Battery Specifications

Type
Ni-MH battery
Alkaline battery
Non-rechargeable Battery
(Lithium)
Rechargeable Battery
(Li-ion)

Battery replacement

Pull the headlamp bracket open as the arrow indicates till it is separated from the base as shown
above.
Hold back the protrusions on the back cover with your fingers (as "open" indicates), and then pull
the back cover open.
Insert the nominal batteries with the cathode side ( ) toward the spring.
Put the two snap joints towards each other, and then securely replace the cover before testing the
HL30's power and functions.
Dimensions Nominal voltage
AA 1.2V
AA 1.5V
AA 1.5V
14500 3.7V
Usability
Recommended
Usable
Usable
Banned
Two snap joints
