  • Page 1 I –9401 Addressable Sounder Strobe C-9401 Sounder Strobe Installation and Operation Manual (Issue 3.02, August 2012)
  • Page 2 I-9401 Addressable Sounder Strobe C-9401 Sounder Strobe Installation and Operation Manual CONTENTS General ........................1 Features ........................1 Technical Specifications................... 1 Structure and Operation Principle ................2 Mounting and Wiring ....................2 Testing ........................4 VII Applications ......................4...
  • Page 3 GST produces two types of sounder strobe, addressable (I-9401) and conventional (C-9401). Addressable sounder strobe can be started directly by fire alarm controller. It can be electronically programmed and modified by P-9910 Hand Held Programmer in field. Conventional sounder strobe can give optical and visual alarm when powered by DC24V, and can be connected to fire alarm controller through an addressable linkage control module.
  • Page 4 I-9401 Addressable Sounder Strobe C-9401 Sounder Strobe Installation and Operation Manual Addressable: Four wires, non-polarized, two-loop to the controller, non-polarized two-wire to the power. Conventional: Non-polarized two-wire with the power. Operating Environment: Temperature: -10℃~+50℃; Relative Humidity≤95%, no condensation; Dimension: 144mm×90mm×57mm;...
  • Page 5 Fig. 3 I-9401 Base box Terminals: D1, D2: Connecting DC24V power, non-polarized; Z1, Z2: Connecting signal loop of the controller, non-polarized; S1, G: Externally controlled passive input. The base box of C-9401 is shown in Fig. 4, please note direction when installing. Page 3...
  • Page 6 C-9401 Sounder Strobe Installation and Operation Manual Mounting Hole Mounting Hole Fig. 4 C-9401 Base box D1, D2: Startup power DC24V; D1 is positive, D2 is negative. Wiring: Twisted pair for signal loop Z1 and Z2, cross section≥1.0mm ; 227IEC01 wire for power supply D1and D2, cross section≥1.5mm...
  • Page 7 I-9401 Addressable Sounder Strobe C-9401 Sounder Strobe Installation and Operation Manual +24V 5 Wiring of signal bus and power bus for intelligent sounder strobe and direct control through passive normally open contact of manual call point Conventional sounder strobe connects DC24V power in direct startup; D1 is positive and D2 is negative which are reverse when not started up.
  • Page 8 Gulf Security Technology Co., Ltd. No. 80, Changjiang East Road, QETDZ, Qinhuangdao, Hebei, P. R. China 066004 Tel: +86 (0) 335 8502434 Fax: +86 (0) 335 8502532 service.gst@fs.utc.com www.gst.com.cn 30301519...
