Installation and Operation Manual
HPA-2
Dual Input Headphone Amplifier
Manual Update: 08/21/08
Due to the dynamic nature of product design, the information contained in this
document is subject to change without notice. Broadcast Tools, Inc., assumes no
responsibility for errors and/or omissions contained in this document. Revisions
of this information or new editions may be issued to incorporate such changes.
Broadcast Tools® is a registered trademark of Broadcast Tools, Inc.
Copyright, 1989 - 2008 by Broadcast Tools, Inc. All rights reserved.
No part of this document may be reproduced or distributed without permission.
Visit www.broadcasttools.com for important product update information.
Advertisement
Table of Contents
Related Manuals for Broadcast Tools HPA-2
Summary of Contents for Broadcast Tools HPA-2
-
Page 1: Installation And Operation Manual
Manual Update: 08/21/08 Due to the dynamic nature of product design, the information contained in this document is subject to change without notice. Broadcast Tools, Inc., assumes no responsibility for errors and/or omissions contained in this document. Revisions of this information or new editions may be issued to incorporate such changes. -
Page 2: Safety Information
HPA-2 Installation and Operation Manual INTRODUCTION CAUTION! Thank you for your purchase of the Broadcast Tools, Inc., HPA-2, Dual input head- phone amplifier. We’re confident this product will give you many years of depend- Broadcast Tools® able service. This manual is intended to give you all the information needed to install Products, as with any and operate the unit. -
Page 3: Product Description
NOTE: If the source feeding the HPA-2 is unbalanced, install a jumper between L- or R- terminal and G (ground). When installation is completed, plug the supplied 12vac wall transformer into the rear panel power plug labeled “12VAC”. The front panel “PWR” led should be illuminated. -
Page 4: Specifications
Power 12 volt AC only. 12vac@500ma transformer supplied. Mechanical 3.70” x 1.55” x 3.50” (WHD) / Weight: 1.0 lbs NOTE: Mechanical drawings for the HPA-2 mounting plates are available for download from the Broadcast Tools® web site. SPECIFICATIONS e-mail: voice: fax: support@broadcasttools.com... - Page 5 If Broadcast Tools is notified, in writing, of a failure of any item manufactured by Broadcast Tools to conform to the foregoing Limited Warranty within one (1) year following the date of the Buyer’s acquisition of the item, and if the item is returned to Broadcast Tools in accordance with Broadcast Tools’...
