Insignia NS-SPBTBRICK Quick Setup Manual

PACKAGE CONTENTS
• Bluetooth speaker
• USB cable
• Quick Setup Guide
FEATURES
• Wirelessly stream from any Bluetooth device
• Rechargeable battery lasts up to 30 hours
• Integrated power bank charges your mobile devices
• Water-resistant body
Play/pause/phone
Top view
Next Volume down
Previous Volume up
Bluetooth pairing
Microphone
LED indicator
Back view
Charging indicator Micro USB charging port
ON/OFF/000
switch DC OUT AUX IN jack
Before using your new product, please read these instructions to prevent any damage.
SAFETY INSTRUCTIONS
• Never expose the product to fire as this could result in personal injury.
• Do not store the product in an extremely cold or warm environment.
• Never dismantle the product.
• Never let children play with the product.
• Do not expose the product to dampness or moisture.
• The product should not be exposed to dripping or splashing.
CHARGING YOUR SPEAKER
1 Connect the small end of the charging cable to the micro USB port on
the back of your speaker.
2 Connect the other end to a USB port on your computer.
Note: When the battery is low, you will hear beeps. About five minutes later, the
speaker will power off automatically.
CHARGING INDICATOR DESCRIPTION
Solid red Charging
Off Fully charged
TURNING YOUR SPEAKER ON AND OFF
• Slide the ON/OFF to ON. The LED indicator blinks quickly and the
speaker enters pairing mode.
CHARGING AN EXTERNAL DEVICE
1 Open the port cover on the back of the speaker.
2 Plug one end of a USB cable into your external device and the other
end into the DC OUT port on the speaker.
3 Switch the ON/OFF switch to . Your external device is being
charged.
CONNECTING WITH BLUETOOTH
1 Make sure that your Bluetooth device is turned on and within 33 feet
(10 meters) of your speaker.
2 On your speaker, press and hold the button. Your speaker enters
pairing mode, and the LED on your speaker blinks. Your speaker
remains in pairing mode until it pairs with a Bluetooth device.
Note: Press and hold the button to return to pairing mode.
3 Turn on your Bluetooth device and turn on Bluetooth. Set your device
to pairing mode, then select NS-SPBTBRICK. See the instructions that
came with your Bluetooth device for information about pairing.
4 If you are asked for a password, enter 0000. When pairing is
complete, the LED on your speaker lights solid blue.
5 To disconnect from the paired Bluetooth device, press and hold the
button on your speaker for three seconds. You will hear a beep. Your
speaker disconnects from the Bluetooth device and enters pairing
mode again.
LED DESCRIPTION
Blinks blue Speaker is in pairing mode
Solid blue Speaker is paired OR an AUX device is connected
Quick Setup Guide |
NS‐SPBTBRICK
Bluetooth Stereo Speaker with Powerbank
RECONNECTING TO A PAIRED DEVICE
When your speaker is not paired to a device, the LED blinks blue.
Your speaker loses the
Bluetooth connection if you... To reconnect...
Turn off your speaker. Turn on your speaker. Your speaker searches
for the last connected Bluetooth device and
reconnects.
Move the Bluetooth device out Make sure that your Bluetooth device is
of range. within 33 feet of your speaker.
Turn off your Bluetooth device. Turn on your Bluetooth device, then make
sure that Bluetooth is on.
Turn off Bluetooth on your Turn on Bluetooth on your Bluetooth device.
Bluetooth device.
Connect your Bluetooth device Disconnect your Bluetooth device from the
to another Bluetooth device. other Bluetooth device, then set your device
to pairing mode. Select NS-SPBTBRICK on
your Bluetooth device.
Notes:
• If a device does not automatically reconnect, you may need to reselect
NS-SPBTBRICK on your Bluetooth device.
• If you move your device out of range, it will remain paired for 10 minutes, but
no sound will come from the speaker until you come back within range. After
10 minutes, the speaker will reenter pairing mode.
LISTENING TO MUSIC
1 Slide the ON/OFF switch to ON, then connect to your Bluetooth
device.
2 Begin playback on your Bluetooth device.
3 Adjust the volume on your speaker by pressing the + or - buttons.
Note: Press the to start playback. Press the and
next or previous track.
to go to the
