SWEEX LC086 Manual

Powerline ethernet adapter 85 mbps

English version

Introduction

• Do not expose the Sweex Powerline Ethernet Adapter 85 Mbps to extreme temperatures. Do not place the product in direct sun

light or close to heating elements.

• Do not use the Sweex Powerline Ethernet Adapter 85 Mbps in extremely dusty or moist environments.

• Prevent hard shocks or impacts of the product, as this can cause damage to the internal electronics.

• Never try to open the product yourself, this voids the warranty.

Important!

Do not connect the Sweex Powerline Ethernet Adapter 85 Mbps to a UPS or a socket with surge protection and/or filter. This can

negatively influence the quality of the signal.

Prior to installing the hardware, follow these precautionary instructions:

• Ensure that there is at least 1 free plug socket available for every adapter.

• Place the adapter in the plug socket.

• Place the second and possibly third (etc.) adapter in a different plug socket.

• Connect the adapter with the network and/or the computer by means of the network cables. There are 3 connection possibilities:

1: From /switch to PC (see image underneath)

LC086 Sweex Powerline Ethernet Adapter 85 Mbps

Table of Contents

Do you have a question about the LC086 and is the answer not in the manual?

Page 1 • Never try to open the product yourself, this voids the warranty. Important! Do not connect the Sweex Powerline Ethernet Adapter 85 Mbps to a UPS or a socket with surge protection and/or filter. This can negatively influence the quality of the signal.
Page 2 No drivers are needed for the Sweex Powerline Ethernet Adapter. The utility that will be installed ensures extra functionality and security. If you do not need this you do not have to install the software. Without software you can immediately use the Sweex Powerline Ethernet Adapter.
Page 3 Select the device you want to configure and click “Enter Password”. The following screen appears: Enter the password that is on the adapter. Pay attention that the MAC address of the adapter is the same as the MAC address in...
Page 4 Applying the security is done in the second tab. Here you can give a unique network name (default is “HomePlug”). This network name is also the password to connect to the Powerline network. After entering a network name you have to click on “Set All Devices”.
