 inch diagonally measured active area with SXGA resolutions (1280  horizontal by 1024 vertical pixel array). Each pixel is divided into RED, GREEN, BLUE dots  which are arranged in vertical stripe and this module can display 16.7M colors.  1.2 FEATURES     High brightness 1600nits   LED Backlight   SXGA(1280x1024) High Definition   High Shock & Vibration Resistance   Smart Panel design   High Uniformity   Low EMI Noise   Wide Dimming   Life Expectancy    1.3 APPLICATION  Outdoor Display    Outdoor Digital Signage  Quick Service Restaurant Display Product      Transportation  Gas Station Forecourt Displays    1.4 GENERAL SPECIFICATI0NS ...

  • Page 5: Absolute Maximum Ratings

    1.5 ABSOLUTE MAXIMUM RATINGS        TFT LCD Module      ABSOLUTE RATINGS OF ENVIRONMENT            Page 5...

  • Page 6: Electrical Characteristics

    2.0 Electrical characteristics    TFT LCD Module Power Specification  Input power specifications are as following:        Note 1: The H‐Stripe pattern is defined as below:                      Page 6...
  • Page 7 Note 2: Measurement Conditions:                                                Page 7...

  • Page 8: Signal Characteristic

    3.0 SIGNAL Characteristic  PIXEL FORMAT IMAGE          INPUT DATA FORMAT          Page 8...
  • Page 9 Signal Description    The module using one LVDS receiver SN75LVDS82(Texas Instruments). LVDS is a  differential signal technology for LCD interface and high speed data transfer device. LVDS  transmitters shall be SN75LVDS83(negative edge sampling). The first LVDS port(RxOxxx)  transmits odd pixels while the second LVDS port(RxExxx) transmits even pixels.              Page 9...

  • Page 10: Timing Characteristics

    4.0 TIMING Characteristics      DE mode only    Timing diagram              Page 10...
  • Page 11 Power ON/OFF Sequence  VDD power and lamp on/off sequence are as follows. Interface signals are also shown in the  chart. Signals from any system shall be Hi‐Z state or low level when VDD is off.                        Page 11...

  • Page 12: Connector And Pin Assignment

    5.0 CONNECTOR and PIN ASSIGNMENT TFT LCD Module PIN ASSIGNMENT     Page 12...

  • Page 13: Optical Specification

    6.0 OPTICAL SPECIFICATION Item Symbol Condition Data Unit Note 0.643 0.345 0.328 Green Color 0.630 θx=0 chromaticity 0.144 Test Mode： Blue θy=0 0.055 （1） （2） （3） BM-7 0.311 White 0.331 Center Luminance of White 1600 cd/㎡ Uniform ％ Contrast Ratio θx=0 1000:1 Test Mode：...
  • Page 14 （2） Definition of Test Point： Active Area （3）BM-7 Measurement Setup: （4）Klein K-10 Measurement Setup: Page 14...

  • Page 15: Led Driving Board Specifications

    7.0 LED DRIVING BOARD SPECIFICATIONS 1. LED Application This specification is applied to LED converter unit for SLD/SLO1968 (1600 nits) LED backlight 2. Operating Characteristics Item Symbol MIN. TYP. MAX. Unit Remark Conditions Input Voltage 10.0 12.0 14.0 Input Current VIN=12V,Vadj=5V ----- -----...
  • Page 16 3. Connector Socket 3-1. Input Connector: J1(JST B2B-PH-K-S or Compatible) PIN No Symbol Description DC+12V DC+12V DC+12V Ground Ground Ground Brightness Brightness Control 5V~0V Control ON/OFF Control 0.8V(OFF) 2~5V(ON) 3-2. Output Connector: J2,J3(JST S2B-EH or Compatible) PIN NO Symbol Description Output LED High Voltage( + ) Output...
  • Page 17 4. Mechanical Characteristics Dimension: 124mm*50mm*15mm INPUT CONNECTOR PIN1:VIN PIN2:VIN PIN3:VIN PIN4:GND PIN5:GND PIN6GND PIN7:BRIGHTNESS PIN8:ON/OFF 15mm   Page 17...

  • Page 18: Ad2662 Specifications (Dlh1968 Only)

    8.0 AD2662 SPECIFICATIONS We developed this A/D board to support industrial high brightness and commercial applications. This A/D board has many functions. It has an external luminance sensor as an option, an optional VR button to control brightness, fan rotation and RS232. Rev.1 is European RoHS compliant. 8.1 General Description Max Resolution Up To WUXGA ...

  • Page 19: Outline Dimensions

    8.2 Outline Dimensions AD2662GD 150mmX100mmX20mm Page 19...
  • Page 20 I/O BOARD 160mmX25mmX15mm Page 20...
  • Page 21 AD2662GDVAR 272mmX100mmX20mm Page 21...

  • Page 22: Ad2662 Board Pin Define

    8.3 AD2662 Board Pin Define J3: Panel connector Pin No. Function Pin No. Function RxO0+ RxE1- RxO0- RxE2+ RxO1+ RxE2- RxO1- RxEC+ RxO2+ RxEC- RxO2- RxE3+ RxOC+ RxE3- RxOC- RxO3+ RxO3- RxE0+ PANEL-VCC RxE0- PANEL-VCC RxE1+ PANEL-VCC CN3: DVI-D INPUT Connector Pin No.

  • Page 23: Cn5: Dvi-D Connector (16Pin 2.0Mm)

    CN5: DVI-D Connector (16pin 2.0mm) Pin No. Function Pin No. Function Pin No. Function RX2- DDC_SDA RX2+ DDC_SCL RX1- DVI HP RX1+ DVI_5V RX0- RXC- RX0+ RXC+ CN2: Analog RGB Input connector (D-SUB 15Pin) Pin No. Symbol Description Pin No. Symbol Description Analog Red...

  • Page 24: J1: Power Connector (12V) (6Pin 2.0Mm)

    Power connector (12V) (6PIN 2.0mm) Pin No. Function Pin No. Function 12VDC 12VDC 12VDC J8: Power connector (5V/12v)(4PIN 2.0mm) Pin No. Function Pin No. Function 5VDC 12VDC J2: Inverter Connector(8PIN 2.0mm) Pin No. Symbol Description Pin No. Symbol Description ON/OFF Backlight ON/OFF BRIGHT Dimming adjust...

  • Page 25: J11 Extern Funtion Connector (11P X 2Pin 2.0Mm)

    Extern Funtion Connector (11P X 2PIN 2.0mm) Pin No. Function Pin No. Function Audio-R Audio-L J5: Ambient (3PIN 2.0mm) Pin No. Function Pin No. Function 3.3VDC Sensor Out J4: VR connector (3PIN 2.0mm) Pin No. Function Pin No. Function 3,3VDC VR Out J12: IR Connector(3PIN 2.0mm)

  • Page 26: I/O Board Pin Define

    8.4 I/O BOARD Pin Define J1:Component Y Pin No. Function Pin No. Function J2:Component Cb Pin No. Function Pin No. Function J3:Component Cr Pin No. Function Pin No. Function J4:S-Video Pin No. Function Pin No. Function Luminance Chrominance J5:Composite Pin No. Function Pin No.

  • Page 27: Ir Receive Board Pin Define

    8.5 IR Receive Board Pin Define J1: IR Connector Pin No. Function Pin No. Function DATA OUT 8.6 DC Characteristics. Power Consumption Note1 Operation Temperature 0~70 ℃ Storage Temperature -20~85 ℃ Note: These values are for the A/D board body. Page 27...

  • Page 28: Osd Menu

    “0”, while press “right” you can increase the brightness to “100”. Ambient light sensor: press this Icon, must to accompany with Litemax ambient light sensor to auto dimming.(OPTION) Potentiometer: press this icon, adjust VR function.(OPTION) Ambient light sensor with OSD offset: press this Icon Press ’menu’’...
  • Page 29 Sound : There are 3 options for “Sound” sub page. Audio Volume: Audio volume adjustment. Mute: You can mute the speaker by pressing this option. Exit: back to the normal screen. Auto Color: by press this “Auto Color” option, you can get the optimal color performance.
  • Page 30 Color Tempture: You can have 3 options in this selection. Color Tempture User Color Tempture_6500K Color Tempture_93OOK “user mode”, “6500K” (Warm color scheme), “9300K (Cold color scheme). Def ault is “user”, and inside all “R”, “G”, and “B” are set “100” Exit: back to the normal screen.
  • Page 31 Auto just: Pressing this option, the AD2662 will adjust the optimal frequency of horizontal and vertical. You will see “Auto tune….” On the screen for around 3 seconds. Clock: If you are not satisfied about the Autotune result, you can adjust manually by “Clock”.

  • Page 32: Burnin Mode

    Osd_time: You can selection the time of OSD from 2 sec. to 16 sec. Osd_HPos: You can move the OSD horizontally over the screen. Osd_VPos: You can move the OSD Vertically over the screen. Exit: back to main menu. Factory_Reset: By pressing this, the screen will be back to the factory setting on very beginning and lost all the personal settings.
  • Page 33                                                                                  ...

  • Page 34: Mechanical Drawing

    9.0 MECHANICAL DRAWING SLD1968 Page 34...
  • Page 35 Page 35...
  • Page 36 SLO1968   Page 36...
  • Page 37             Page 37...

  • Page 38: Precautions

    10.0 PRECAUTIONS    10.1 HANDLING PRECAUTIONS    (1)    The module should be assembled into the system firmly by using every mounting hole.  Be careful not to twist or bend the module.    (2)    While assembling or installing modules, it can only be in the clean area. The dust and oil  may cause electrical short or damage the polarizer.    (3)    Use fingerstalls or soft gloves in order to keep display clean during the incoming    inspection and assembly process.    (4)    Do not press or scratch the surface harder than a HB pencil lead on the panel    because the polarizer is very soft and easily scratched.    (5)    If the surface of the polarizer is dirty, please clean it by some absorbent cotton or soft  cloth. Do not use Ketone type materials (ex. Acetone), Ethyl alcohol, Toluene, Ethyl acid  or Methyl chloride. It might permanently damage the polarizer due to chemical  reaction.    (6)    Wipe off water droplets or oil immediately. Staining and discoloration may occur if    they left on panel for a long time.    (7)    If the liquid crystal material leaks from the panel, it should be kept away from the eyes  or mouth. In case of contacting with hands, legs or clothes, it must be washed away ...
