Summary of Contents for JTS TG-98STX
- Page 2 Thank you for choosing the JTS wireless system. In order to obtain the best efficiency from the system, you are recommended to take a few minutes to read this instruction manual carefully.
-
Page 3: Table Of Contents
INDEX TG-98STX Stationary Transmitter 1. Important Cautions 2. Introduction 3. Specification 4. Parts Identification & Accessories 5. Preparing procedures & basic operation 6. Loop Out Application... -
Page 4: Important Cautions
• This stationary transmitter TG-98STX provides an option for fixed installation to the TG-98RA. It can expand coverage of the wireless system by using antenna booster, directional antenna and antenna combiner. • TG-98STX preset 6 groups each of up to 23 channels. -
Page 5: Specification
3. Specification TG-98STX Carrier Frequency Range 502 ~ 960MHz RF Output Power Hi / Low Nominal Frequency Deviation ± 40KHz (modulation) Audio Input Impedance 20KΩ Nominal Input Level -20 DBV Maximal Input Level 0 dBV LED Display AF Level, Channel... -
Page 6: Parts Identification & Accessories
4. Parts Identification & Accessories TG-98STX Power On / Off switch LED Display Channel / Group Selector Set button Volume control Monitor volume control Ø3.5mm Stereo Phone Jack Antenna DC input ( 12~18V 450mA ) Balanced Loop Out Connector CH.1 Balanced Loop Out Connector CH.2... -
Page 7: Optional Accessories
Optional Accessories RM-901 Rack Mount Kit RTF-1 Antenna Extension Cable... -
Page 8: Preparing Procedures & Basic Operation
TG-98STX (1) Connect the main unit Connect the DC INPUT in the rear panel of TG-98STX to an AC to DC adaptor. (2) Basic operation 1. Connect the mixer output to the XLR / Ø6.3mm combo CH1 input at the rear panel of TG-98STX with AF input cable. - Page 9 AF Level of CH2 Monitor channel display GROUP CHANNEL Channel display Group TG-98STX (4) Attach the antenna The user-friendly antenna comes with BNC connector. Connect the antenna on the rear of the transmitter and align it upward. ANTENNA OUT (5) Power On / Off...
- Page 10 (9) Set the rubber pad Four self-adhesive rubber pads are provided to ensure the stability. They are to be placed on the bottom of the transmitter. (10) RTF-1 Antenna Extension Cable (Optional) Antenna extension cable enables front mounting antenna which benefits the RF effeciency.
-
Page 11: Loop Out Application
Multiple Systems Make use of the loop out connectors to deliver one signal from the mixer to multiple TG-98STX or other devices. 1. Connect the mixer outputs to inputs of the first transmitter. 2. Connect loop out connectors of the first transmitter to the second one. - Page 12 PROFESSIONAL CO., LTD. No. 148, 9th Industry Road, Ta-Li Industrial Park, Taichung City, Taiwan, R.O.C. Tel: 886-4-24938803 Fax: 886-4-24914890 E-mail: jts@jts.com.tw www. jts.com.t w...
