Printing From "Js Rip; Canceling Printing From "Js Rip - GRAPHTEC JS500 Rip Manual

2. Right click without selecting an image to set the following adjustment items:
"Select All", "Save Job", "Save Job As", "Print", "Check Bar Set", and "Import"
3. Right click after selecting an image to set the following adjustment items:
"Position", "Scale", "Tile", "Rotate", "Rotate Part", "Duplicate", "Delete", "Delete Tile", "Mirror", "Repeat",
"Crop", "Image Margin", and "Information"
4. Right click after selecting multiple images to set the following adjustment items:
"Group", "Copy", "Delete", "Align Left Edges", and "Align Right Edges"
"Align Top Edges", and "Align Bottom Edges"
14 Printing from "JS RIP"
. Start up "JS RIP".
Start up from Start → All Progress → Graphtec → JS RIP.
Or double-click the icon on the desktop.
2. Open [New Job] and import the file (image) for printing.
Or open a RIP File (***.pjf).
3. Select the Model from [Digital Printer Setup].
4. In [Printer Setup], set [Print Model], [Media], unilateral or bidirectional, [Color File], the Repeat quantity.
5. Press the Online button on the printer to make it online.
6. Press the [Print] button.
7. Printing starts.
8. After printing is complete, the printheads stop at the Home Position in the standby mode.
If no operation is performed for a certain period after the printheads are moved to the Home Position, the
Capping operation is automatically performed.
15 Canceling printing from "JS RIP"
. Press the [Esc] key on the "JS RIP" screen during printing.
2. The following dialog is displayed.
Press [Yes] to quit printing.
Press [No] to resume printing.
44
