FOR YOUR SAFETY - PLEASE READ THESE WARNINGS FIRST! .................... 2

Customer Service Information ................................................................. 3
Introduction ..................................................................................................... 3
Popular Option Parts .................................................................................... 3
Recommended Tools And Supplies ........................................................... 4
Becoming Familiar With Your X-Terminator 2 Rtr Nitro Buggy .... 5
Tips From The Pros .......................................................................................... 7
Preparing To Run Your X-Terminator 2 Rtr Nitro Buggy ................ 7
Becoming Familiar With The Xtm Racing 24.7 Nitro Engine ..............11
Fueling And Starting The Xtm Racing 24.7 Nitro Engine ................. 13
Breaking In The Xtm Racing 24.7 Nitro Engine ..................................... 14
For your saFety - pLease reaD tHese Warnings First!
engine Warnings
Never use any fuel in your engine other than glow fuels
●
specifically designed for use in model car engines. Use of any
other types of fuel can cause severe damage to your engine
and/or personal injury. NEVER USE GASOlINE/PETROl
OR dIESEl fUEl!
Never operate your model on any public streets. This could
●
cause traffic accidents, personal injury or property damage.
Glow fuel engines emit exhaust vapors that are poisonous
●
and can be dangerous to your health. It is important that you
operate your engine in a very well-ventilated area, preferably
outdoors.
Before starting your engine, make sure that the throttle trim
●
is set to the idle position. Starting your engine at any setting
above idle can cause the model to lurch out of your hands.
When your engine is running, there are certain parts that
●
rotate at high speeds. Be careful not to touch the drive shafts,
gears, clutch assembly or any other moving parts. Otherwise,
serious injury could result.
It is normal for your engine and tuned pipe to get very hot
●
during operation. Never touch these parts while they are hot
or you could be burned.
Model engines produce vibration when they are running. It
●
is important to periodically check the engine mounting screws
and other assemblies to ensure they are tight. Running your
engine with the engine mounting screws loose can lead to severe
engine and/or chassis damage.

tabLe oF Contents

Basic Engine Maintenance .......................................................................... 17
Installing The Body....................................................................................... 17
Chassis Tuning Guide .................................................................................... 17
Maintaining Your X-Terminator 2 Rtr Nitro Buggy .......................... 22
Troubleshooting Guide .............................................................................. 23
Assembly Manual And Replacement Parts List .................................. 24
Replacement Parts List .............................................................................. 52
Option Parts List............................................................................................ 61
Important Warranty Service Information .......................BACK COVER
Warranty Information .............................................................BACK COVER
Visit us on the web at
www.teaMXtM.CoM
Glow fuels like those used in your model engine are
●
poisonous. Follow all the precautions that are printed on the
fuel manufacturer's container.
Keep glow fuel out of the reach of children.
●
Glow fuel is extremely flammable. Keep away from high heat,
●
sparks and flame.
Under no circumstances should you operate your model in
●
crowds of people. Serious injury could result.
Never operate your model on busy streets or if there are cars
●
around.
Do not use your model to chase pets or other animals.
●
The receiver and battery boxes are not waterproof; therefore,
●
do not drive through water, wet grass, mud or snow.
Because your model is operated by radio control, it is important
●
to make sure you always are using fresh and/or fully charged
batteries (if using NiCDs or NiMHs). Never allow the batteries
to run low or you could lose control of the model.
If your model becomes stuck, allow the engine to idle, then
●
retrieve your model by hand.
To prevent excessive r.p.m. from damaging your engine and/or
●
drivetrain components, we suggest reducing throttle while in the
air during jumps.
Page
gLoW FueL Warnings
generaL Warnings
