Quick Start Guide
DS-9000 / DS-9100 Series DVR
Menu Structure
The menu structure of the DS-9000 / DS-9100 Series DVR is
as followed:
Startup and Shutdown
Proper startup and shutdown procedures are crucial to
expanding the life of your DVR.
To startup your DVR:
1. Ensure the power supply is plugged into an electrical
outlet. It is HIGHLY recommended that an
Uninterruptible Power Supply (UPS) is used in
conjunction with the unit. The Power indicator LED on
the front panel should turn red, indicating the unit is
receiving power.
2. Press the POWER button on the front panel. The Power
indicator LED should turn blue. The unit will begin to
start.
3. After startup, the Power indicator LED will remain blue.
A splash screen with the status of the DSP and HDD will
be shown. The first row of icons at the bottom of the
screen shows the DSP status. If an 'X' is shown on top of
an icon, it means that the DSP initialization has failed.
The second row of icons shows the HDD status. If an 'X'
is shown, it means that the HDD is not installed or cannot
be detected.
(V1.0.2)
There are two proper ways to shutdown the DVR. To
shutdown the DVR:
•
OPTION 1: Standard Shutdown
1. Enter the Shutdown menu by clicking on Menu >
2. Select the Shutdown button.
3. Click the Yes button.
•
OPTION 2: Manual Shutdown

1. Press and hold the POWER button for 3 seconds.
2. Enter the administrator's username and password in the
dialog box for authentication.
3. Click the Yes button.
Note:
system is shutting down.
Using the Setup Wizard
By default, the
Setup Wizard will
start once the
DVR has loaded.
The Setup Wizard
will walk you
through some of
the more important settings of your DVR. If you do not
wish to use the Setup Wizard at this time, click the Cancel
button. You may also choose to use the Setup Wizard at a
later time by leaving the "Start Wizard when DVR starts?"
checkbox checked.
To start using the Setup Wizard:
Quick Start Guide - DS-9000 / DS-9100 Series DVR
Shut down.
Do not press the POWER button again when the

1


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-9000 series and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION DS-9000 series

Summary of Contents for HIKVISION DS-9000 series

  • Page 1 Quick Start Guide  DS-9000 / DS-9100 Series DVR (V1.0.2) There are two proper ways to shutdown the DVR. To Menu Structure  shutdown the DVR: • The menu structure of the DS-9000 / DS-9100 Series DVR is OPTION 1: Standard Shutdown as followed: 1. Enter the Shutdown menu by clicking on Menu > Shut down.
  • Page 2   1. Click the Next button 9. Click the Next button. on the Wizard window. This will take you This will take you to to the Record Settings the User Permission Window. window. 10. To enter the 2. Navigate to the Admin Record Settings window, click the Enter button.
  • Page 3   Congratulations! You’ve completed the Setup Wizard. The 4. Recordings will next step in the initial setup process is to setup the system automatically be date and time. playbacked in the Playback Setting Date & Time  interface. It is extremely important to setup the system date and time to accurately timestamp recordings and events.
  • Page 4   Playback from System Log  4. Select the files to You may also playback recordings from the System Log. export. To playback video from the System Log: You may also click 1. Enter the Log the Play button to Search menu by verify that these files clicking Menu>...
  • Page 5   1. Enter the Camera 8. If IP camera was Management menu added successfully, the by clicking Menu > Status for that camera Setting > Camera. would show that it is 2. Determine Connected. If it does number of analog not, click the Set  ...
  • Page 6   Using the Front Panel Controls      The controls on the front panel include: Power Button: Powers DVR on/off. IR Receiver: Receiver for IR remote. USB Ports: Universal Serial Bus (USB) ports for additional devices such as USB mouse and USB Hard Disk Drive (HDD).
  • Page 7   • ESC Button: The ESC button is used to escape to the previous menu and to arm/disarm the DVR in Preview mode. • REC/SHOT Button: The REC/SHOT button is used to enter the Manual Record interface. If used when controlling a PTZ, pressing the REC/SHOT button and then a Numeric button will call a PTZ preset.
  • Page 8   Note: If GUARD indicator is blue (default), all alarm event and exception settings are valid. Otherwise, alarm event and exception settings will be invalid, but normal recording will still be available. Note: It is important to note that you must click the EDIT button on either the remote or front panel on a text field before you’re able to edit its content.
