JTS US-8010 Instruction Manual

Hide thumbs Also See for US-8010:
Table of Contents

Advertisement

Quick Links

Download this manual
US-8010
US-8010D Series
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the US-8010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JTS US-8010

Summary of Contents for JTS US-8010

  • Page 1 US-8010 US-8010D Series Instruction Manual...
  • Page 2 Thank you for choosing the JTS wireless system. In order to obtain the best efficiency from the system, you are recommended to take a few minutes to read this instruction manual carefully.
  • Page 3 INDEX 1. Important Caution 2. Features 3. Specification 3-1 Receiver// US-8010D/ US-8010 3-2 Handheld Transmitter // Mh-700 / Mh-800 / Mh-700D 3-3 Body-pack Transmitter // PT-900B / PT-900BD 3-4 Optional Condenser Microphone 4. Part Identification & Accessories 4-1 Receiver// US-8010D/ US-8010...

  • Page 4: Important Caution

    1. Important Caution • Always makes all connections before plugging the unit into an AC power outlet. • Do not leave the device in a place neither with high temperature nor high humidity. • Always do not handle the power cord with wet hands! •...

  • Page 5: Specification

    3. Specification 3-1 Receiver Model No........US-8010D / US-8010 Frequency Preparation..Crystal Carrier Frequency Range 600~960 MHz Frequency Stability....±10KHz S/N Ratio........> 105dB T.H.D........<0.6%@1KHz Display......Display Contents....Antenna, RF/AF Status Controls......Power On/Off, Audio Level Audio Output Level....

  • Page 6: Body-Pack Transmitter

    3-3 Body-pack Transmitter Model No.......... PT-900 / PT-900BD Frequency Preparation.... Crystal Carrier Frequency Range..600~960 MHz RF Outputs........10mW Stability......... ±10KHz Frequency Deviation....±48KHz LED Display........Power On/Off, Low Battery Controls......... Power On/Off, AF Level Spurious Emissions....<-50 dBC Audio Frequency Response 40~18,000 Hz Battery........

  • Page 7: Headset Microphone

    Headset Microphone Model No....... CM-204 CM-204U CM-204UL Connector......4P Mini XLR 4P Mini XLR 801C3 (3 pin mini XLR) 801C4 (4 pin mini XLR) 801CS (3.5 stereo plug) Frequency Response..60~15,000 Hz 30~18,000 Hz 100 ~ 18,000Hz Polar Pattern......Omni-directional Cardioid Cardioid Sensitivity (at 1000Hz)
  • Page 8 Ear-hook Microphone Model No....... CM-801/CM-804i CM-8015/CM-825i Connector......801C4 (4 pin mini XLR) 801C4 (4 pin mini XLR) Option Connector... 801C3 (3 pin mini XLR) 801C3 (3 pin mini XLR) 801CS (3.5 stereo plug) 801CS (3.5 stereo plug) Frequency Response..60~15,000 Hz 50~18,000 Hz Polar Pattern......

  • Page 9: Parts Identification & Accessories

    4. Parts Identification & Accessories 4-1 Receiver // US-8010D / US-8010 Power On/Off RF indicator AF indicator Volume control Antenna DCV Input (12-18V DC/150mA) Unbalanced 6.3mm jack socket Balanced XLR socket 4-2 Handheld Transmitter // Mh-800 / Mh-700D / Mh-700...

  • Page 10: Body-Pack Transmitter // Pt-900B / Pt-900Bd

    4-3 Body-pack Transmitter // PT-900B / PT-900BD Mic. input Power On/off switch Power Indicator Antenna AF level control Battery tray Battery tray cover Carry case Belt-loop 4-4 Optional Condenser Microphone Lavaliere Microphone // CM-501 / CM-201 / CM-125 Clip 4 Pin Mini XLR Windscreen CM-501 CM-201...
  • Page 11 Headset Microphone // CM-204 / CM-204U / CM-204UL / CM-225 / CX-504 Gooseneck Headband 4 Pin Mini XLR Windscreen CM-204 CM-204U CM-204UL Standard : 4 Pin Mini XLR 3 Pin Mini XLR 3.5 Stereo Plug CM-225 CX-504...
  • Page 12 Ear-hook Microphone // CM-801 CM-804i CM-8015 CM-825i Boom CM-801 Adjustable Headband Adjustable ear hook Detchable Cable Cable Clip Windscreen 4 Pin Mini XLR 3 Pin Mini XLR Option CM-804i 3.5 Stereo Plug Option CM-8015 CM-825i WIRELESS MICROPHONE SYSTEM...
  • Page 13 Compatible Instrument Microphone // CX-500 / CX-500F / CX-520 CX-508W / CX-516W Gooseneck Clip Bracket Volume Control CX-500 Windscreen 4 Pin Mini XLR CX-500F CX-508W CX-516W CX-520...

  • Page 14: Accessories

    4-5 Accessories AC/DC adaptor Switching Power Supply(100V~240V , 50~60Hz) Linear Power Supply (220V , 50Hz) Option Linear Power Supply (220V , 60Hz) Option Screwdriver Option DR-900 dual rack adaptor RP-900 panel cover Option AF output cable (with Φ6.3 plug at both ends) GC-80/GC-100 Guitar Cable Option Option...

  • Page 15: Preparing Procedures & Basic Operation

    5. Preparing Procedures & Basic Operation 5-1 Receiver // US-8010D / US-8010 (1) Audio Output Connector The receiver equipped with both balanced XLR output and unbalanced φ 6.3mm jack output; you can choose the proper way for using. Connect one end of the Audio cable to the AF output socket in the rear panel of the receiver and plug another end to the “MIC IN”...

  • Page 16: Rack Mounting

    5-2 Rack Mounting (1) Before mount receivers onto DR-900 rack adaptor, please release any cables from the rear of the receiver. (2) Turn over receiver and DR-900 rack adaptor simultaneously, there are 4 threaded holes each in the bottom of receiver and rack adaptor for inserting screws. (3) Single receiver Insert in a receiver through the front of DR-900 until it is firmly attached to the rack, then screw on a RP-900 to another side of the rack.
  • Page 17 5-4 Handheld transmitter // Mh-700D / Mh-700 / Mh-800 (1) Mh-700D & Mh-700 & Mh-800 Handheld Transmitter 1. Turn the microphone ball grille counter-clockwise ( Figure 1), press both release knobs to remove the battery tray from the mic. housing ( Figure 2). 2.
  • Page 18 5-5 Body-pack Transmitter // PT-900B / PT-900BD (1) Basic operation 1. Slide the battery tray cover in the direction of the arrow to open it, insert two 1.5V batteries according ON/OFF the correct polarity, and return the cover. 2. Switch the transmitter On The On/Off switch is located on the top of the transmitter.

  • Page 19: Installation Of Condenser Microphones

    Plug the connector into input socket on the body-pack transmitter. MIC IN (3) Instrument Microphones The system is compatible with JTS various instrument microphones. For detail please refer to user’ s manuals of these microphones.
  • Page 20 (4) Ear-hook Microphone 1. Lightweight Dual Ear Hook Microphone Try on whether the headset is fit. Adjust the headband to a suitable width. Tighten or loosen the curve of the ear-hook by twisting the loop or expanding it. Curve and bend the boom to fit your face. Attach the detachable cable to a suitable place by a cable clip.
  • Page 21 6. Recommendation (1) In order to achieve the optimum reception condition and also extend the operating distance, please leave a “open space” between the receiver and transmitter. (2) Keep the devices away from the metal objects or any interference sources, at least 50 cm. (3) To avoid the feed-back effect, don’t leave the mic.

  • Page 22: Important Notice

    7. Important Notice (1) JTS offers wireless systems in a selection of bands that conform to the different government regulations of specific nations or geographic regions. These regulations help limit radio frequency (RF) interference among different wireless devices and prevent interference with local public communications channels, such as television and emergency broadcasts.
  • Page 24 US-8010D/US-8010/Mh-700D/Mh-700/Mh-800 PT-900BD/PT-900B 59506-041-07...
