Insignia NS-SPBTP1-W Quick Setup Manual

Congratulations on your purchase of a high-quality Insignia product.
Your Insignia NS-SPBTP1-W Bluetooth plug-in wall speaker represents
the state-of-the-art in speaker and Bluetooth design and is designed
for reliable and trouble-free performance.
PACKAGE CONTENTS
• Bluetooth plug-in wall speaker
• Quick Setup Guide
FIND YOUR USER GUIDE ONLINE!
We are going green so a copy of your User Guide
is not provided in the box but is available online.
Go to www.insigniaproducts.com, then click
Support & Service.
Enter your model number in the box under
Manual, Firmware, Drivers & Product
Information, then click ►.
Before using your new product, please read these instructions to prevent any damage.
FEATURES
• Bluetooth connectability
• Built-in power adapter
• Built-in rechargeable battery
# ITEM DESCRIPTION
1 / (Power/Pair) • Press and hold for three seconds to turn this system on. Press and
button release to turn it o .
• Press and hold for two seconds to put this system into pairing mode.
2 Volume+/– buttons Press to increase or decrease the volume level of playback.
3 Battery/pairing indicator • Indicates the battery charging status.
• Indicates the pairing states.
4 AC power plugs (foldable) Fold down, then plug into a wall outlet to charge your speaker.
5 AUX IN jack Plug an external audio device into this jack to hear the playback
from this speaker.
6 USB charge port Connect an external device to this port to charge it.
Quick Setup Guide |
Bluetooth Plug-In Wall Speaker
CHARGING THE BATTERY
• This system has a built-in rechargeable battery. To charge, fold down the
AC power plug as shown below, then gently insert it into a wall outlet.
90°
Right view
• The battery indicator
indicates the charging state.
Top view
MODE CHARGING
Standby Solid red
Power on (not connected) Lights alternately red and purple
Bluetooth mode Solid purple
AUX IN mode Lights alternately red and purple
NS-SPBTP1-W
Wall outlet
FULLY CHARGED
O
Blinking blue
Solid blue
Blinking blue
