Page 2: Table Of Contents
DI-9204Exd Digital Flame-proof Manual Call Point Installation and Operation Manual The Intelligent Solution CONTENTS 1 General........................1 2 Features ........................1 3 Technical Specifications ................... 1 4 Construction and Operation Principle..............2 4.1 Exterior View ......................2 4.2 Operation Principle....................2 5 Installation and Wiring ....................2 5.1 Wall-mounting .......................2... -
Page 3: General
(FACP). The MCP can work at addressable mode to connect with GST’ s series FACP that can control fire suppression devices and transmit signal through loop. It can also work at non-addressable mode to connect with 24VDC power and output fire alarm signal through key switch. -
Page 4: Construction And Operation Principle
DI-9204Exd Digital Flame-proof Manual Call Point Installation and Operation Manual The Intelligent Solution 4 Construction and Operation Principle 4.1 Exterior View The exterior view of the MCP is shown in Fig. 1. Cover Base DO NOT OPEN WHEN AN EXPLOSIVE... - Page 5 DI-9204Exd Digital Flame-proof Manual Call Point Installation and Operation Manual The Intelligent Solution 5.1.1 Installation of Base and Mounting Plate The MCP consists of a base and an enclosure. Before installation, unfasten the four screws and remove the enclosure from the base with care.
-
Page 6: Pole-Mounting
DI-9204Exd Digital Flame-proof Manual Call Point Installation and Operation Manual The Intelligent Solution Gland body 1. Grommet 2.Armored Cable 3. Entrance Interface 4. Middle Sheath 5. Taper Washer 6. Outer Washer 7. Grommet 8. Nut 9. Flame-proof Washer 10.Sealing Filler Fig. -
Page 7: Testing
DI-9204Exd Digital Flame-proof Manual Call Point Installation and Operation Manual The Intelligent Solution M5×10 Hexagon Socket M4 × 10 Countersunk Head Screw Screw Assembly Rubber Washer Cable Fig. 6 Unit: mm Fig. 7 6 Testing Warning: Power up only after all the devices are well connected. -
Page 8: Operation
7 Operation (1) If the MCP works in addressable mode, it needs to be programmed with an address ranging from 1 to 242 using GST handheld programmer. Please refer to the installation and operation manual of the programmer. (2) Please reset the MCP if the fire alarm is cleared. -
Page 9: Application In Supervised Digital Input (Sdi) Loop
DI-9204Exd Digital Flame-proof Manual Call Point Installation and Operation Manual The Intelligent Solution 8.3 Application in Supervised Digital Input (SDI) Loop The MCP can also be used in SDI loop, as in Fig. 10, in which the 2.5k resistor is connected between Z1 and Z2, and the 1k resistor is connected between K2 and Z1. - Page 10 GST China Gulf Security Technology Co., Ltd. No. 80, Changjiang East Road, QETDZ, Qinhuangdao, Hebei, P. R. China 066004 Tel: +86 (0) 335 8502528 Fax: +86 (0) 335 8508942 Email: sales@gst.com.cn www.gst.com.cn GST UK Global System Technology PLC Lion Court, Staunton Harold Hall,...
