- Page 1 M105-DE100-005 HIGH RESOLUTION DOME CAMER A OPER ATI ON MA NUAL Thank you for choosing our high quality camera. Before attempting to connect or operate, please read and follow these instructions.
- Page 2 CAU T ION These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. Use Class 2 Power Supply Only...
- Page 3 C O NT E NT S 1. CAUTIONS 2. IMPORTANT SAFETY INSTRUCTIONS 3. FEATURES 4. EQUIPMENT AND ACCESSORIES 5. OVERVIEW AND FUNCTION 6. INSTALLATION 7. CONNECTION 8. DIMENSIONS 9. SPECIFICATION 10. OSD MENU STRUCTURE...
- Page 4 1 . C AUT IO N S This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
-
Page 5: Risk Of Electric Shock Do Not Open
1 . C AUT IO N S WEEE (Waste Electrical & Electronic Equipment) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. -
Page 6: Important Safety Instructions
2 . IMP O R TA NT S A FE T Y I N ST R U C T I O N S 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. - Page 7 3 . F E AT U R E S • 1/3 960H SONY EXview HAD CCD II • High Resolution of 700TV Lines • OSD Function • Multi Language (ENGLISH / JAPANESE / GERMAN / FRENCH / RUSSIAN / PORTUGUESE / SPANISH / CHINESE) •...
-
Page 8: Equipment And Accessories
4 . EQ UI P ME N T AN D A C CE SS O R I ES DOME CAMERA VIDEO OUTPUT TEST CABLE OPERATION MANUAL SCREW - 3ea TEMPLATE... -
Page 9: Ov Ervi Ew A N D F U N C T I O N
5 . OV ERVI EW A N D F U N C T I O N • Name (LED Type) IR L E D 30ea P hoto C el l 3 -A x i s G imba l • CONTROL FUNCTION (OSD JOYSTICK) Se r v ic e V i d eo O S D J o y s t i ck... -
Page 10: Installation
6 . INS TAL LATI O N Lens Focus Knob Lens Zoom Knob Separate LED Cover (Sunshield Cover) and adjust LENS ZOOM / FOCUS KNOB After setting the LENS, assemble the LED Cover (Sunshield Cover). PART NAME Mount Guide Housing Bottom Holder Panning Holder Tlit Holder Rotate... - Page 11 7 . C ON NE CT I O N • DUAL(DC 12V/AC24V) D C 1 2V / A C 24 V D U A L P O W E R S U P P L Y V I D E O I N B NC FE M A L E V ID EO •...
- Page 12 8 . D IM EN S I O N S Unit : mm Ø100 Ø135...
-
Page 13: Specification
9 . SPE CIF I C ATI ON Signal Format NTSC 1/3˝ 960H SONY EXview HAD CCD II Image Device Scanning System 2:1 Interlace H.Resolution 700TV Lines Scanning Frequency H:15.734KHz, V:59.94Hz H:15.625KHz, V:50Hz Total Pixels 1020(H) X 508(V) 1020(H) X 596(V) Effective Pixels 976(H) X 494(V) 976(H) X 582(V) - Page 14 1 0. OS D M E N U ST R U CT U R E MAIN 1st Sub 2nd Sub 3rd Sub 4th Sub MENU MENU MENU MENU MENU MA NUAL T Y PE LEN S M ODE A UT O , O P E N, C L O S E AUT O S P E E D ( 0 00 ~ 2 5 5 )
- Page 15 1 0. OS D M E N U ST R U CT U R E MAIN 1st Sub 2nd Sub 3rd Sub 4th Sub MENU MENU MENU MENU MENU DE TEC T S E NS E ( 0 0 0 ~ 12 7 ) B L O CK DI S P OFF,ON,ENABLE (CONTROLER) M O NI TO R A REA...
