5. NOTES FOR INSTALLATION

5.1
For the reader cable connection to the CODE Controller, CAT 5 cable or 8 core
twisted pair cable can be used.
5.2
The reader is normally installed at the right side of the door (outside) at a height
of 1.4m from the floor and 3-5 cm from the door frame, with the exit button
(inside) also 1.4m from the floor
5.3
The reader should not be installed against a metal surface. If this can not be
avoided, either the metal surface should be removed, with only the fixing area
remaining, or an isolation material thicker than 10cm should be placed
between the reader and the metal surface.
5.4
The Controller to reader length should not exceed 60 metres using CAT 5 cable
5.5
Please observe reader power polarity when connecting to the access controller
6. INSTRUCTIONS FOR KEYPAD
6.1
The CODE Keypad supports 6-digit number password
6.2
The Reader converts the 6-digit Password number to a 26-bit Wiegand output.
6.3
The user should input the second digit within 2 seconds after inputting the first.
Otherwise the first digit will be deleted and the user has to input the password again.
