G51 UltraGlow
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper
installation,
alteration, service or maintenance can
cause injury or property damage. Refer to
this manual. For assistance or additional
information consult an authorised installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapours and liquids in the vicinity
of this or any other appliance.
Installation and service must be performed
by an authorised installer, service agency or
the gas supplier.
Models: G51-NG
FOR YOUR SAFETY
adjustment,
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electrical
switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fire
department.
G51-ULPG
Advertisement
Table of Contents
Related Manuals for Regency G51-NG UltraGlow
Summary of Contents for Regency G51-NG UltraGlow
- Page 1 Owners & Installation G51 UltraGlow Models: G51-NG G51-ULPG PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, What to do if you smell gas: alteration, service or maintenance can Do not try to light any appli- cause injury or property damage.
-
Page 2: To The New Owner
The G51 has been approved by the Australian Gas Association for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and the many features of your Regency Fireplace. -
Page 3: Table Of Contents
TABLE OF CONTENTS Operating Instructions Safety Label Safety Label ............... 4 Operating Instructions ..........18 Lighting Procedure ............ 18 Shutdown Procedure ..........18 First Fire ..............18 Installation Normal Operating Sounds of Gas Appliances ..........18 Unit Dimensions ............5 Important Message ............ -
Page 4: Safety Label
SAFETY LABEL (Australia Only) -
Page 5: Unit Dimensions
UNIT DIMENSIONS... -
Page 6: Important Message
INSTALLATION IMPORTANT: INSTALLATION BEFORE YOU START SAVE THESE CHECKLIST INSTRUCTIONS FOR YOUR SAFETY GAS PIPE TESTING MATERIALS REQUIRED... -
Page 7: Minimum Fireplace Dimensions
INSTALLATION MINIMUM FIREPLACE GAS CONNECTION MINIMUM DIMENSIONS CLEARANCES TO GAS CONNECTION WARNING: COMBUSTIBLES Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. REGULATOR TEST POINT PRESSURE... -
Page 8: Flueing
INSTALLATION FLUEING GAS AERATION TEST FOR FLUE SPILLAGE SETTING INSTALLATION OF FLUE GATHER Combustion and Ventilation Air WARNING: This appliance needs fresh air for safe operation and must be in- stalled with provisions for adequate combustion and ventilation air available to the room in which it is to be operating. -
Page 9: Ulpg Conversion
INSTALLATION CONVERSION KIT FROM NATURAL GAS TO ULPG #390-969 FOR G51 USING SIMPLOSIT GAS VALVE THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! R e g u l a t o r Valve Shield Screw Test point... -
Page 10: Valve Tray Installation
INSTALLATION VALVE TRAY INSTALLATION Screw Valve Shield Secure valve tray with 4 screws. Valve Cover Flex Pipe Gas Line... -
Page 11: Burner Installation
INSTALLATION BURNER INSTALLATION Burner Tube Orifice Secure burner to valve tray. Screw location in valve tray. Valve Cover... -
Page 12: Log Set Installation
INSTALLATION LOG SET INSTALLATION 02-95 The "02" reference numbers (i.e. 02-55) are moulded into the rear/bottom of each log. 02-95 Brackets 02-51 Rest notch on right side of grate. 02-95 02-95 02-51 Pins Cutouts... - Page 13 INSTALLATION 02-95 02-51 02-50 Fit notch into 2nd grate tab. Fit notch onto left side of grate. Rear Bracket Cutout 02-97 02-51 Cutouts 02-97 Fit notch into 5th grate tab. 02-50 Bracket towards back of grate. Photo shows rear of grate.
- Page 14 INSTALLATION 02-52 Embers Lava Ensure not to block the burner ports. Cutout Bracket Log 02-51 was removed to show placement of Log 02-52.
-
Page 15: Finishing Trim (Optional)
INSTALLATION OPTIONAL OPTIONAL BRICK PANELS FINISHING TRIM Left Side F i n i s h i n g Trim Top Finishing Trim... -
Page 16: Screen Installation (Optional)
INSTALLATION OPTIONAL SCREEN INSTALLATION Top Louver Top Right Bracket Top Right Pin in Screen Bracket Bottom Right Spring Loaded Pin Bracket Top Right Bracket Location Firebox Bottom Right Side Trim Bracket Screw loca- tions. Bottom Right Bracket Location Side Trim... -
Page 17: Wiring
INSTALLATION WIRING Caution: Ensure that the wires do CAUTION: Label all wires prior to not touch any hot surfaces and are disconnection when servicing con- away from sharp edges. trols. Wiring errors can cause im- proper and dangerous operation. WARNING: Electrical Grounding Instructions This appliance is equipped with a three pronged (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-prong receptacle. -
Page 18: Operating Instructions
OPERATING INSTRUCTIONS OPERATING NORMAL OPERATING INSTRUCTIONS SOUNDS OF GAS APPLIANCES SHUTDOWN PROCEDURE FIRST FIRE LIGHTING PROCEDURE Shut off Valve... -
Page 19: Lighting Plate Instructions
OPERATING INSTRUCTIONS COPY OF LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING ANY SERVICING OR REPAIRS SHOULD BE CARRIED OUT ONLY BY AN AUTHORISED PERSON. -
Page 20: Maintenance
MAINTENANCE MAINTENANCE LOG REPLACEMENT CLOTHING OR OTHER FLAMMA- INSTRUCTIONS BLE MATERIAL SHOULD NOT BE PLACED ON OR NEAR THE APPLI- ANCE. Top View of pilot flame WARNING: CHILDREN AND ADULTS SHOULD BE ALERTED TO THE HAZARDS OF HIGH SUR- FACE TEMPERATURE AND SHOULD STAY AWAY TO AVOID BURNS OR CLOTHING IGNITION. -
Page 21: Fan Replacement
MAINTENANCE FAN REPLACEMENT Rear Log Tray Ground Wire C o n n e c t o r Wires Fan Deflector... -
Page 22: Replacement Parts List
REPLACEMENT PARTS Part # Description 390-033 Hood Pilot 390-510/P Valve Assembly - NG 390-511/P Valve Assembly - ULPG 390-525 Burner Assembly - NG / ULPG 511-031 Clip Brick 560-519/P Fan Assembly 390-000 Grate Assembly 390-930 Log Set 904-258 Magnet Ceramic 904-785 1/2"... -
