Haier HSU-07HEA03/R2 Operation Manual

Split type room air conditioner

Hide thumbs Also See for HSU-07HEA03/R2:

Installation manual (17 pages)

Operation manual (29 pages)

Operation manual (29 pages)

Table Of Contents

Table of Contents

Quick Links

OPERATION MANUAL

HSU-07HEA03/R2

HSU-09HEA03/R2

HSU-12HEA03/R2

HSU-18HEA03/R2

HSU-22HEA03/R2

HSU-24HEA03/R2

HSU-09HEA103/R2

HSU-12HEA103/R2

H2SM-(9+9)HEA03/R2

H2SM-(9+12)HEA03/R2

●

Please read this operation manual before using the air conditioner.

Keep this operation manual for future reference.

0010526880

Contents

....................................................1

CAUTIONS

PARTS AND FUNCTIONS

................................................................3

OPERATION

......................................................................6

MAINTENANCE

.......................................................... 7

TROUBLE SHOOTING

Índice

.................................................... 1

PRECAUCIONES

COMPONENTES Y FUNCIONES

................................................................ 10

FUNCIONAMIENTO

...................................................................... 13

MANTENIMIENTO

RESOLUCIÓN DE PROBLEMAS

Contenuti

.................................................... 1

AVVERTENZE

.................................................................... 16

PARTI E FUNZIONI

................................................................ 17

FUNZIONAMENTO

...................................................................... 20

MANUTENZIONE

RISOLUZIONE DEI PROBLEMI

Table des matières

.................................................... 1

AVERTISSEMENTS

.................................................................... 23

PIÈCES ET FONCTIONS

................................................................ 24

OPÉRATION

...................................................................... 27

MAINTENANCE

.......................................................... 28

DÉPANNAGE

....................................................

.................................................................... 9

.......................................................... 14

.......................................................... 21

Table of Contents

Need help?

Do you have a question about the HSU-07HEA03/R2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Haier HSU-07HEA03/R2

Page 1: Operation Manual
TROUBLE SHOOTING Índice ............ 1 PRECAUCIONES ..............9 COMPONENTES Y FUNCIONES ..............10 FUNCIONAMIENTO ..............13 MANTENIMIENTO ............14 RESOLUCIÓN DE PROBLEMAS HSU-07HEA03/R2 HSU-09HEA03/R2 Contenuti HSU-12HEA03/R2 ............ 1 AVVERTENZE ..............16 PARTI E FUNZIONI HSU-18HEA03/R2 ..............17 FUNZIONAMENTO ..............20...
Page 2: Parts And Functions
Parts and Functions Remote controller Indoor Unit CLOCK button 6. HEALTH button 7. MODE button Air Purifying Filter Inlet grille 8. HOUR button SWING button Inlet 10. ON/OFF button 11.TIMER ON display 12. FAN SPEED display Outlet AUTO Emergency Anion generator 13.
Page 3: Clock Set
Operation Emergency operation and test operation Clock set Press CLOCK button, "AM" or "PM" flashes. Emergency Operation: Press to set correct time. Each press will increase Use this operation only when the remote controller or decrease 1min. If the button is kept pressed,time will is defective or lost.
Page 4: Sleep Operation
Operation In AUTO mode Sleep Operation The unit operaters in corresponding sleep mode adapted to the automatically selected operation Before going to bed,you can simply press the SLEEP mode. button and unit will operate in SLEEP mode and bring 4. In FAN mode you a sound sleep.
Page 5 EUROPEAN REGULATIONS Operation CONFORMITY FOR THE MODELS Timer On/Off On-Off Operation All the products are in conformity with the following European provision: Set clock correctly before starting TIMER operation. - Low Voltage Directive 73/23/EEC 1.After unit starts, select your desired operation mode. - Low Voltage Directive 2006/95/EC 2.Press TIMER button to change TIMER mode.
Page 6: Replacement Of Air Purifying Filter
Maintenance For Smart Use of The Air Conditioner Remote Controller Indoor Body Setting of proper room Do not block the air inlet temperature or outlet Proper wipe the air conditioner by using a temperature soft and dry cloth.For serious stains, use a neutral detergent diluted with Do not usewater,wipe the controller water.Wring the water out of the...
Page 7 Cautions WARNING Please call Sales/Service Shop for the Installation. Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. WARNING Check proper When abnormality such as burnt-small found, Use an exclusive immediately stop the operation button and power source installation of the...
Page 8: Trouble Shooting
Trouble shooting Cautions Before asking for service, check the following grille of the air Do not obstruct or cover the ventilation first. conditoner.Do not put fingers or any other things into the inlet/outlet and swing louver. Phenomenon Cause or check points Do not allow children to play with the air conditioner .In no When unit is stopped, it won't restart...
Page 9: Codes And Description
HSU-18,22HEA03/R2 Service Diagnosis 7.Codes and Description 7.1Codes and Description HSU-18HEA03/R2 7.1.1Problem Symptoms and Measures Reference Symptom Check Item Details of Measure page Check to make sure that the rated voltage is Check the power supply. ---- supplied. None of the Check to make sure that the indoor PCB is units operates Check the indoor PCB...
Page 10 HSU-18,22HEA03/R2 Service Diagnosis Pull the sensor out of the mainboard Measure the value of resistance Between its two jumpers Measure the temperature at the room temperature sensing head. Check the value of the Sensor is broken,replace it with new sensor sensor to see whether the sensor is damaged or not? The indoor PCB is broken, replace with new indoor PCB...
Page 11 HSU-18,22HEA03/R2 Service Diagnosis E14 :Indoor fan motor malfunction Notes: When the unit is on ,don’t pull out or insert the terminal of the motor (CN9), or else The motor would be damaged. whether terminal CN8 Pull out and reinsert the terminals and CN9 on indoor PCB well inserted or not? Electrify the machine again and turn it on in the cooling...
Page 12: Problem Symptoms And Measures
HSU-18,22HEA03/R2 Service Diagnosis 7.2 Codes and Description HSU-22HEA03/R2 7.2.1Problem Symptoms and Measures Reference Symptom Check Item Details of Measure page Check to make sure that the rated voltage is Check the power supply. ---- supplied. None of the Check to make sure that the indoor PCB is units operates Check the indoor PCB ----...
Page 13 HSU-18,22HEA03/R2 Service Diagnosis Pull the sensor out of the mainboard Measure the value of resistance Between its two jumpers Measure the temperature at the room temperature sensing head. Check the value of the Sensor is broken,replace it with new sensor sensor to see whether the sensor is damaged or not? The indoor PCB is broken, replace with new indoor PCB...
Page 14 HSU-18,22HEA03/R2 Service Diagnosis Turn off power supply and rotate fan by hand Does fan rotate Replace fan motor smoothly? Turn power ON and operate fan Turn off power supply and disconnect Does it rotate? fan motor connector,then turn power Check output of fan motor connector Is motor power voltage DC310V between the red wire and the black wire of Terminal CN601 generated?
