Installation and Operation Manual
Eight-output, two-input AES/EBU Digital Audio Distribution
Amplifier with StudioHub+ RJ45 Connectors
If you need a firmware upgrade, contact Broadcast Tools®
No part of this document may be reproduced or distributed without permission.
ALL SPECIFICATIONS AND FEATURES FOR THIS PRODUCT ARE SUBJECT TO
NOTE: We recommend the use of Chrome, Firefox or Safari as your browser.
Due to the dynamic nature of product design, the information contained in this
document is subject to change without notice. Broadcast Tools, Inc., assumes no
responsibility for errors and/or omissions contained in this document. Revisions
of this information or new editions may be issued to incorporate such changes.
Broadcast Tools® is a registered trademark of Broadcast Tools, Inc.
All Sentinel® labeled products are registered trademarks of Broadcast Tools, Inc.
Copyright® 1989 - 2016 by Broadcast Tools, Inc. All rights reserved.
No part of this document may be reproduced or distributed without permission.
Visit www.broadcasttools.com for important product update information.
AES DA 2x4
Manual update: 4/12/2015
CHANGE WITHOUT NOTICE
®
Advertisement
Table of Contents
Related Manuals for Broadcast Tools AES DA 2x4
Summary of Contents for Broadcast Tools AES DA 2x4
- Page 1 NOTE: We recommend the use of Chrome, Firefox or Safari as your browser. Due to the dynamic nature of product design, the information contained in this document is subject to change without notice. Broadcast Tools, Inc., assumes no responsibility for errors and/or omissions contained in this document. Revisions of this information or new editions may be issued to incorporate such changes.
-
Page 2: Table Of Contents
AES DA 2x4 Installation and Operation Manual Table of Contents Section Title ........Page # Introduction . -
Page 3: Introduction
AES DA 2x4 Installation and Operation Manual INTRODUCTION CAUTION! Thank you for your purchase of a BROADCAST TOOLS® AES DA 2X4 is a professional quality AES/EBU digital audio distribution amplifier. We’re confident Broadcast Tools® that this product will give you many years of dependable service. This manual is... -
Page 4: Product Overview
If any damage is present, please notify the shipper imme- diately and retain the packaging for inspection by the shipper. The package should contain the AES DA 2X4, and a 9 VDC wall power supply with domestic connec- tor. Manuals may be downloaded from our web site. -
Page 5: Installation/Operation
UPS Standby Power System We recommend that you connect your AES DA 2X4 to a UPS system. A UPS helps minimize the risk to the AES DA 2X4 and provides power during a power outage. -
Page 6: Aes/Ebu Outputs
AES DA 2x4 Installation and Operation Manual AES/EBU Outputs The AES DA 2x4 has eight transformer isolated 110-ohm AES/EBU outputs with StudioHub+ RJ45 jacks, labelled “1-4” and “5-8”. Connect the inputs of your AES/EBU compatible devices to the AES output jacks. -
Page 7: Aes/Ebu Activity Detectors/Alarm Relays
Red inactivity LED will light, its Green activi- ty LED will extinguish, and its Alarm Relay will close. The AES DA 2x4 has two SPDT alarm relays, one labeled “K1” for Input One and one labelled “K2” for Input Two. Connections should be made to the three-position plugin euro-block’s NO (normally open), CM (common) and NC (normally closed) -
Page 8: Specifications
AES DA 2x4 Installation and Operation Manual SPECIFICATIONS Digital Inputs: Two transformer isolated AES/EBU inputs (110-ohm) with StudioHub+ compatible RJ45 jacks. Digital Outputs: Eight transformer isolated AES/EBU outputs with StudioHub+ compatible RJ45 jacks. 110-ohm impedance. Switch selectable 1x8 or 2x4 configuration. -
Page 9: Warranty
If Broadcast Tools is notified, in writing, of a failure of any item manufactured by Broadcast Tools to conform to the foregoing Limited Warranty within one (1) year following the date of the Buyer’s acquisition of the item, and if the item is returned to Broadcast Tools in accordance with Broadcast Tools’... - Page 10 Product_Name Installation and Operation Manual APPENDIX e-mail: voice: fax: support@broadcasttools.com 360.854.9559 866.783.1742...
- Page 11 Product_Name Installation and Operation Manual APPENDIX e-mail: voice: fax: support@broadcasttools.com 360.854.9559 866.783.1742...
- Page 12 Product_Name Installation and Operation Manual APPENDIX e-mail: voice: fax: support@broadcasttools.com 360.854.9559 866.783.1742...
