INTRODUCTION
This service manual describes the latest service information
for the IC-E7 VHF/UHF DUALBAND FM TRANSCEIVER at
the time of publication.
MODEL VERSION
Europe
Italy
IC-E7
France
United Kingdom
To upgrade quality, all electrical or mechanical parts and internal
circuits are subject to change without notice or obligation.
DANGER
NEVER connect the transceiver to an AC outlet or to a DC
power supply 3.7 V. Such a connection could cause a fire or
electric hazard.
DO NOT expose the transceiver to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when
connecting the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100 mW)
to the antenna connector. This could damage the trans-
ceiver's front end.
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit Icom parts number
2. Component name and informations
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
5030002860 LCD A01B004X
8810008990 Screw PH B0 2×10 ZK
Addresses are provided on the inside back cover for your
convenience.
1. Make sure the problem is internal before disassembling the transceiver.
2. DO NOT open the transceiver until the transceiver is disconnected from its power source.
3. DO NOT force any of the variable components. Turn them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insulated turning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the transceiver is defective.
6. DO NOT transmit power into a signal generator or a sweep generator.
7. ALWAYS connect a 30 dB to 40 dB attenuator between the transceiver and a deviation meter or spectrum analyzer when
using such test equipment.
8. READ the instructions of test equipment thoroughly before connecting equipment to the transceiver.
Icom, Icom Inc. and
Kingdom, Germany, France, Spain, Russia and/or other countries.
SYMBOL
EUR
ITR
FRA
UK
IC-E7 Main unit 5 pieces
IC-E7 Chassis 10 pieces
REPAIR NOTES
logo are registered trademarks of Icom Incorporated (Japan) in the United States, the United
