LITEMAX SLD2415 User Manual

Sunlight readable 24” led b/l lcd
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LITEMAX
Sunlight Readable 24" LED B/L LCD
All information is subject to change without notice.
Approved by
SLD/SLO2415

User Manual

rd
(3
Edition 2012/3/19)
Checked by
LITEMAX
8F, No.137, Lane 235, Bau-chiau Rd.,
Shin-dian City, Taipei County, Taiwan R.O.C.
Tel : 886-2-8919-1858
Fax: 886-2-8919-1300
Homepage:
Page 1
Prepared by
Electronics Inc.
http://www.litemax.com.tw

Advertisement

Table of Contents
loading

Related Manuals for LITEMAX SLD2415

Summary of Contents for LITEMAX SLD2415

  • Page 1: User Manual

    LITEMAX SLD/SLO2415 Sunlight Readable 24” LED B/L LCD User Manual Edition 2012/3/19) All information is subject to change without notice. Approved by Checked by Prepared by LITEMAX Electronics Inc. 8F, No.137, Lane 235, Bau-chiau Rd., Shin-dian City, Taipei County, Taiwan R.O.C.

  • Page 2: Record Of Revision

    RECORD OF REVISION Version and Date Page Old Description New Description Remark Aug,12,2011 Preliminary Release Nov,09,2011 Mar,19,2012 Remove PWM Data Page 2...

  • Page 3: Table Of Contents

    Contents RECORD OF REVISION ....................2 Contents........................... 3 1.0 GENERAL DESCRIPTION ..................4 1.1 FEATURES ......................4 1.2 GENERAL SPECIFICATIONS ................4 1.3 ABSOLUTE MAXIMUM RATINGS ............... 5 2.0 Electrical characteristics ..................6 3.0 SIGNAL Characteristic....................9 4.0 TIMING Characteristics....................11 5.0 CONNECTOR and PIN ASSIGNMENT..............

  • Page 4: General Description

     Full HD(1920x1080)  High Shock & Vibration Resistance  Low Power Consumption  High Uniformity  Low EMI Noise  Wide Dimming  Life Expectancy 1.2 GENERAL SPECIFICATIONS Model No.  SLD2415  SLO2415  Description  24” TFT LCD Display, LED Backlight, 1000nits, FHD(1920x1080)  Display Area (mm)  531.3 x 298.9 mm  Brightness  1000 cd/m   Resolution ...

  • Page 5: Absolute Maximum Ratings

    1.3 ABSOLUTE MAXIMUM RATINGS TFT LCD Module ABSOLUTE RATINGS OF ENVIRONMENT Page 5...

  • Page 6: Electrical Characteristics

    2.0 Electrical characteristics TFT LCD Module Power Specification Page 6...
  • Page 7 Signal Electrical Characteristics Input signals shall be low or Hi-Z state when VDD is off. Please refer to specifications of SN75LVDS82DGG (Texas Instruments) in detail. Page 7...
  • Page 8 Page 8...

  • Page 9: Signal Characteristic

    3.0 SIGNAL Characteristic Page 9...
  • Page 10 Signal Description The module using one LVDS receiver SN75LVDS82(Texas Instruments). LVDS is a differential signal technology for LCD interface and high speed data transfer device. LVDS transmitters shall be SN75LVDS83(negative edge sampling). The first LVDS port(RxOxxx) transmits odd pixels while the second LVDS port(RxExxx) transmits even pixels. Page 10...

  • Page 11: Timing Characteristics

    4.0 TIMING Characteristics Basically, interface timing described here is not actual input timing of LCD module but close to output timing of SN75LVDS82DGG (Texas Instruments) or equivalent. DE Mode Only Timing diagram Page 11...
  • Page 12 Power ON/OFF Sequence VDD power and lamp on/off sequence are as follows. Interface signals are also shown in the chart. Signals from any system shall be Hi-Z state or low level when VDD is off. Page 12...

  • Page 13: Connector And Pin Assignment

    5.0 CONNECTOR and PIN ASSIGNMENT TFT LCD Module PIN ASSIGNMENT Page 13...

  • Page 14: Optical Specification

    6.0 OPTICAL SPECIFICATION Optical Condition Data Unit Note Item Symbol 0.639 0.351 0.342 Green Color 0.621 chromaticity θx=0 0.147 Blue Test Mode： θy=0 0.063 （1） （2） （3） BM-7 0.335 White 0.367 Center Luminance of White cd/㎡ 1000 cd/㎡ Average 1000 ％...
  • Page 15 Test Mode：  （1） Definition of Viewing Angle（θx，θy） ： （2） Definition of Test Point： Active Area Page 15...
  • Page 16 （3）BM-7 Measurement Setup: （4）Klein K-10 Measurement Setup:   Page 16...

  • Page 17: Led Driving Board Specifications

    7.0 LED DRIVING BOARD SPECIFICAT IONS 1. LED Application      This specification is applied to LED converter unit for SLD/SLO2415(1000nit) LED backlight    2. Operating Characteristics    Item  Symbol  MIN.  TYP. MAX.  Unit  Remark  Conditions   Input Voltage  Vin              10.0  12.0 14.0      V  Input Current  VIN=12V,Vadj=5V    0.0  ‐‐‐‐‐...
  • Page 18             3‐1. Input Connector: J1(JST B2B‐PH‐K‐S or Compatible  PIN No  Symbol  Description  1  Vin    DC+12V  2  Vin    DC+12V  3  Vin    DC+12V  4  GND    Ground  5  GND    Ground  6  GND    Ground  7  Brightness  Brightness Control    5V~0V  8  Control ...
  • Page 19 Dimension:    124mm*50mm*15mm                                                                INPUT CONNECTOR  J1:  PIN1:VIN  PIN2:VIN  PIN3:VIN  PIN4:GND  PIN5:GND ...

  • Page 20: Ad2662Gdvar Specifications

    8.0 AD2662GDVAR SPECIFICATIONS We developed this A/D board to support industrial high brightness and commercial applications. This A/D board has many functions. It has an external luminance sensor as an option, an optional VR button to control brightness, fan rotation and RS232. Rev.1 is European RoHS compliant.

  • Page 21: Outline Dimensions

    8.2 Outline Dimensions AD2662GD 150mmX100mmX20mm Page 21...
  • Page 22 I/O BOARD 160mmX25mmX15mm Page 22...
  • Page 23 AD2662GDVAR 272mmX100mmX20mm Page 23...

  • Page 24: Ad2662 Board Pin Define

    8.3 AD2662 Board Pin Define J3: Panel connector Pin No. Function Pin No. Function RxO0+ RxE1- RxO0- RxE2+ RxO1+ RxE2- RxO1- RxEC+ RxO2+ RxEC- RxO2- RxE3+ RxOC+ RxE3- RxOC- RxO3+ RxO3- RxE0+ PANEL-VCC RxE0- PANEL-VCC RxE1+ PANEL-VCC CN3: DVI-D INPUT Connector Pin No.

  • Page 25: Cn5: Dvi-D Connector (16Pin 2.0Mm)

    CN5: DVI-D Connector (16pin 2.0mm) Pin No. Function Pin No. Function Pin No. Function RX2- DDC_SDA RX2+ DDC_SCL RX1- DVI HP RX1+ DVI_5V RX0- RXC- RX0+ RXC+ CN2: Analog RGB Input connector (D-SUB 15Pin) Pin No. Symbol Description Pin No. Symbol Description Analog Red...

  • Page 26: J1: Power Connector (12V) (6Pin 2.0Mm)

    Power connector (12V) (6PIN 2.0mm) Pin No. Function Pin No. Function 12VDC 12VDC 12VDC J8: Power connector (5V/12v)(4PIN 2.0mm) Pin No. Function Pin No. Function 5VDC 12VDC J2: Inverter Connector(8PIN 2.0mm) Pin No. Symbol Description Pin No. Symbol Description ON/OFF Backlight ON/OFF BRIGHT Dimming adjust...

  • Page 27: J11 Extern Funtion Connector (11P X 2Pin 2.0Mm)

    Extern Funtion Connector (11P X 2PIN 2.0mm) Pin No. Function Pin No. Function Audio-R Audio-L J5: Ambient (3PIN 2.0mm) Pin No. Function Pin No. Function 3.3VDC Sensor Out J4: VR connector (3PIN 2.0mm) Pin No. Function Pin No. Function 3,3VDC VR Out J12: IR Connector(3PIN 2.0mm)

  • Page 28: I/O Board Pin Define

    8.4 I/O BOARD Pin Define J1:Component Y Pin No. Function Pin No. Function J2:Component Cb Pin No. Function Pin No. Function J3:Component Cr Pin No. Function Pin No. Function J4:S-Video Pin No. Function Pin No. Function Luminance Chrominance J5:Composite Pin No. Function Pin No.

  • Page 29: Ir Receive Board Pin Define

    8.5 IR Receive Board Pin Define J1: IR Connector Pin No. Function Pin No. Function DATA OUT 8.6 DC Characteristics. Power Consumption Note1 ℃ Operation Temperature 0~70 ℃ Storage Temperature -20~85 Note: These values are for the A/D board body. Page 29...

  • Page 30: Osd Menu

    “0”, while press “right” you can increase the brightness to “100”. Ambient light sensor: press this Icon, must to accompany with Litemax ambient light sensor to auto dimming.(OPTION) Potentiometer: press this icon, adjust VR function.(OPTION) Ambient light sensor with OSD offset: press this Icon Press ’menu’’...
  • Page 31 Sound : There are 3 options for “Sound” sub page. Audio Volume: Audio volume adjustment. Mute: You can mute the speaker by pressing this option. Exit: back to the normal screen. Auto Color: by press this “Auto Color” option, you can get the optimal color performance.
  • Page 32 Color Tempture: You can have 3 options in this selection. Color Tempture User Color Tempture_6500K Color Tempture_93OOK “user mode”, “6500K” (Warm color scheme), “9300K (Cold color scheme). Def ault is “user”, and inside all “R”, “G”, and “B” are set “100” Exit: back to the normal screen.
  • Page 33 Auto just: Pressing this option, the AD2662 will adjust the optimal frequency of horizontal and vertical. You will see “Auto tune….” On the screen for around 3 seconds. Clock: If you are not satisfied about the Autotune result, you can adjust manually by “Clock”.
  • Page 34 Osd_time: You can selection the time of OSD from 2 sec. to 16 sec. Osd_HPos: You can move the OSD horizontally over the screen. Osd_VPos: You can move the OSD Vertically over the screen. Exit: back to main menu. Factory_Reset: By pressing this, the screen will be back to the factory setting on very beginning and lost all the personal settings.

  • Page 35: Mechanical Drawing

    9.0 MECHANICAL DRAWING SLD2415 Page 35...
  • Page 36 SLO2415 Page 36...

  • Page 37: Precautions

    10.0 PRECAUTIONS HANDLING PRECAUTIONS (1) The module should be assembled into the system firmly by using every mounting hole. Be careful not to twist or bend the module. (2) While assembling or installing modules, it can only be in the clean area. The dust and oil may cause electrical short or damage the polarizer.
