- Page 1 Installation & Service Manual Reverse Osmosis Drinking Water Systems 75 GPD with Fully Automatic Noiseless Booster Pump...
- Page 2 Distributed by: Serial #...
- Page 3 Please read this entire service guide prior to beginning installation. REVERSE OSMOSIS SYSTEM WITH BUILT IN PUMP Congratulations on choosing the Millennium Reverse Osmosis System. Our high quality reverse osmosis system has been designed and tested to give you trouble free performance for many years with proper maintenance.
- Page 4 INSTALLATION DIAGRAM FOR MILLENNIUM SYSTEM (shown with standard faucet) RO dispensing Faucet Booster Pump (Fig. 1) A 3/8” Yellow tubing to tank Transformer Connect to GFI electrical outlet Stage 2: GAC carbon WARNING: CONNECT YOUR SYSTEM TO THE COLD WATER SUPPLY ONLY. DO NOT USE WATER SUPPLY THAT IS MICRO-BIOLOGICALLY UNSAFE, OR OF UNKNOWN SOURCE WITHOUT ADEQUATE DISINFECTION BEFORE OR AFTER THE SYSTEM.
- Page 5 INSTALLATION DIAGRAM FOR MILLENNIUM SYSTEM (shown with optional air gap faucet) Air Gap dispensing Faucet (Optional) 1/4” red tubing to air gap 1/4” red tubing air gap to drain clamp Booster Pump (Fig. 1) B 3/8” Yellow tubing to tank Transformer Connect to GFI electrical outlet Stage 2: GAC carbon...
- Page 6 Installation Kit Contents 1. Color Coded Tubing: Color Coded Tubing ( 4 coils, 4 colors) ¼’’ Green Tubing (approximately 8 feet) ¼’’ Red Tubing (approximately 6 feet) 3/8’’ Yellow Tubing (approximately 6 feet) 3/8’’ Blue Tubing (approximately 6 feet) Optional 5th coil is added for air gap installations 3/8”...
- Page 7 TAPPING INTO THE COLD WATER LINE A - (Using the water supply adaptor Part # PPASV121208W ) For flex metal or plastic line. NOTE: The Millennium drinking water system must be connected to the COLD water ® supply only. 1) Turn off the cold water supply to the sink faucet by locating the round or oblong handle and turning clockwise until the water supply is off.
- Page 8 DRILLING THE HOLE FOR THE FAUCET NOTE: SAFETY GLASSES SHOULD BE WORN TO PROTECT YOUR EYES WHILE DRILLING THE FAUCET WHOLE. 1) For best results, a ½” drill bit for a non air gap faucet or 7/8” dill bit for an air gap faucet should be used to drill a hole into your sink for the auxiliary faucet.
-
Page 9: Mounting The Faucet
MOUNTING THE FAUCET Standard Faucet (Fig. 4 A) 1) Drill a ½” hole in the sink or the counter top, or use an existing hole. 2) Slide chrome cover plate and rubber gasket on to stem of faucet and place faucet onto sink, with the stem going through the hole. -
Page 10: Drain Clamp Installation
DRAIN CLAMP INSTALLATION (Fig. 5) Sink 1) The drain clamp assembly should be installed above the trap and on the vertical or horizontal tail piece (Fig. 5) Mount drain saddle at either location (Fig. 6) Never mount here 2) Mark the hole position on the pipe and drill a ¼’’ hole through one side of the pipe. -
Page 11: Positioning The System
POSITIONING THE SYSTEM 1) The head assembly will stand up in the sink cabinet or can be hung on screws. 2) The storage tank may be laid on its side. The bladder tank will function both ways horizontal and vertical. 3) The head assembly and/or storage tank may be placed up to 10 feet from the point of use with some pressure loss. -
Page 12: Start-Up Procedure
START UP PROCEDURE 1) Check to see all connections are made 2) Check that the pre-filter and pre-carbon sumps are secure with “O” rings in place using the housing wrench provided. 3) Slowly turn on the water by turning the needle valve counterclockwise or ball valve 1/4 turn, where handle is parallel to the tubing line. - Page 13 5) Drain your storage tank frequently to ensure the freshness of the water in the storage tank by lifting the faucet handle into the open position until water flow stops from the tank. Return the faucet handle to the closed position and the tank will refill in 2 hours.
-
Page 14: Changing The Filters
CHANGING THE FILTERS CAUTION: ANY REPLACEMENT FILTERS OR MEMBRANES NOT RECOMMENDED BY THE FACTORY CAN CAUSE SEVERE DAMAGE TO THE SYSTEM AND VOID ALL WARRANTIES. MAINTENANCE Before starting maintenance, check the reverse osmosis system for TDS reduction to determine if membranes will or will not need to be changed. If TDS reduction is less than 90% concentration, then the membrane should be replaced. -
Page 15: Troubleshooting
TROUBLESHOOTING SYMPTOM CAUSE CORRECTION NOTES: 1) TURN WATER SUPPLY ON. 1) WATER SUPPLY IS TURNED OFF. 2) CHECK TO MAKE SURE FEED VALVE IS NOT CLOGGED. 2) NOT ENOUGH WATER PRESSURE TO 1) CHECK FEED WATER PRESSURE. MUST SYSTEM. BE AT LEAST 10PSI. 3) PREFILTERS CLOGGED. -
Page 16: Conditions Of Warranty
Millennium LIMITED WARRANTY ® The Millennium reverse osmosis system is warranted to be free from defects in materials and workmanship under normal ® use within the operating parameters listed below. For a period of five years from the date of purchase Millennium will ®...
