LITEMAX SSD1505 V2 User Manual

Sunlight readable 15” led b/l lcd
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LITEMAX
SSD1505 V2
Sunlight Readable 15" LED B/L LCD

User Manual

Approved by
Checked by
Prepared by
Ming
Jacky
Eric
LITEMAX
Electronics Inc.
8F, No.137, Lane 235, Bau-chiau Rd.,
Shin-dian Dist., New Taipei City, Taiwan
R.O.C.
Tel : 886-2-8919-1858
Fax: 886-2-8919-1300
Homepage:
http://www.litemax.com
LITEMAX
Electronics Inc.
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSD1505 V2 and is the answer not in the manual?

Questions and answers

Related Manuals for LITEMAX SSD1505 V2

Summary of Contents for LITEMAX SSD1505 V2

  • Page 1: User Manual

    LITEMAX SSD1505 V2 Sunlight Readable 15” LED B/L LCD User Manual Approved by Checked by Prepared by Ming Jacky Eric LITEMAX Electronics Inc. 8F, No.137, Lane 235, Bau-chiau Rd., Shin-dian Dist., New Taipei City, Taiwan R.O.C. Tel : 886-2-8919-1858 Fax: 886-2-8919-1300 Homepage: http://www.litemax.com...

  • Page 2: Record Of Revision

    Record of Revision Version and Date Page Old Description New Description Remark August/05/2016 Initial release LITEMAX Electronics Inc. Page 2...

  • Page 3: Table Of Contents

    General Description ........................19 Outline Dimensions ........................20 AD2662GDHMVAR Pin Definition ..................22 OSD Functions .......................... 28 Precautions ............................35 Handling Precautions ........................ 35 Storage Precautions ........................35 Operation Precautions ....................... 35 Disclaimer ............................35 LITEMAX Electronics Inc. Page 3...

  • Page 4: General Description

    General Description The SSD1505 is a 15 inch color TFT-LCD display with special aspect ratio 16:3 and wide resolution 1280 x 242. It is Litemax’s Spanpixel series product which designed for high brightness 1000 nits with power efficiency LED backlight.

  • Page 5: Absolute Maximum Ratings

    Note 2:Permanent damage to the device may occur if exceeding maximum values Note 3:Temperature and relative humidity range are shown as the below figure. 1. 90% RH Max ( Ta ≦39°C) 2. Max wet-bulb temperature at 39°C or less . ( Ta ≦39°C) 3. No condensation LITEMAX Electronics Inc. Page 5...

  • Page 6: Electrical Characteristics

    Electrical Characteristics DC Characteristcs Note 1:Measurement Conditions: The duration of rising time of power input is 470 us. LITEMAX Electronics Inc. Page 6...
  • Page 7 DC Characteristcs of each signal are as following DC Characteristics of each signal are as following: Note 1: LVDS Signal Waveform LITEMAX Electronics Inc. Page 7...
  • Page 8 (2) AC Characteristics LITEMAX Electronics Inc. Page 8...

  • Page 9: Input Terminal Assignment

    INPUT TERMINAL ASSIGNMENT LVDS INPUT Pin Assignment LITEMAX Electronics Inc. Page 9...

  • Page 10: Lvds Interface

    LVDS INTERFACE JEDIA Format : SELLVDS=L VESA Format : SELLVDS=H or Open VESA LVDS Format Pixel Format Definition Following figure shows the relationship between theinput signals and LCD pixel format. LITEMAX Electronics Inc. Page 10...

  • Page 11: Interface Timing

    INTERFACE TIMING INPUT SIGNAL TIMING SPECIFICATIONS The input signal timing specifications are shown as the following table Timing Diagram LITEMAX Electronics Inc. Page 11...

  • Page 12: Power On/Off Sequence

    Signals from any system shall be Hi-Z state when VDD is off. Note1 :Recommend setting T5 = 0ms to avoid electronic noise when VDD is off. Note2 : During T5 and T6 period , please keep the level of input LVDS signals with Hi-Z state. LITEMAX Electronics Inc. Page 12...

  • Page 13: Optical Specification

    Test Mode: θy=0 (1) (4) Color Saturation NTSC Klein K-10 θx+ Horizontal θx- Viewing Test Mode: CR ≥ 10 θy+ Angle (1) (3) Vertical θy- Test Mode： (1) Definition of Viewing Angle (θx , θy): LITEMAX Electronics Inc. Page 13...

  • Page 14: Active Area

    (2) Definition of Test Point: Active Area (3) BM-7 Measurement Setup: (4) Klein K-10 Measurement Setup: LITEMAX Electronics Inc. Page 14...

  • Page 15: Led Driving Board Specifications

    90.8 Remark: (1) this data is based on the testing result of practical input voltage, Iin is measured by related Vin.(min, typ, max) (2) η out(max) outH(max) in(max) inH(min) η out(min) outH (min) in(min) inH(max) LITEMAX Electronics Inc. Page 15...

  • Page 16: Connector Socket Input Connector

    Brightness Brightness control Control ON/OFF Control Output Connector: J2,J3 (JST S2B-EH or Compatible) PIN NO Symbol Description Output LED High Voltage( + ) Output LED Low Voltage ( - ) Mechanical Characteristics Dimension: 70mm*30mm*9mm 8.5mm LITEMAX Electronics Inc. Page 16...

  • Page 17: Mechanical Drawing

    Mechanical Drawing LITEMAX Electronics Inc. Page 17...
  • Page 18 LITEMAX Electronics Inc. Page 18...

  • Page 19: Ad2662Gdhmvar & Osd Functions

    *External V.R. brightness control (optional) • *External light sensor brightness control (optional) • *External RS232 control (optional) • Input power 12V (DC) • CBVS, S-VIDEO, *YCbCr (optional) input • Audio in and 2Wx2 Audio Out (optional) LITEMAX Electronics Inc. Page 19...

  • Page 20: Outline Dimensions

    Outline Dimensions AD2662GDHMVAR 125mmX75mm LITEMAX Electronics Inc. Page 20...
  • Page 21 I/O Board 160mmX25mmX15mm HDMI Board 37mmX21.5mmX6.5mm LITEMAX Electronics Inc. Page 21...

  • Page 22: Ad2662Gdhmvar Pin Definition

    AD2662GDHMVAR Pin Definition LITEMAX Electronics Inc. Page 22...
  • Page 23 Shield HDMI 5V Shield Hot Plug Detect 8.3.3 CN5: DVI-D Connector (16pin 2.0mm) Pin No. Function Pin No. Function Pin No. Function RX2- DDC_SDA RX2+ DDC_SCL RX1- DVI HP RX1+ DVI_5V RX0- RXC- RX0+ RXC+ LITEMAX Electronics Inc. Page 23...
  • Page 24 Pin No. Function Pin No. Function 12VDC 12VDC 8.3.7 CN1: Power Jack (12V) Pin No. Function Pin No. Function 12VDC 8.3.8 J1: Power connector (12V) (4PIN 2.0mm) Pin No. Function Pin No. Function 12VDC 12VDC LITEMAX Electronics Inc. Page 24...
  • Page 25 FUNCTION KEY UP KEY 8.3.13 J10: Speaker Connector (4PIN 2.0mm) Pin No. Function Pin No. Function SPK_R+ SPK_R- SPK_L- SPK_L+ 8.3.14 J11 Extern Function Connector (11P X 2PIN 2.0mm) Pin No. Function Pin No. Function LITEMAX Electronics Inc. Page 25...
  • Page 26 8.3.19 (I/O Board) J2: Component Cb Pin No. Function Pin No. Function 8.3.20 (I/O Board) J3: Component Cr Pin No. Function Pin No. Function 8.3.21 (I/O Board) J4: S-Video Pin No. Description Pin No. Description Luminance Chrominance LITEMAX Electronics Inc. Page 26...
  • Page 27 Pin No. Function Pin No. Function 8.3.24 (I/O Board) CN1: 11P X 2 Connector Pin No. Function Pin No. Function Component Cb Component Y Component Cr S-Video Y S-Video C Composite Audio IN(R) Audio IN(L) LITEMAX Electronics Inc. Page 27...

  • Page 28: Osd Functions

    Exit the screen adjustment; push the “MENU” button. When no operation is done around 30 sec (default OSD timeout), it goes back to the stand-by mode and no more switching is accepted except MENU to restart the setting. LITEMAX Electronics Inc. Page 28...
  • Page 29 “0”, while press “right” you can increase the brightness to “100”. Ambient light sensor: press this Icon, must to accompany with Litemax ambient light sensor to auto dimming.(OPTION) Potentiometer: press this icon, adjust VR function.(OPTION) Ambient light sensor with OSD offset: press this Icon Press ’menu’’...
  • Page 30 There have VGA, DVI, HDMI, AV, S-VIDEO, YPBPR source input. Sound: There are 3 options for “Sound” subpage. Audio Volume: Audio volume adjustment. Mute: You can mute the speaker by pressing this option. Exit: back to the normal screen. LITEMAX Electronics Inc. Page 30...
  • Page 31 Color Temperature User Color Temperature_6500K Color Temerapture_9300K Exit: back to the normal screen. “User mode”, “6500K” (Warm color scheme), “9300K (Cold color scheme). Default is “user”, and inside all “R”, “G”, and “B” are set “100” LITEMAX Electronics Inc. Page 31...
  • Page 32 HPos: You can shift the screen horizontally by this function. Vpos: You can shift the screen vertically by this function. Exit: Back to normal screen. Tools : On the “Tools” sub menu, you will see 4 icons. LITEMAX Electronics Inc. Page 32...
  • Page 33 “Menu” and “right >” buttons simultaneously. You will see the “lock” icon below on the center of the screen for 3 seconds. If any button is pushed after the lock function is LITEMAX Electronics Inc. Page 33...
  • Page 34 To release the OSD lock, press “Menu” and “Right >”. The below icon will appear on the center of the screen for 3 seconds. Now all OSD keys are active again. LITEMAX Electronics Inc. Page 34...

  • Page 35: Precautions

    (2) Always follow the correct power on/off sequence when LCD module is connecting and operating. This can prevent the CMOS LSI chips from damage during latch-up. Disclaimer All information in this document are subject to change, please constant LiteMax for any new design. LITEMAX Electronics Inc.
