LITEMAX SSD1505 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Global LCD Panel Exchange Center
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
LITEMAX
SSD1505
Spanpixel
Sunlight Readable 15" LCD Display
nd
(2
Edition 10/21/2010 )
All information is subject to change without notice.
Approved by
Ming
Checked by
Prepared by
Hank
Jacky
LITEMAX
Electronics Inc.
8F, No.137, Lane 235, Bau-Chiau Rd.,
Shin-Dian City, Taipei County, Taiwan R.O.C.
Tel : 886-2-8919-1858
Fax: 886-2-8919-1300
Homepage: http://www.litemax.com/
Page 1
www.panelook.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSD1505 and is the answer not in the manual?

Questions and answers

Related Manuals for LITEMAX SSD1505

Summary of Contents for LITEMAX SSD1505

  • Page 1 Global LCD Panel Exchange Center LITEMAX SSD1505 Spanpixel Sunlight Readable 15" LCD Display Edition 10/21/2010 ) All information is subject to change without notice. Approved by Checked by Prepared by Ming Hank Jacky LITEMAX Electronics Inc. 8F, No.137, Lane 235, Bau-Chiau Rd., Shin-Dian City, Taipei County, Taiwan R.O.C.

  • Page 2: Record Of Revision

    www.panelook.com Global LCD Panel Exchange Center RECORD OF REVISION Version Date Description Remark V1.0 1/21/2010 Initial Release Page 2 www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

  • Page 3: Table Of Contents

    3.0 OPTICAL CHARACTERISTICS .................. 9 3.1 TEST CONDITIONS .................... 9 3.2 OPTICAL SPECIFICATIONS ................9 4.0 MECHANICAL CHARACTERISTICS ................ 12 SSD1505 MECHANICAL SPECIFICATION ............. 12 5.0 PRECAUTIONS ......................13 5.1 HANDLING PRECAUTIONS................13 5.2 STORAGE PRECAUTIONS................13 5.3 OPERATION PRECAUTIONS ................13 6.0 AD Board &...

  • Page 4: General Description

    1.0 GENERAL DESCRIPTION 1.1 OVERVIEW The SSD1505 is a 15 inch color TFT-LCD display with special aspect ratio 16:3 and XGA wide resolution 1280 x 242 (1280 horizontal by 242 vertical pixel array). It is Litemax’s Spanpixel series product which designed for high brightness 1000 nits sunlight readable display, power efficiency LED backlight system and fanless display.

  • Page 5: Electrical Characteristics

    www.panelook.com Global LCD Panel Exchange Center 2.0 ELECTRICAL CHARACTERISTICS 2.1 ELECTRICAL CHARACTERISTICS Note 1: The variance of VDD power consumption is ±30%. Note 2: Measurement conditions: Page 5 www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

  • Page 6: Lcd Panel Signal Processing Board

    www.panelook.com Global LCD Panel Exchange Center 2.2 LCD PANEL SIGNAL PROCESSING BOARD The module using a pair of LVDS receiver SN75LVDS82(Texas Instruments) or compatible. LVDS is a differential signal technology for LCD interface and high speed data transfer device. Transmitter shall be SN75LVDS83(negative edge sampling) or compatible. The first LVDS port(RxOxxx) transmits odd pixels while the second LVDS port(RxExxx) transmits even pixels.

  • Page 7: Backlight Connector Pin Configuration

    www.panelook.com Global LCD Panel Exchange Center 2.3 BACKLIGHT CONNECTOR PIN CONFIGURATION LED Driving Electrical specification 2.4 SIGNAL TIMING SPECIFICATIONS DE only Mode Page 7 www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

  • Page 8: Signal Timing Waveforms

    www.panelook.com Global LCD Panel Exchange Center 2.5 SIGNAL TIMING WAVEFORMS Page 8 www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

  • Page 9: Optical Characteristics

    www.panelook.com Global LCD Panel Exchange Center 3.0 OPTICAL CHARACTERISTICS 3.1 TEST CONDITIONS Optical characteristics are determined after the unit has been ‘ON’ and stable for approximately 45 minutes in a dark environment at 25 . The values specified are at an approximate distance 50cm from the LCD surface at a viewing angle of and equal to 0°.
  • Page 10 www.panelook.com Global LCD Panel Exchange Center Definition of luminance measured points: Measure the luminance of gray level 255 at point L(1) Definition of White Variation ( W): Measure the luminance of gray level 255 at 9 points Page 10 www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
  • Page 11 www.panelook.com Global LCD Panel Exchange Center 3. Response time T is the average time required for display transition by switching the input signal for five luminance ratio (0%,25%,50%,75%,100% brightness matrix) and is based on fv=60Hz to optimize. 4. Viewing angle is the angle at which the contrast ratio is greater than 10. The angles are determined for the horizontal or x axis and the vertical or y axis with respect to the z axis which is normal to the LCD surface.

  • Page 12: Mechanical Characteristics

    Global LCD Panel Exchange Center 4.0 MECHANICAL CHARACTERISTICS SSD1505 MECHANICAL SPECIFICATION Item Min. Typ. Max. Unit Horizontal(H) - Module Vertical(V) 106.2 Size Depth(D) 37.8 Weight (Module only) Weight (1 module per box) Page 12 www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

  • Page 13: Precautions

    www.panelook.com Global LCD Panel Exchange Center 5.0 PRECAUTIONS 5.1 HANDLING PRECAUTIONS The module should be assembled into the system firmly by using every mounting hole. Be careful not to twist or bend the module. While assembling or installing modules, it can only be in the clean area. The dust and oil may cause electrical short or damage the polarizer.

  • Page 14: Ad Board & Osd Functions

    www.panelook.com Global LCD Panel Exchange Center 6.0 AD Board & OSD Functions 6.1 AD BOARD GENERAL SPECIFICATIONS Max Resolution Up To WXGA 60Hz Analog RGB Input 1.5Wx2 Audio Out LVDS Output Support Panel DC5V or 3.3V, 12V Output Automatic External Fan Control OSD Control Inverter 0~5V Dimming Control *External V.R.

  • Page 15: Membrane Control Buttom

    www.panelook.com Global LCD Panel Exchange Center 6.3 MEMBRANE CONTROL BUTTOM POWER SWITCH: Pushing the power switch will turn the monitor on. Pushing it again to turn the monitor off. Power LED: Power ON-Green / Power off-No. Up Key >: Increase item number or value of the selected item. Menu Key: Enter to the OSD adjustment menu.
  • Page 16 “0”, press “right” to increase the brightness to “100” Ambient light sensor: Press this Icon for auto dimming. (OPTION) To use this option, the Litemax ambient light sensor needs to have been installed Potentiometer: Navigate to this icon to adjust the VR function. (OPTION) Ambient light sensor with OSD offset: To set minimum brightness level based on ambient light.
  • Page 17 www.panelook.com Global LCD Panel Exchange Center To adjust from “100” to “0”, press “menu” and the “left” buttons. Exit: You can exit this sub menu back to normal screen. Analog: RGB/VGA input Digital: DVI input AV1: Composite input S-Video: S-Video input S-Video Exit Exit: You can exit this sub menu back to the beginning...
  • Page 18 www.panelook.com Global LCD Panel Exchange Center UnMute/Mute: You can mute the speaker by pressing this option. Exit: back to the beginning menu. Auto Color: By navigating over to the “Auto Color” option, optimal color performance is invoked. SRGB: Windows standard color setting Color Temperature: You have 3 options in this selection Color Temperature User Define: Default is 100 for “R”, “G”, and “B”.
  • Page 19 www.panelook.com Global LCD Panel Exchange Center Color Tempture_6500K: Warm color scheme Color Tempture_93OOK: Cold color scheme Exit: back to the normal screen. Go to the “Image” page, and you will see the below picture Auto Adjust: Choose this option and the AD5766 will adjust to the optimal horizontal and vertical frequency.
  • Page 20 www.panelook.com Global LCD Panel Exchange Center OSD Control: Selecting this option, brings you to 4 more options: OSD _time: Select time for the OSD user interface to stay on screen, for 2 sec. to 16 sec. Default is 6 sec. OSD _HPos: Moves the OSD user interface horizontally on screen.
  • Page 21 www.panelook.com Global LCD Panel Exchange Center Exit OSD Lock Function: It is possible to lock all the OSD buttons to prevent unauthorized changes to occur by pressing “Menu” and “right >” buttons simultaneously. You will see the “lock” icon below on the center of the screen for 3 seconds. If any button is pushed after the lock function is initiated, the below icon will appear on the screen.' To release the OSD lock, press “Menu”...
