1050 Keyboard

For access, remove this FRU:
v "1010 Battery pack" on page 68
1a
Screw 1a is only for the models with 14.1-in. LCD.
Step Icon
1
3
1a
(continued)
Screw (quantity)
M2 × 12 mm, bind-head,
nylon-coated (3)
M2 × 12 mm, bind-head,
nylon-coated (1)
ThinkPad R50/R50p and R51 Series
Removing and replacing a FRU
1
Color
Black
Black
Torque
0.245 Nm
(2.5 kgfcm)
0.245 Nm
(2.5 kgfcm)
73
