LITEMAX SSF 0822 User Manual

Sunlight readable 8"
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LITEMAX
SSF/SSH 0822
Spanpixel
Sunlight Readable 8" LCD Display
rd
(2
Edition 2014/09/10 )
All information is subject to change without notice.
Approved by
Checked by
Prepared by
LITEMAX
Electronics Inc.
8F, No.137, Lane 235, Bau-Chiau Rd.,
Xindian Disty, New Taipei City, Taiwan R.O.C.
Tel : 886-2-8919-1858
Fax: 886-2-8919-1300
Homepage: http://www.litemax.com/
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSF 0822 and is the answer not in the manual?

Questions and answers

Related Manuals for LITEMAX SSF 0822

Summary of Contents for LITEMAX SSF 0822

  • Page 1 Edition 2014/09/10 ) All information is subject to change without notice. Approved by Checked by Prepared by LITEMAX Electronics Inc. 8F, No.137, Lane 235, Bau-Chiau Rd., Xindian Disty, New Taipei City, Taiwan R.O.C. Tel : 886-2-8919-1858 Fax: 886-2-8919-1300 Homepage: http://www.litemax.com/ Page 1...

  • Page 2: Record Of Revision

      RECORD OF REVISION  Version Date Description Remark Initial Release V1.0 Aug/10/2012 1.Update brightness V1.1 Sep/10/2014 2. Update MECHANICAL Page 2...

  • Page 3: Table Of Contents

    CONTENTS RECORD OF REVISION ....................2   1.0 GENERAL DESCRIPTION ..................4   OVERVIEW ........................ 4   FEATURES ........................ 4   APPLICATION ......................4   GENERAL SPECIFICATI0NS ..................4   2.0 ELECTRICAL CHARACTERISTICS ................. 5   2.1 TFT Block Diagram ....................5  ...

  • Page 4: General Description

    The SSF/SSH0822 is a 8 inch color TFT-LCD display with special aspect ratio 16:5 and wide resolution 1024 x 324 (1024 horizontal by 324 vertical pixel array). It is Litemax’s Spanpixel series. The SSH0822 build in AD board supports VGA input FEATURES - 8”...

  • Page 5: Electrical Characteristics

    2.0    ELECTRICAL CHARACTERISTICS    2.1 TFT Block Diagram Page 5...

  • Page 6: Relationship Between Displayed Color And Input

    2.2 Relationship Between Displayed Color and Input Page 6...
  • Page 7 Page 7...

  • Page 8: Electrical Characteristics

    2.3 Electrical Characteristics Page 8...
  • Page 9 Page 9...
  • Page 10 Page 10...
  • Page 11 Page 11...

  • Page 12: Optical Characteristics

    3.0 OPTICAL CHARACTERISTICS  TEST CONDITIONS Optical characteristics are determined after the unit has been ‘ON’ and stable for approximately 45 minutes in a dark environment at 25. The values specified are at an approximate distance 50cm ℃ from the LCD surface at a viewing angle of Φ and θ equal to 0°. FIG.
  • Page 13 Measuring point for surface luminance & measuring point for luminance variation. FIG. 2 5 Points for Luminance Measure Response time is defined as the following figure and shall be measured by switching the input signal for “White” and “Black”. FIG. 3 Response Time Definition for viewing angle FIG.

  • Page 14: Mechanical Characteristics

    4.0 MECHANICAL CHARACTERISTICS  SSF/SSH0822 MECHANICAL SPECIFICATION Item Min. Typ. Max. Unit Horizontal(H) - Module Vertical(V) 79.2 Size Depth(D) Weight (Module only) 0.17/ 0.27 Page 14...

  • Page 15: Precautions

    5.0 PRECAUTIONS    HANDLING PRECAUTIONS The module should be assembled into the system firmly by using every mounting hole. Be careful not to twist or bend the module. While assembling or installing modules, it can only be in the clean area. The dust and oil may cause electrical short or damage the polarizer.

  • Page 16: Ad Board & Osd Functions

    6.0 AD Board & OSD Functions  We developed this A/D board to support industrial high brightness and commercial applications. This A/D board has one functions. It has a VGA input. Rev.1 is European RoHS compliant. General Description                                                  ...
  • Page 17 AD6038GM 114mmX40mm Page 17...
  • Page 18 AD6038GM Board Pin Define CN4: Panel connector Pin No. Function Pin No. Function RxO0- RxE1+ RxO0+ RxE2- RxO1- RxE2+ RxO1+ RxEC- RxO2- RxEC+ RxO2+ RxE3- RxOC- RxE3+ RxOC+ RxO3- RxO3+ RxE0- PANEL-VCC RxE0+ PANEL-VCC RxE1- PANEL-VCC CN2: Analog RGB Input connector (13pin connector) Pin No.
  • Page 19 CN3: Touch Power connector Pin No. Function Pin No. Function J1: Inverter Connector(8PIN 2.0mm) Pin No. Symbol Description Pin No. Symbol Description ON/OFF Backlight ON/OFF BRIGHT Dimming adjust 12VDC Input 12VDC 12VDC Input 12VDC 12VDC Input 12VDC J5: Key Pad (9PIN 2.0mm) Pin No.
  • Page 20 CN1: RS232 Connector Pin No. Function Pin No. Function UART TX UART RX Page 20...

  • Page 21: Osd Menu

    Potentiometer: press this Icom, adjust VR function.(OPTION) Ambient light sensor: press this Icon,must to accompany with Litemax ambient light sensor to auto dimming.(OPTION) OSD Brightness： Press the “menu” once, to adjust the brightness. Press “left” to dim down the brightness to “0”, press “right”...
  • Page 22 (Enable function in factory mode) Audio Volume: Audio volume adjustment. UnMute/Mute: You can mute the speaker by pressing this option Exit: back to the beginning menu. Auto Color ： By navigating over to the “Auto Color” option, optimal color performance is invoked. Windows standard color setting SRGB: Page 22...
  • Page 23 Color Temperature: You have 4 options in this selection Color Temperature User Define: Default is 100 for “R”, “G”, and “B”. Color Tempture_6500K: Warm color scheme Color Tempture_93OOK: Cold color scheme Exit: back to the beginning menu. Auto Adjust: Choose this option and the AD6038 will adjust to the optimal horizontal and vertical frequency.
  • Page 24 HPos: You can shift the screen horizontally using this function. Vpos: You can shift the screen vertically using this function. Exit: back to the beginning menu. OSD Control: Selecting this option, brings you to 5 more options: Osd_time: Select time for the OSD user interface to stay on screen, for 2 sec. to 16 sec.
  • Page 25 Osd_Rotation: Rotates the OSD user interface Rotation(0°/90°/180°/270°) on screen. Exit: You can exit this sub menu back to the beginning Factory_Reset: By pressing this, the screen will revert to factory settings, and the previous settings will be deleted. Sharpness: Sharpen characters. For some old programs which use 640x400 and 720x400 (DOS Mode Dos_mode/Gxf_mode: and graphics mode), This option needs to be selected manually.
