ENglISH VErSIoN
Important!
• Do not expose the Powerline Adapter to extreme temperatures. Do not place the device in direct sunlight or in the direct vicinity of heating
elements.
• Do not use the Powerline Adapter in extremely moist or dusty surroundings.
• Protect the device against powerful shocks and falls - they may damage the internal electronics.
• Never attempt to open the device yourself, there are no serviceable parts inside. Opening the device will cause the warranty to lapse.

Package contents

In this package you will find:
• Powerline Adapter
• Network cable
• CD with software and manual
Note: For Powerline kits, one network cable should be included for each adapter, in the same colour as the adapter.
If you find that any of the package contents are missing, please return the package to the sales point where it was bought.
Terminology list
This manual will contain a number of technical terms. It is important to know what they mean before you begin
installing and configuring the router.
• Router A router is a network device required for sharing an Internet connection between multiple devices, such as computers but also other
devices such as a network printer, internet-enabled Blu-Ray player or network storage device / NAS. If you wish to use powerline adapters to
connect more than one device to the Internet, a router is also required.
• Network cable A network cable is used for connecting network devices such as computers, modems and routers to the powerline adapter or to
eachother.
• Powerline adapter This is the product you have just bought.
• Powerline security By default, your powerline network is not secured. This means that it is possible that others in the same building or buildings
nearby can use a powerline adapter to gain access to your network. Powerline security protects your network so that only authorized adapters
can gain access. Sweex recommends all users to secure their powerline network after installation. For more information please see the "Securing
your powerline network" section of this manual.
2
Powerline Adapter
