Flavor Burst TS 44BEV User Manual

Frozen beverage system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
Flavor Burst
Frozen Beverage System
Model TS 44BEV
Manufactured by
Flavor Burst Company
499 Commerce Drive
Danville, IN 46122
For general information and to locate a
distributor near you, call or visit our website:
Phone: (317) 745-2952
Toll Free Number: (800) 264-3528
Fax: (317) 745-2377
www.flavorburst.com
For pricing, ordering and support, contact one
of our qualified distributors.
Warranty
An installation and warranty form is provided with every TS 44BEV system, located inside the
TS 44BEV unit with this manual. It is important that the operator carefully review the warranty and
installation documents accompanying the unit before using this system. Any questions or concerns
regarding the warranty should be clarified upon delivery or installation. For more information, contact
®
your local authorized Flavor Burst
distributor.
©2014 Flavor Burst Company
Printed in January
Printed in
All Rights Reserved
The United States of America
