- Page 1 User’s Manual ATX x Motherboard x 2807770 Version 1.0, October 2007...
- Page 2 Copyrights This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer. In general, the manufacturer will not be liable for any direct, indirect, special, incidental or consequential damages arising from the use of inability to use the product or documentation, even if advised of the possibility of such damages.
-
Page 3: Serial Ata Ribbon Cable X
2 8 0 7 7 7 0 User’s Manual Packing List Please check package component before you use our products. Hardware: 2807770 Full size ATX motherboard x 1 Cable Kit: Floppy flat cable x 1 DB25 & DB9 cable x 1... - Page 4 2 8 0 7 7 7 0 User’s Manual Index Chapter1 <Introduction> ..............6 1.1 <Product Overview>................. 6 1.2 <Product Specification> ................7 1.3 <Component Placement> ................ 9 1.4 <Block Diagram>..................10 1.5 <Mechanical Drawing >................11 Chapter 2 <Hardware Setup> ............
-
Page 5: Table Of Contents
2 8 0 7 7 7 0 User’s Manual Chapter 3 <System Configuration> ........... 34 3.1 <SATA configuration>................34 3.2 <SATA RAID Configuration> ..............35 3.3 <Audio Configuration> ................39 3.4 <Video Memory Setup> ................. 40 Appendix A <I/O Port Pin Assignment> ......... - Page 6 2 8 0 7 7 7 0 User’s Manual (This page is left for blank...
-
Page 7: Chapter1
Accelerator (GMA) 3000 technology for new graphic engine. It can provide up to 256MB of frame buffer when you install over 512MB of system memory. The ICH8DO integrates with up to 10 USB2.0 interfaces (6 ports for 2807770) I/O panel, and serial ATA II interface with RAID function. -
Page 8: Product Specification
2 8 0 7 7 7 0 User’s Manual 1.2 <Product Specification> General Specification Form Factor Full size ATX motherboard Intel® Core 2 Quad/Core 2 Duo/Pentium 4/Pentium D/ Celeron D series processor with LGA775 socket Package type: PLGA 775 Front side bus: 533/800/1066MT/s (133/200/266/QuadMHz x 4) Intel®... - Page 9 Storage within -20 ~ 85 C (-4 ~ 185 Ordering Code 2807770 Support Intel Core 2 Quad LGA775 with DDRII, Onboard VGA, Dual Intel Gigabit LAN 10 x USB2.0, Realtek ALC888 HD Audio, 6 x COM Ports, GPIO, SATA and ISA slot...
-
Page 10: Component Placement
2 8 0 7 7 7 0 User’s Manual 1.3 <Component Placement> DIMM Mini PCI PCI-Express Serial port Audio SPDIF... -
Page 11: Block Diagram
2 8 0 7 7 7 0 User’s Manual 1.4 <Block Diagram> Intel Core 2 Quad / Duo with 775 pin PLGA processor 6.4GB/s Intel GMA3000 Graphics 4 x 240-pin DDR2 PCI-Express x16 533/667/800MHz 8GB/s Intel Q965 up to 8GB 2GB/s SMBus 2.0 6 x Serial ATA II ports... -
Page 12: Mechanical Drawing
2 8 0 7 7 7 0 User’s Manual 1.5 <Mechanical Drawing > “ “ “ “ “ “ “ “ “ -11-... -
Page 13: Chapter 2
2 8 0 7 7 7 0 User’s Manual Chapter 2 <Hardware Setup> 2.1 <Connector Location> COM Port 3~6 CN_USB1/2 JRTC JFRNT CN_DIO SATA II CPUFAN CN_AUDIO SYSFAN CN_LPT IrDA CN_12V NBFAN CN_SMBUS CDIN COM2 -12-... -
Page 14: Jumper Location
2 8 0 7 7 7 0 User’s Manual 2.2 <Jumper Location> Jumper Function JRTC CMOS Operating/Clear Setting JRTC -13-... -
Page 15: Connector Reference
2 8 0 7 7 7 0 User’s Manual 2.3 <Connector Reference> 2.3.1 <Internal Connectors> Connector Function PLGA775 CPU socket DDRII1/2/3/4 240 -pin DDR2 SDRAM DIMM socket S_ATAII1/2/3/4/5/6 7-pin Serial ATA II connector 24-pin power supply connector CN_12V 8-pin +12V additional power supply connector CN_AUDIO 5 x 2-pin audio connector CDIN... -
Page 16: Cpu And Memory Setup
2 8 0 7 7 7 0 User’s Manual 2.4 <CPU and Memory Setup> 2.4.1 <CPU installation> 2807770 has a PLGA775 CPU socket onboard; please check following steps to install the processor properly. Attention If 2807770 need RMA, please Keep CPU socket cover on the CPU Socket. -
Page 17: Memory Installation
2 8 0 7 7 7 0 User’s Manual 2.4.2 <Memory installation> 2807770 has four 240-pin DDR2 DIMM support up to 8GB of memory capacity. The memory frequency supports 533/667/800 MHz. Only Non-ECC memory is supported. Dual-Channel technology is supported while applying two modules with A+B channel. -
Page 18: Cmos Setup
2 8 0 7 7 7 0 User’s Manual 2.5 <CMOS Setup> The board’s data of CMOS can be setting in BIOS. If the board refuses to boot due to inappropriate CMOS settings, here is how to proceed to clear (reset) the CMOS to its default values. -
Page 19: Serial Ata Installation
2 8 0 7 7 7 0 User’s Manual 2.6 <Serial ATA installation> 2807770 has six Serial ATA II interfaces with RAID function, the transfer rate of the Serial ATA II can be up to 300MB/s. Please go to http://www.serialata.org/ for more about Serial ATA technology information. -
Page 20: Floppy Installation
2 8 0 7 7 7 0 User’s Manual 2.7 <Floppy Installation> 2807770 has one 34-pin floppy interface, it supports use floppy and powering from onboard, please follow up the steps below to install the device. Floppy Installation... -
Page 21: Lan Installation
2 8 0 7 7 7 0 User’s Manual 2.8 <LAN installation> 2807770 integrates two Gigabit LAN interfaces with Dual Intel 82573L; they provide a standard IEEE 802.3 Ethernet interface for 1000BASE-T, 100BASE-TX and 10BASE-T applications. 2807770 provides two RJ45 connectors on the rear I/O panel. -
Page 22: Audio Installation
2 8 0 7 7 7 0 User’s Manual 2.9 <Audio Installation> The board integrates onboard audio interface with REALTEK ALC888 codec, with Intel next generation of audio standard as High Definition Audio, it offers more vivid sound and other advantages than former AC97 audio compliance. - Page 23 2 8 0 7 7 7 0 User’s Manual Connector: CN_AUDIO Type: 10-pin (2 x 5) header (pitch = 2.54mm) Description Description MIC_L Ground MIC_R ACZ_DET Front_R MIC_JD Sense Front_L Line_JD Connector: CDIN Type: 4-pin header (pitch = 2.54mm) Description CD –...
-
Page 24: Display Installation
2 8 0 7 7 7 0 User’s Manual 2.10 <Display Installation> 2807770 integrates with Intel® Q965 GMCH for Intel Graphic Media Accelerator (GMA) 3000 technology. It supports Intel® DVMT (Dynamic Video Memory Technology) 3.0 for up to 256MB frame buffer size shared with system memory. With a 400MHz core and DirectX 9 and OpenGL acceleration, 2807770 provides the powerful onboard graphics interface without additional graphic card. -
Page 25: Usb Installation
2 8 0 7 7 7 0 User’s Manual 2.11 <USB Installation> 2807770 integrates 10 USB2.0 ports. The specifications USB2.0 are listed below: Interface USB2.0 Controller Intel ICH8DO Transfer Rate Up to 480Mb/s The Intel® ICH8DO contains and Enhanced Host Controller Interface (EHCI) and six Universal Host Controller Interfaces (UHCI), it can determine whether your connected device is for USB1.1 or USB2.0, and change the transfer rate automatically. - Page 26 2 8 0 7 7 7 0 User’s Manual Connector: CN_USB1/2 Type: 10-pin (5 x 2) header for USB1/2 Ports Description Description Data0- Data1- Data0+ Data1+ Ground Ground Ground CN_USB1/2 -25-...
-
Page 27: Power And Fan Installation
2 8 0 7 7 7 0 User’s Manual 2.12 <Power and Fan Installation> The 2807770 provides a standard ATX power supply with 24-pin ATX connector and additional 12V connector, and the board provides one 4-pin fan connectors supporting smart fan for CPU cooler and two 3-pin cooler fan connectors for system and Northbridge chip. - Page 28 2 8 0 7 7 7 0 User’s Manual Connector: ATX Type: 24-pin ATX power connector PIN assignment 3.3V 3.3V 3.3V -12V PS_ON PW_OK 5V_SB 3.3V Connector: CN_12V Type: 8-pin standard Pentium 4 additional +12V power connector Description Description Ground +12V Ground +12V...
-
Page 29: Gpio & Smbus Interface
2 8 0 7 7 7 0 User’s Manual 2.13 <GPIO & SMBUS interface> The board provides a programmable 8-bit digital I/O interface, and one SMBus (System management bus) interface for control panel application. Connector: CN_DIO Type: onboard 2 x 6-pin header, pitch=2.0mm Description Description Ground... -
Page 30: Serial Port
2 8 0 7 7 7 0 User’s Manual 2.14 <Serial Port> The board supports one RS232 serial port and one jumper selectable RS232/422/485 serial ports. The jumper JCSEL1 & JCSEL2 can let you configure the communicating modes for COM2. Connector: CN_COM2 Type: 10-pin (5 x 2) 2.54mm x 2.54mm-pitch box header for COM2 Description... - Page 31 2 8 0 7 7 7 0 User’s Manual JCSEL1 JCSEL2 RS-422 RS-485 RS-232 JCSEL1 JCSEL2...
-
Page 32: Switch & Indicator
2 8 0 7 7 7 0 User’s Manual 2.15 <Switch & Indicator> The JFRNT provides front control panel of the board, such as power button, reset and beeper, etc. Please check well before you connecting the cables on the chassis. Connector: JFRNT Type: onboard 14-pin (2 x 7) 2.54-pitch header Function... -
Page 33: Expansion Interface
2 8 0 7 7 7 0 User’s Manual 2.16 <Expansion Interface> 2807770 has one x16 and x4 PCI-Express slot. PCI-Express is the last expansion interface technology, for its serial data transfer scheme, each lane will be up to 500MB/s (duplex), and the x16 (16 lanes) can be up to 8GB/s more than 2GB/s as AGP 8x bus transfer rate. - Page 34 2 8 0 7 7 7 0 User’s Manual (This page is left for blank) -33-...
-
Page 35: Sata Configuration
2 8 0 7 7 7 0 User’s Manual Chapter 3 <System Configuration> 3.1 <SATA configuration> SATA Mode: This option can let you select whether the Serial ATA hard drives would work under normal IDE mode or RAID mode. The RAID mode need more than one HDD is applied. -34-... -
Page 36: Sata Raid Configuration
2 8 0 7 7 7 0 User’s Manual 3.2 <SATA RAID Configuration> The board integrates Intel® ICH8DO with RAID function for Serial ATA II drives, and supports the configurations below: RAID 0 (Stripping): Two hard drives operating as one drive for optimized data R/W performance. - Page 37 2 8 0 7 7 7 0 User’s Manual Please press <CTRL+I> to enter the RAID configuration menu. You can setup the RAID under operation system for Microsoft® Windows XP SP1 or Windows 2000 SP4 version, please install the Intel® Application Accelerator Ver.4.5 later to support RAID configuration with Intel®...
- Page 38 2 8 0 7 7 7 0 User’s Manual 2. Select Actions to Create RAID Volume Rename the Volume name Select RAID Level as 0 Left as default -37-...
- Page 39 2 8 0 7 7 7 0 User’s Manual 3. Please select two hard drives to prepare to set the RAID volume 4. Specify the Volume size Tune this bar to specify the volume size, if you specify the volume size lower than maximum, you can create a second volume for another...
-
Page 40: Audio Configuration
2 8 0 7 7 7 0 User’s Manual 3.3 <Audio Configuration> The board integrates Intel® ICH8DO with REALTEK® ALC888codec. It can support 7.1channel sound under system configuration. Please follow the steps below to setup your sound system. Install REALTEK AC97 Audio driver. Lunch the control panel and Sound Effect Manager. -
Page 41: Video Memory Setup
2 8 0 7 7 7 0 User’s Manual 3.4 <Video Memory Setup> Based on Intel® Q965 chipset with GMA (Graphic Media Accelerator) 3000, the board supports Intel® DVMT (Dynamic Video Memory Technology) 3.0, which would allow the video memory be triggered up to 256MB. To support DVMT, you need to install the Intel GMA 3000 Driver with supported OS. - Page 42 2 8 0 7 7 7 0 User’s Manual strongly recommend to be selected as MAX DVMT. Fixed + DVMT Memory Size: You can select the fixed amount and the DVMT amount at the same time for a guaranteed video memory and additional dynamic video memory, please check the table below for available setting.
- Page 43 2 8 0 7 7 7 0 User’s Manual (This page is left for blank) -42-...
- Page 44 2 8 0 7 7 7 0 User’s Manual (This page is left for blank) -43-...
-
Page 45: Appendix A
2 8 0 7 7 7 0 User’s Manual Appendix A <I/O Port Pin Assignment> A.1 <Floppy Port> Connector: FDD Type: 34-pin (2 x 17) 2.54-pitch box header Description Description Ground DRIVE DENSITY SELECT 0 Ground DRIVE DENSITY SELECT 1 Ground Ground INDEX-... -
Page 46: A.2
2 8 0 7 7 7 0 User’s Manual A.2 <Serial Port> Connector: COM1 Type: 9-pin D-sub male connector on I/O Panel Description Description Ground Connector: COM2/3/4/5/6 Type: 10-pin (2x5) 2.54-pitch box header Description Description DCD- DSR- SIN- RTS- CTS- DTR- Ground A.3 <VGA Port>... -
Page 47: A.4
2 8 0 7 7 7 0 User’s Manual A.4 <LAN Port> Connector: RJ45 Type: RJ45 connector with LED on I/O Panel Description TRD0+ TRD0- TRD1+ TRD1- Description NC TRD2+ TRD2- TRD3+ TRD3- A.5 <SMBus> Connector: CN_SMBUS Type: 5-pin SMBus (1x5)2.54 pitch header Description Description SMBDATA... -
Page 48: A.6
2 8 0 7 7 7 0 User’s Manual A.6 <Parallel Port> Connector: LPT (PRINTER) Type: 26-pin (2 x 13) 2.54-pitch box header Description Description STROBE- AUTO FEED- ERROR- INITIALIZE- SELECT INPUT- Ground Ground Ground Ground Ground ACKNOWLEDGE- Ground BUSY Ground PAPER EMPTY Ground... -
Page 49: Appedix B
2 8 0 7 7 7 0 User’s Manual Appedix B <System Resources> B1. <I/O Port Address Map> -48-... - Page 50 2 8 0 7 7 7 0 User’s Manual -49-...
- Page 51 2 8 0 7 7 7 0 User’s Manual B2. <Memory Address Map> -50-...
- Page 52 2 8 0 7 7 7 0 User’s Manual B3. <System IRQ Resources> IRQ : -51-...
- Page 53 2 8 0 7 7 7 0 User’s Manual (This page is left for blank) -52-...
-
Page 54: Appendix C
2 8 0 7 7 7 0 User’s Manual Appendix C <Programming GPIO’s> The GPIO can be programmed with the MSDOS debug program using simple IN/OUT commands.The following lines show an example how to do this. GPIO0…..GPIO7 bit0……bit7 -o 4E 87 ;enter configuration -o 4E 87 -o 4E 07... - Page 55 2 8 0 7 7 7 0 User’s Manual Appendix D <Watch Dog timer Setting > The watchdog timer makes the system auto-reset while it stops to work for a period. The integrated watchdog timer can be setup as system reset mode by program. Timeout Value Range - 1 to 255 - Second or Minute...
- Page 56 Any advice or comments about our products and service, or anything we can help you with please don’t hesitate to contact with us. We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free (U.S. Only) 800-833-8999...
