INSTRUCTION MANUAL
& REFERENCE GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cobra Te and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Serpent Cobra Te

Summary of Contents for Serpent Cobra Te

  • Page 1 INSTRUCTION MANUAL & REFERENCE GUIDE...

  • Page 2: Table Of Contents

    The exploded views and parts lists for the The Serpent Cobra E-truggy is based on the Serpent Cobra are included in the back of this successfull Cobra offroad platform. It is designed manual. The exploded views show all the parts of...
  • Page 3 5HDG WKLV ¿UVW this car on public roads, crowded places or near infants. - Before operating this car, always check the mechanical status of the car. Also check that the transmitter and - This is a highly technical hobby product, intended to be used receiver frequencies correspond and are not used by in a safe racing environment.

  • Page 4: Differential Center Assembly

    DIFFERENTIAL CENTER ASSEMBLY STEP Use some grease during assembly CENTER 8x16x5 DIFF Add 2mm oil before assembling the gear 8x16x5 Use silicone oil to hold seal in position Use some grease during assembly M3x12 Silicone oil fill just over gear shaft. Check default SET-UP sheet for CST...

  • Page 5: Differentail Fr/Rr Assembly

    DIFFERENTIAL FRONT/REAR ASSEMBLY STEP Use some grease during assembly FR/RR 8x14x4 DIFF Flanged Add 2mm oil before assembling the gear Use some grease Use silicone oil during assembly to hold seal in position 8x14x4 Flanged M3x12 Silicone oil fill just over gear shaft.

  • Page 6: Center Assembly

    CENTER ASSEMBLY STEP M4X10 STEP M3X8 Page...

  • Page 7: Rear Assembly

    REAR ASSEMBLY M5X4 STEP 13x19x4 8x9x16 8x11x0.2 2.5X13 8x11x0.1 STEP Nylock nut M3 2.5X5 WIDE THREAD Use 14x15.6x0.2 shims to adjust proper gear mesh (shims included in the diff bag). Notice orientation of the diff. M3X18 STEP M3X14 M3X16 Page...
  • Page 8 STEP M4x12 Special M3x40 Proper insert orientation in the REAR bracket, Proper insert orientation in the FRONT left and right equal type bracket, left and right equal type STEP Nylock nut M3 Nylock nut M3 M3x18 M3x18 M3x20 M3x25 M3x18 M3x20 Page...
  • Page 9 STEP M3x12 Flanged M3x6 56.5mm 11.1 STEP 8x16x5 Move clips over pin 2.5x15 after assembling 15x21x4 2.5x17 M3x4 M5x4 11.2 Nylock nut M3 M3x22 Nylock nut M3 Page...
  • Page 10 STEP M3x3 M3x3 M3x3 M3x3 Use threadlock on these screws 35mm STEP M4x12 Page...

  • Page 11: Front Assembly

    FRONT ASSEMBLY STEP M5x4 8x11x0.2 13x19x4 8x19x6 8x11x0.1 2.5x13 STEP Use 14x15.6x0.2 shims to adjust proper gear mesh (shims included 2.5x5 in the diff bag). Notice WIDE THREAD orientation of the diff. STEP Nylock nut M3 M3x18 M3x20 M3x16 Cilinder Head M3x14 STEP...
  • Page 12 STEP M4x12 Special M3x16 Proper insert orientation Proper insert orientation in the rear bracket in the front bracket STEP M3x12 Flanged 61.5mm Page...
  • Page 13 STEP 15x21x4 2.5x15 8x16x5 M3x4 2.5x17 M5x4 Move clips over pin after assembling STEP NOTE: C-hubs show L or R indication M3x6 M3x6 Left hand side Page...
  • Page 14 STEP M3x22 Nylock nut M3 M4x18 SPECIAL STEP M3x3 M3x3 M3x3 M3x3 Use threadlock on these screws 35mm Page...

  • Page 15: Steering Assembly

    STEP M4x14 M4x12 STEERING ASSEMBLY STEP M4x10 M4x10 M4x10 Page...
  • Page 16 STEP Nylock nut M3 M3x18 M3x18 STEP M3x18 M3x18 64.5mm STEP 6x10x3 6x10x3 6x10x3 Nylock M3 Nylock M3 Page...
  • Page 17 STEP M3x16 M3x10 M3x10 STEP Nylock nut M3 M3x12 Nylock nut M3 M3x12 Page...

  • Page 18: Side-Guard/Radio Assembly

    SIDE-GUARD / RADIO ASSEMBLY STEP M3x3 STEP M3x8 M4x10 M4x10 M3x8 M3x8 M3x8 M4x10 M4x10 Page...
  • Page 19 32.1 32.2 STEP M2x10 M2x10 M3x16 M3x3 INCLUDED INCLUDED Use enough servo-spacers M3x16 to allow servolever to clear radiobox by 0.5 to 1.0 mm (see step 32.3) INCLUDED 32.3 Tip: Use double sided tape to mount the ESC and Transponder. NOT INCLUDED M3x12 Tip: Note orientation of...

  • Page 20: Shocks Assembly

    SHOCK ASSEMBLY Use threadlock 35.1 STEP Nut M3 35.2 Apply silcione oil to assemble the o-rings 35.3 Apply silcione oil to assemble the shockshaft 35.4 Apply silcione oil to mount the nut 35.5 REAR FRONT shock shock 35.6 124mm 113.5mm Page...
  • Page 21 35.7 Push membrane into the shock top 35.8 - Fill up with sillicone oil - Wait for air bubbles to escape - Close top only 3/4 - Check default SET-UP sheet for CST value of silicone oil 35.9 Page...

  • Page 22: Shock Mounting

    SHOCK MOUNTING STEP M3x8 M3x8 M3x3 NOTE: SHOKS SHOWN WITHOUT SHOCKS BOOTS M3x3 NOTE: SHOKS SHOWN WITHOUT STEP SHOCKS BOOTS M3x8 M3x8 M3x3 Page M3x3...

  • Page 23: Final Assembly

    FINAL ASSEMBLY STEP M4x10 INCLUDED M4x4 M4x10 M3x15 STEP Nylock nut M3 Page...
  • Page 24 ¿W 6DPH IRU WKH ERG\ PRXQWLQJ holes.  5HPRYH WKH ERG\ SURWHFWLRQ ¿OP on the outside of the body. 4) Apply the provided Serpent and Cobra decals, and mount the body on the bodyposts, with the provided bodyclips. WHEELS AND...

  • Page 25: Reference Guide

    REF GUIDE: EXPLODED VIEWS and PARTS-LIST Contents DIFFERENTAL ASSEMBLIES TRANSMISSION CENTER REAR ASSEMBLY FRONT ASSEMBLY STEERING ASSEMBLY RADIO ASSEMBLY SHOCK ASSEMBLY FINAL ASSEMBLY I PARTS-LIST Page...

  • Page 26: Differental Assemblies

    DIFFERENTIAL ASSEMBLIES 1396 600627 CENTER 600421 110127 600376 600627 600210 600425 1396 600410 600210 600421 600376 Complete FR/RR Diff 600323 600627 Complete CENTER Diff 50T 600375 600627 Complete DIFF UNI 600325 600421 600200 FRONT REAR 600696 1349 600200 600425 600421 1349 TRANSMISSION CENTER 110109...

  • Page 27: Rear Assembly

    REAR ASSEMBLY Page...

  • Page 28: Front Assembly

    FRONT ASSEMBLY Page...

  • Page 29: Steering Assembly

    STEERING ASSEMBLY 110104 110127 110158 110104 600153 600334 600182 600173 1321 110402 110402 600672 1321 600128 600191 600178 600170 600131 110402 600128 1321 600178 600128 600199 600412 600167 600330 600109 600131 600169 600191 600412 110140 600131 600191 600191 600131 600178 110127 110140 RADIO ASSEMBLY...

  • Page 30: Shock Assembly

    SHOCK ASSEMBLY 600159 600111 600158 600160 Front 600387 Rear 600234 600145 600112 600235 110407 600393 Front 600112 600394 Rear 600118 600180 SHOCK SPRINGS 600252 Spring set RR pink 2.8lbs (2) 600253 Spring set RR blue 3.0lbs (2) 600254 Spring set RR purple 3.2lbs (2) 600255 Spring set RR green 3.4lbs (2) 600256 Spring set RR grey 3.6lbs (2) 600257 Spring set RR yellow 3.8lbs (2)

  • Page 31: Parts Lists

    PARTS-LIST 'HVFULSWLRQ 600394 Shockshaft RR Truggy (2) 600035 Serpent 811 Cobra-T Truggy 1/8 4wd TE 6KRFN $EVRUEHUV RSWLRQ Decals 600282 Shock bushing delrin (4) 1887 Decal Serpent black/white 1/8 (2) 600287 Shock spring support alu (4) 1889 Decal Serpent chrome 1/8 (2)
  • Page 32 600373 C-Hub Truggy 12 L+R 600132 Suspension bracket inserts (30) 600379 Driveshaft Truggy (2) 600133 Wing mount set 600381 Gear coupler rubber boot (2) 600155 Suspension bracket RR RR 3 600382 Hex adaptor clip (2) 600156 Suspension bracket RR FR 2 600396 Shocktower Truggy front carbon 600168...
  • Page 33 600209 Diff pin 10T (2) 190512 Allen wrench 3.0 x 120mm 600210 Diff pin outdrive (2) 190513 Ball driver hex wrench 2.0 x 120mm 600213 Shim 6x11.75x0.2 (10) 190514 Ball driver hex wrench 2.5 x 120mm 600214 Shim 3.5x12x0.2 (10) 190515 Ball driver hex wrench 3.0 x 120mm 600215...
  • Page 34 Hoody sweater Serpent black-zip (XL) 190205 Hoody sweater Serpent black-zip (2XL) 190206 Hoody sweater Serpent black-zip (3XL) 190207 Hoody sweater Serpent black-zip (4XL) ) 190215 T-shirt Serpent WC edition black (S) 190216 T-shirt Serpent WC edition black (M) 190217 T-shirt Serpent WC edition black (L)
  • Page 35 NEWS / NOTES Page...
