  • Page 1 USER GUIDE D680C Solo...
  • Page 3 Follow all safety instructions in order to ensure proper operation of your device. The manufacturer accepts no liability if these instructions are not followed. declaration compliance looked www.sagemcom.com website section «Support», or can be obtained from the following address: Sagemcom USA LLC 14651 North Dallas Parkway Suite 900 Dallas, TX 75254...

  • Page 4: Safety Instructions

    Recommendations and safety instructions For safety reasons, never put the handset in the base station without the battery inserted or without the lid on the battery compartment as this could cause an electric shock. To avoid damaging your handset/base, only use certified rechargeable batteries NiMH 1.2 V 750 mAh, never use non rechargeable batteries.
  • Page 5 In zones where there is a risk of frequent thunder storms, we recommend that you protect your telephone line using an electric power surge protection device. Avoid using the telephone during an electrical storm, there may be a remote risk of electric shock from lightning. Do not attempt to remove screws or open the appliance.
  • Page 6 D680C FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's -authority to operate the equipment. FCC ID: VW3D680C This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: this device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation.
  • Page 7 D680C • This product complies with FCC radiation exposure limits set forth for an uncontrolled environment. • To comply with FCC RF exposure requirements, the base unit must be installed and operated 20 cm (8 inches) or more between the product and all person's body (excluding extremities of hands, wrist and feet).
  • Page 8 Should you experience trouble with this equipment, please contact [US: 1 866 242 3550], for repair or warranty information, Service can be facilitated through our office at: Sagemcom USA LLC 14651 North Dallas Parkway Suite 900 Dallas, TX 75254 If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved.
  • Page 9 D680C b) The USOC jack required [RJ11C] c) Facility Interface Codes ("FIC") [XXX] d) Service Order Codes ("SOC") [XXX] e) The FCC Registration Number [US: NS3W400BD680C] If this product is equipped with a corded or cordless handset, it is hearing aid compatible. FCC ID: VW3D680C US: NS3W400BD680C REN: 0.0B...

  • Page 10: Table Of Contents

    D680C Contents Discover............11 Your phone ................. 11 Unpacking........................11 Installing the belt clip....................12 The handset......................... 13 The base ........................14 Connecting the base....................15 Browser......................... 16 Menu browsing ......................16 The screen ........................19 Charging................20 Handset set-up..............21 Replacing the batteries ............
  • Page 11 D680C Options during a call ............34 Enable/Disable loudspeaker (hands-free mode) ..........34 Adjusting volume......................34 Enable the mute mode....................35 Using additional handsets ........... 36 Calling another handset (intercom) ..............36 Intrusion........................36 Manage your contacts........37 Use the phonebook ............. 37 Create an entry ......................
  • Page 12 D680C Handset version ......................48 Resetting the handset....................49 The base ................50 Changing the base code ..................50 Resetting the base..................... 50 Base version........................ 51 The line ................52 Change the line name....................52 Pair the handset with a line ..................52 Allow three-way communication (Intrusion) ............

  • Page 13: Discover

    D680C Discover... Discover... Your phone Unpacking Open the box and make sure it contains the following items: A belt clip A handset Un chargeur équipé de Un chargeur équipé de Un chargeur équipé de A base son bloc son bloc son bloc d’alimentation d’alimentation...

  • Page 14: Installing The Belt Clip

    D680C Discover... Installing the belt clip To install the belt clip: 1 First insert one side of the clip into the dedicated slot (A). 2 Gently press on the other side of the clip until the pin snaps into the other slot.

  • Page 15: The Handset

    D680C Discover... The handset Description 6. Alphanumeric keyboard: long press the numeric buttons to initiate calls to pre-programmed numbers. 7. Star key: lock / unlock keypad (long press). 8. R key: allows you to put a conversation on hold by pressing the R key or disconnect the call in process, by pressing the R key...

  • Page 16: The Base

    D680C Discover... The base Caption Description Indicator light button Paging/Pairing: • Short press: paging of handsets. • Long press: pairing of handsets. Power socket Telephone socket Note Indicator light operation: Fixed: base startup. Fast flashing: the base is in pairing mode. Medium Flashing: searching for handsets paired to the base.

  • Page 17: Connecting The Base

    D680C Discover... Connecting the base Phone Cable Gateway Take the base and turn it over. 1 Plug the telephone cord into the socket. 2 Connect the other end of the cord to the cable Gateway. 3 Take the power adapter. Connect the power adapter cord to the underside of the base.

  • Page 18: Browser

    D680C Discover... Browser Legend Item Description Loudspeaker (switch hands-free mode)/disable (switch to handset mode). Enable/disable the silent mode. Select key / Main menu access key. Phonebook access key. Call log access key. Menu browsing To browse through menus, use the browser keys and the keys Corresponds to...
  • Page 19 D680C Discover... You can go directly to the desired menu by pressing the corresponding sub-menu number (from 1 to 6). Menu Menu 2: Voicemail Menu 3: Calls Menu 1: Phonebook Menu 4: Accessories Menu 6: Settings Menu 5: Melodies Select Back 1 Press Menu 2 Press the top or the bottom ...
  • Page 20 D680C Discover... ETAILED BROWSER EXAMPLE CHANGING THE RING TONE OF EXTERNAL CALLS 1 Press Menu key). The main menu is displayed on the screen. 2 Press the () key then press the () key. 3 Enter the Melodies menu by pressing the (OK) key.

  • Page 21: The Screen

    D680C Discover... The screen HE ICONS DISPLAYED In standby mode or during use, your phone screen communicates your phone’s current state through icons, and in particular: 10:00 pm 01/31/2013 DECT X Menu Phonebook Legend Description Status icons: indicates your phone's current state. Information field: the current time HH:MM (am /pm), the current date MM/DD/YYYY,...

  • Page 22: Charging

    D680C Discover... Charging To charge your telephone, place the handset on its charger and make sure the charger is connected to the power supply. The battery charging icon moves to inform you that charging is in progress. The icon display stops moving when the batteries are charged. Note The handset's approximate operating times are: - Talk time: 10 hours.

  • Page 23: Handset Set-Up

    2 Install the new batteries one by one, noting the polarity of the batteries, and replace the battery cover. 3 The message " SAGEMCOM " is displayed on the screen for a few seconds. 4 The Language menu is displayed.
  • Page 24 , the "Power off ?" Power off ? message is displayed on the screen. Long press Long Press Yes to confirm. To turn on your handset, press the red key , the "SAGEMCOM" agemcom Long press Long message is displayed on the screen.

  • Page 25: Replacing The Batteries

    D680C Discover... Replacing the batteries 1 Turn off the handset. Turn it around so that the battery compartment is accessible. 2 Remove the battery compartment cover. 3 Remove the old batteries, insert the new batteries, noting the polarity of the batteries. 4 Replace the battery compartment cover.

  • Page 26: Menu Tree Structure

    D680C Discover... Menu tree structure Phonebook List Options Search During a call Second call Delete all Intercom Speed Dialing Calls Phonebook Voicemail Selec. call line Mute Call Edit Calls All calls Melodies Incoming calls External ringtone * Outgoings calls Internal ringtone Missed calls Beeps Events...
  • Page 27 D680C Discover... Settings Settings Date/time Auto hang/pick up Language Display Advanced settings * Registration Set handset Person.regist Base priority Handset Version Reset handset Change code Set base Reset base Base Version Set line Line name Attached HS Configuration Flash time Selec.

  • Page 28: Call

    D680C Call... Call... Note If the handset is being synchronized with the base, the "Please wait" message is displayed on the screen. It is not possible to make or receive calls until the "Please wait" message has disappeared from the screen. Managing calls Making a call Note...

  • Page 29: Ending A Call

    D680C Call... 2 (P ETHOD DIALING Call in handset mode 1 Press on the green key for 3 or more seconds. 2 Dial your contact’s number. Call in speakerphone mode 1 Press on the loudspeaker key to speak in speakerphone mode. The icon is displayed on the screen.

  • Page 30: Receiving A Call

    D680C Call... Receiving a call o answer a call press the key or simply pick the handset up from its base if the automatic pick up option is activated. You can also press Accept or press key. 2 At the end of the call, press the handset key and put the handset back on its charger.

  • Page 31: Managing Several Calls

    D680C Call... Managing several calls Your phone allows you to take and manage several calls (subject to service availability) when you are already on a call. Receiving a second call During a call, a beep indicates the arrival of a second call. The contact details of the second caller are displayed on the screen.

  • Page 32: Ending One Of The Calls In Progress

    D680C Call... Ending one of the calls in progress • During a conversation press Options. • Choose the option Release using the  or  keys. Press OK. The current call is ended and you resume the previous call. Note During the call you can hang up both calls by pressing key for a long time.

  • Page 33: Making A Second Call

    D680C Call... Making a second call • During a conversation press Options. • Choose the option Second call using the  or  keys. Press OK. • Select the number for the person you want to call in the address book by pressing , and then OK.

  • Page 34: Transferring Calls

    D680C Call... Transferring calls During a call, you can transfer it to another handset. This function can be used as long as two handsets have been registered to the same base. • During a conversation press Options. • Choose the option Intercom. Press OK. NANNOUNCED TRANSFER This function allows you to transfer the current call directly to another device.
  • Page 35 D680C Call... NNOUNCED TRANSFER This function allows you to transfer the current call to another device once it has been picked up Steps Calling handset Called handset Press OK. Select the handset (or all handsets) to call. Press OK. Rings: internal call. Press the key to accept the internal call.

  • Page 36: Options During A Call

    D680C Call... Options during a call You can use the following options during a call: Enable/Disable loudspeaker (hands-free mode) ANDSET LOUDSPEAKER During the call you can activate hands-free mode pressing the key. 3021547 The icon is displayed on the 3021547 01:24 01:24 Mute...

  • Page 37: Enable The Mute Mode

    D680C Call... Enable the mute mode During a call, you can switch to mute mode and your handset's microphone will be muted and your contact will no longer hear you. TO ENABLE THE MUTE MODE • During a conversation, press Options •...

  • Page 38: Using Additional Handsets

    D680C Call... Using additional handsets You can associate additional handsets with your phone. You can then make and receive outside calls or calls between these handsets. Note ou first have to pair the handsets with the base. For further details, refer to the section “Associating a new handset ”, page 46 Calling another handset (intercom)

  • Page 39: Manage Your Contacts

    D680C Manage your contacts... Manage your contacts... Use the phonebook Your phonebook is common to all the DECT handsets paired to the same base. You can also directly access the list of phonebook entries using key. When browsing through the phonebook, the handset displays the number of the current entry and the total number of available entries.

  • Page 40: Call A Contact From The Phonebook

    D680C Manage your contacts... Call a contact from the phonebook • Press Menu • Select Phonebook, press OK. • Select an entry using List or Search and press OK. • Select Call and press OK. Changing an entry • Press Menu •...

  • Page 41: Delete All The Entries

    D680C Manage your contacts... Delete all the entries • Press Menu • Select Phonebook, press OK. • Select Delete all using the or  keys. Press OK. For the question Delete all?, press OK to confirm the deletion of all •...

  • Page 42: Voicemail Service

    D680C Voicemail Service Voicemail Service Warning You should not change the voicemail number unless instructed by your phone service provider. Note The default voice mail number is *99. Modifying the Voicemail number This function allows you to change your voicemail number. Unanswered calls are redirected to your telephone line's voicemail.

  • Page 43: Audio Adjustment

    D680C Audio adjustment... Audio adjustment... Changing the ringtone You can change the ring of: outside calls, calls between handsets (intercom). • Press Menu • Select Melodies, press OK. • Select External ringtone to change the ringing tone for external calls. - OR - •...

  • Page 44: Enabling/Disabling Audio Alerts

    D680C Audio adjustment... Enabling/Disabling audio alerts Audio alerts refer to: • pressing the keypad keys, • putting the handset on the charger, • low battery alert, others (error alerts). • Note The enabled function is marked by the symbol • Press Menu •...

  • Page 45: Setting Up

    D680C Setting up... Setting up... The phone Setting the date and the time Note The time format is 12 hours, use thekey to set am or • Press Menu • Select Settings, press OK. • Select Settings using the  or  keys and press OK. •...

  • Page 46: Picking Up And Hanging Up Calls Automatically

    D680C Setting up... Picking up and hanging up calls automatically This function allows you to take and end a call by simply taking the handset off or placing it back on its charger. • Press Menu • Select Settings, press OK. •...

  • Page 47: Adjust The Brightness

    D680C Setting up... Adjust the brightness • Press Menu • Select Settings, press OK. • Select Settings using the  or  keys and press OK. • Select Display using the  or  keys and press OK. • Select Brightness using the  or  keys and press OK. •...

  • Page 48: The Handset

    D680C Setting up... The handset Associating a new handset The base allows you to pair additional handsets so that they are recognized. ROM THE BASE To enable the pairing mode, press and hold (on the bottom of the base). ROM THE HANDSET Case 1: The handset displays "Please Register".

  • Page 49: Customizing The Handset's Registration

    D680C Setting up... Customizing the handset’s registration This function allows you to pair your handset with a phone base (if you have more than one phone base). • Press Menu • Select Settings, press OK. • Select Advanced settings using the  or  keys and press OK. •...

  • Page 50: Defining The Main Base For Your Handset

    D680C Setting up... Defining the main base for your handset This function allows you to specify the priority base to be used for making calls. Note Only if you have paired the same handset on several bases. • Press Menu •...

  • Page 51: Resetting The Handset

    D680C Setting up... Resetting the handset When you reset your handset, all the settings are returned to their initial values (factory settings), except for the phonebook. • Press Menu • Select Settings, press OK. • Select Advanced settings using the  or  keys and press OK. •...

  • Page 52: The Base

    D680C Setting up... The base Changing the base code The base code (PIN number) is 0000 by default, but can be changed to 4 other numbers. You will be prompted to enter it, when registering a new handset. • Press Menu •...

  • Page 53: Base Version

    D680C Setting up... Base version • Press Menu • Select Settings, press OK. • Select Advanced settings using the  or  keys and press OK. • Select Set base using the  or  keys and press OK. • Select Base Version using the ...

  • Page 54: The Line

    D680C Setting up... The line This menu allows you to change the settings of the lines on the base. We do not recommend that you change line settings without Important first contacting your operator, as this may result in your phone line being disconnected.

  • Page 55: Allow Three-Way Communication (Intrusion)

    D680C Setting up... Allow three-way communication (Intrusion) This intrusion function allows or prohibits a second handset registered on the same base to share an ongoing conversation. If the intrusion mode is enabled, you will then be able to share a call in progress with another handset.

  • Page 56: Call Management

    D680C Setting up... Call management This menu allows you to select the line on which you want to make your first outgoing call. Managing your calls • Press Menu • Select Settings, press OK. • Select Advanced settings using the  or  keys and press OK. •...

  • Page 57: The List Of Handsets

    D680C Setting up... The list of handsets This menu displays the list of handsets registered on the same base. Manage handsets • Press Menu • Select Settings, press OK. • Select Advanced settings using the  or  keys and press OK. •...

  • Page 58: Accessories

    D680C Accessories... Accessories... The alarm Note The alarm clock function arranges your handset to ring each day at a specified time. Once a time is programmed, the selected ringtone rings for 60 seconds through the handset’s loudspeaker and a warning screen is displayed. To stop the warning, press any key on the handset.

  • Page 59: The Timer

    D680C Accessories... The timer Note The timer function enables the handset to ring after a programmed time. You can view the time countdown in minutes on the screen. Program the timer • Press Menu • Select Accessories, press OK. • Select Timer using the ...

  • Page 60: Tracking Your Calls

    D680C Tracking your calls... Tracking your calls... Call logs Logs are lists of numbers or events received or sent by your phone. Depending on your phone company and the options of your contract, the following information may be accessed in the call logs: •...

  • Page 61: Viewing The Received Or Dialed Call Log

    D680C Tracking your calls... Viewing the received or dialed call log Note Unknown calls are not included in the received call log. • Press Menu • Select Calls, press OK. • Select Incoming calls, (or Outgoings calls) using  or  keys then press OK.

  • Page 62: Consulting The Missed Call Log

    D680C Tracking your calls... Consulting the missed call log icon is displayed if there are one or more new missed call which have not been reviewed yet. Note Once the missed call log has been viewed, the icon disappears from all handsets. •...

  • Page 63: Managing Incoming Or Outgoing Calls

    D680C Tracking your calls... Managing incoming or outgoing calls Menu > Calls • Press Menu • Select Calls, press OK. • Select All calls or Outgoings calls or Incoming calls or Missed calls then press OK. • The list of calls (incoming/outgoing/missed) is displayed. •...

  • Page 64: The Events Log

    D680C Tracking your calls... The events log Note icon is displayed if there is one or more voicemail messages. Checking new events A summary screen for the number of events that occurred in your absence is displayed: number of missed calls, operator messages.

  • Page 65: Appendix

    D680C Appendix Appendix Care and Maintenance Turn off the device and remove it from the power supply before cleaning the surface. Use a soft, lint-free cloth. Never user liquid, gaseous or easily flammable cleansers (sprays, abrasives, polishers, alcohol). Do not allow any moisture to reach the interior of the device.
  • Page 66 D680C Appendix Problems Remedies No radio link between the • Make sure the handset is registered by handset and base. moving closer to the base, if it is registered correctly, the handset screen should display its own handset number. You obtain a "busy" dial •...

  • Page 67: Environment

    Environment Environmental protection and sustainable development is an important priority for Sagemcom. Sagemcom has a policy of using environmentally- friendly systems and makes environmental protection an essential part of the life-cycle of its products – from the manufacturing, to the installation, operation and disposal.

  • Page 68: Guarantee

    Consumer for Products purchased and used in the United States of America. What will Sagemcom do if the Product is not free from defects in materials and workmanship during the limited warranty period (“Materially Defective Product”)? During the limited warranty period, Sagemcom’s authorized service...
  • Page 69 Sagemcom will return repaired or replaced Product under this limited warranty. Transportation, delivery or handling charges are prepaid. Sagemcom assumes no risk for damage or loss of the Product in transit. If the Product failure is not covered by this limited warranty, or proof of...

  • Page 70: Other Limitations

    This warranty is the complete and exclusive agreement between you and Sagemcom. It supersedes all other written or oral communications related to this Product. Sagemcom provides no other warranties for this Product. The warranty exclusively describes all of Sagemcom’s responsibilities regarding the Product.
  • Page 71 D680C Guarantee • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Privacy of communications may not be ensured when using this telephone!
  • Page 72 Sagemcom Broadband SAS 250, route de l'Empereur - 92848 Rueil-Malmaison - France Tél. +33(0)1 57 61 10 00 - Fax : +33(0)1 57 61 10 01 www.sagemcom.com...
