English version
Introduction
First of all, many thanks for purchasing this Sweex Bluetooth Adapter. By means of this adapter you can easily make a Bluetooth connection
between your computer and other Bluetooth devices, such as e.g. a telephone or printer.
To ensure this product operates correctly, we advise you to carefully read this manual first. If despite this manual you still experience problems
during installation or operation of this product, go to sweex.com and look under the heading service & support.
Contents of the box
Prior to installation, check if all required parts are present. The following parts must be present in the box:
• S weex Bluetooth adapter
• C D-ROM with manual and driver
If one of the above parts is missing, please contact the supplier.
Specifications BT100
• B luetooth Class II USB Adapter
• B luetooth 1.2, Class II
• M aximum range Bluetooth connection: 10 metres
• M aximum data speed: 723 Kbps
• I nterface: USB 1.1
• S upports: Windows 98SE, 2000 and XP
Additional specifications BT100
• P ower consumption: 30 mA
• F requency area: 2.400 GHz ~ 2.480 GHz ISM Band
• S ensitivity: -80 dBm
• O utput voltage: 5V
• O perating temperature: -10 ~55 ºC
• D imensions: 45 x 22 x 8.5 mm (l x h x w)
• W eight: < 8g

BT100 - Sweex Bluetooth Class II Adapter USB
BT110 - Sweex Bluetooth Class I Adapter USB
S W E E X . C O M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT100 and is the answer not in the manual?

Questions and answers

Summary of Contents for SWEEX BT100

  • Page 1 English version BT100 - Sweex Bluetooth Class II Adapter USB BT110 - Sweex Bluetooth Class I Adapter USB Introduction First of all, many thanks for purchasing this Sweex Bluetooth Adapter. By means of this adapter you can easily make a Bluetooth connection between your computer and other Bluetooth devices, such as e.g. a telephone or printer. To ensure this product operates correctly, we advise you to carefully read this manual first. If despite this manual you still experience problems during installation or operation of this product, go to sweex.com and look under the heading service & support. Contents of the box Prior to installation, check if all required parts are present. The following parts must be present in the box: • S weex Bluetooth adapter • C D-ROM with manual and driver If one of the above parts is missing, please contact the supplier. Specifications BT100 • B luetooth Class II USB Adapter • B luetooth 1.2, Class II • M aximum range Bluetooth connection: 10 metres • M aximum data speed: 723 Kbps • I nterface: USB 1.1 • S upports: Windows 98SE, 2000 and XP Additional specifications BT100 • P ower consumption: 30 mA • F requency area: 2.400 GHz ~ 2.480 GHz ISM Band...
  • Page 2 English version Specifications BT110 • B luetooth Class I USB Adapter • B luetooth 1.2, Class I • M aximum range Bluetooth connection: 100 metres • M aximum data speed: 723 Kbps • I nterface: USB 1.1 • S upports: Windows 98SE, 2000 and XP Additional specifications BT110 • P ower consumption: 30 mA • F requency area: 2.400GHz ~ 2.480 GHz ISM Band • S ensitivity: -80 dBm • O utput voltage: 5V • O perating temperature: -10 ~55 ºC • D imensions: 45 x 22 x 8.5 mm (l x h x w) • W eight: < 8g System requirements • A free USB port • A 500 MHz processor (minimum)
  • Page 3 English version Installing the driver Start up the computer and wait until it has completely finished loading and starting the programmes. Insert the CD-ROM supplied in the CD-ROM player. The installer will start automatically. Select option “Install Driver” to install the driver on your computer. Subsequently, click “Next”/“OK” until the installation is complete. Adding a Bluetooth device After having installed the Bluetooth adapter, a ‘B’ icon appears on the right-hand side of the taskbar. Right-click here - the following menu appears: Select the first option; “Add a Bluetooth device” The following screen appears: Tick the option “My device is set up and ready to be found”. In the case of a mobile phone, ensure that Bluetooth is activated and that the telephone can be detected. The manual of the relevant device describes how to activate this. Then click on “Next”. S W E E X . C O M...
  • Page 4 English version An overview appears, listing the devices found: Select the device that you want to add. Then click on “Next”. The following screen appears. Here you can add a password to connect your device. In this example we have chosen “0000” (however, you can also choose another password). Then click on “Next”. Windows now tries to connect the adapter to the telephone: During the connecting process the telephone will request confirmation. The password must be entered also. The correct procedure depends on the brand name and type of telephone. To this end, we refer you to the manual of the relevant telephone.
  • Page 5 English version Sending a file Here select the option “Send a file”. The adapter will now search for Bluetooth devices within its range: Select the device that you want to send a file to. To this end, we have selected the mobile phone which was already connected to the adapter. If you choose another device, you can enter a password. We recommend using a password to increase security during file transfers. Then click on “Next”. Now select the file that you want to send and click on “Next”. S W E E X . C O M...
  • Page 6 English version The file has been sent successfully. Receiving a file Prior to being able to receive a file, you must ensure that the adapter can be detected. You can do so as follows: Select the option “Open Bluetooth Settings”. Click on the second tab and the following appears: Here tick the option “Turn discovery on”. The adapter can now be detected by other Bluetooth devices.
  • Page 7 English version Here select the option “Receive a file”. The adapter is now waiting for a device to connect. The adapter has received and accepted the file. You can choose how to name the file and where to store it. The file transfer has been completed successfully. S W E E X . C O M...
  • Page 8 English version Warranty Any products under the Sweex brand are warranted for a period of three years. We do not grant support or warranties for any software and/or (rechargeable) batteries included. Warranty claims are only settled via the dealer where the product concerned was purchased. The rightful owner has and retains title to all brand names and related rights mentioned in this manual.
