- Page 1 2807633 User’s Manual Mini-ITX Mainboard Version 1.0...
-
Page 2: Trademarks
Copyrights This document is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer. -
Page 3: Safety Instructions
Safety Instructions Always read the safety instructions carefully. Keep this User’s Manual for future reference. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. The openings on the enclosure are for air convection hence protects the equip- ment from overheating. -
Page 4: Fcc-B Radio Frequency Interference Statement
FCC-B Radio Frequency Interference Statement Th is eq u ip men t h as been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Table Of Contents
CONTENTS Copyright Notice ....................ii Trademarks ......................ii Revision History ....................ii Technical Support ....................ii Safety Instructions ....................iii FCC-B Radio Frequency Interference Statement ........... iv WEEE (Waste Electrical and Electronic Equipment) Statement ........ v Chapter 1 Getting Started ................1-1 Mainboard Specifications ................ - Page 6 PCI (Peripheral Component Interconnect) Slot ........2-18 PCI Interrupt Request Routing ............. 2-18...
-
Page 8: Chapter 1 Getting Started
Mini ITX mainboard from GAI. ® Based on the innovative Intel 945GM & ICH7M con- trol lers for optimal system efficien cy, th e 2807633 ® accommodates the latest Intel Core 2 Duo/ Core Duo/Core Solo/Celeron M p rocessors in Socket M and supports one 240-pin 533/667MHz DDRII DIMM to provide the maximum of 2GB memory capacity. -
Page 9: Mainboard Specifications
Mainboard Specifications Processor Support ® - Intel Core 2 Duo/Core Duo/Core Solo/Celeron M CPU in Socket M - Supports 3 pin CPU Fan Pin-Header with Fan Speed Control - Supports Intel Dual Core Technology to 533/667MHz and up Supported FSB - 533/667MHz Chipset ®... - Page 10 Getting Started - 1 PS2 keyboard/mouse port - 1 Line-In/Line-Out/Mic-In stacked audio jack Onboard P inheaders - 1 USB 2.0 pinheader (2 ports) - 1 parallel port pinheader - 1 f ront audio pinheader - 1 LVDS connector - 1 Digital I/O pinheader (16GPIO) - 1 RS232/422/485 COM port header for COM2~COM5 (optional) - 1 front panel pinheader Slots...
-
Page 11: Mainboard Layout
Gb LA N 945GM Int el 82573 L LAN Ja cks Gb LA N T: Lin e-In M: Line-Ou t B: Mic -In DIMM1 PCI-E1 JCI1 BIOS SYSFAN1 PCI1 JAUD1 PCI2 JCOMP 5 JA MP1 JC OMP4 2807633 Mini ITX Mainboard... -
Page 12: Chapter 2 Hardware Setup
Hardware Setup Chapter 2 Hardware Setup This chapter provides you with the information about hardware setup procedures. While doing the installation, be careful in holding the components and follow the installation procedures. For some components, if you install in the wrong orientation, the components will not work properly. - Page 13 JLPT1, p.2-15 ATX1, p.2-7 F_USB2, p.2-14 IDE1, CPU, p.2-3 p.2-9 SATA1/2, p.2-10 CPUFAN1, p.2-12 JFP1, p.2-12 Back Panel I/O, p.2-8 J1, p.2-17 CLR_CMOS1, p.2-17 JLVDS1, p.2-16 DDRII DIMM, p.2-6 JCI1,p.2-9 PCI-E Slot, BIOS p.2-18 SYSFAN1, J3, p.2-15 p.2-12 J2, p.2-13 PCI Slot, p.2-18 PCI-E Slot, p.2-18...
- Page 14 Hardware Setup Chapter 2 Hardware Setup This chapter provides you with the information about hardware setup procedures. While doing the installation, be careful in holding the components and follow the installation procedures. For some components, if you install in the wrong orientation, the components will not work properly.
-
Page 15: Cpu & Cooler Set Installation
CPU & Cooler Set Installation 1. Place the CPU on top of the socket. Make sure to align the gold arrow on the CPU with the arrow key on the socket. 2. Push the CPU down until its pins securely fit into the socket. 3. - Page 16 Hardware Setup 5. Mount the cooler set (fan & heatsink bundled) on top of the CPU and fit it into the retention mechanism. 7. Connect the fan power cable from the 6. Secure the metal clips back to the mounted fan to the 3-pin fan power con- retention mechanism.
-
Page 17: Memory
MS-96 Memory The mainboard provides one 240-pin non-ECC DDRII 533/667 DIMM slot and supports up to 2GB system memory. DDRII 240-pin, 1.8V 64x2=128 pin 56x2=112 pin Single-Channel: All DIMMs in GREEN Installing DDRII Modules 1. The memory module has only one notch on the center and will only fit in the right orientation. -
Page 18: Power Supply
Hardware Setup Power Supply ATX 20-Pin System Power Connector: ATX1 This connector allows you to connect to an ATX power supply. To connect to the ATX power supply, make sure the plug of the power supply is inserted in the proper orientation and the pins are aligned. -
Page 19: Back Panel
MS-9642 Mainboard Back Panel Serial Port LAN Port M ouse Line-In Line-Out Mic-In VGA Port Keyboard USB Ports LAN Ports Serial Port Connector The serial port is a 16550A high speed communications port that sends/ receives 16 bytes FIFOs. You can attach a serial mouse or other serial devices directly to the connector. -
Page 20: Connectors
Hardware Setup Connectors Chassis Intrusion Switch Connector: JCI1 This connector connects to a 2-pin chassis switch. If the chassis is opened, the switch will be short. The system will record this status and show a warning mes- sage on the screen. To clear the warning, you must enter the BIOS utility and clear the record. -
Page 21: Serial Ata Connectors: Sata1, Sata2
MS-9642 Mainboard Serial ATA Connectors: SATA1, SATA2 SATA1~SATA2 are high-speed SATA interface ports and support SATA data rates of 150MB/s. Each SATA connector can connect to 1 hard disk device and is fully com- pliant with Serial ATA 1.0 specifications. SATA1 SATA2 Serial ATA cable... -
Page 22: Audio Amplifier Connector: Jamp1
Hardware Setup Audio Amplifier Connector: JAMP1 The JAMP1 is used to connect audio amplifiers to enhance audio performance. Pin Definition JAMP1 SIGNAL AMP_L- AMP_L+ AMP_R- AMP_R+ Front Audio Connector: JAUD1 The JAUD1 connects to an optional audio bracket that provides extra front panel audio IO jacks. -
Page 23: Fan Power Connectors: Cpufan1, Sysfan1
MS-9642 Mainboard Fan Power Connectors: CPUFAN1, SYSFAN1 The fan power connectors support system cooling fan with +12V. When connecting the wire to the connectors, always take note that the red wire is the positive and should be connected to the +12V, the black wire is Ground and should be connected to GND. -
Page 24: Serial Port Connector: J2
Hardware Setup Serial Port Connector: J2 The J2 is a RS232/422/485 COM port pinheader that connects to serial devices. RS232 RS422 RS485 COM2 COM3 COM4 COM5 V = supported X = not supported Serial Port Bracket (Optional) Connect to J2 J2 Pin Definition Voltage Select Serial Port Serial Port... -
Page 25: Front Usb Connector: F_Usb2
MS-9642 Mainboard Front USB Connector: F_USB2 The mainboard provides one USB 2.0 pinheader (optional USB 2.0 bracket available) ® that is compliant with Intel I/O Connectivity Design Guide. USB 2.0 technology in- creases data transfer rate up to a maximum throughput of 480Mbps, which is 40 times faster than USB 1.1, and is ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, mo- dems and the like. -
Page 26: Digital Io Connector: J3
Hardware Setup Digital IO Connector: J3 The J3 connects to the General-Purpose Input/Output (GPIO) peripheral module. J3 Pin Definition SIGNAL SIGNAL VCC3 VCC5 N_GPIO10 N_GPIO20 N_GPIO11 N_GPIO21 N_GPIO12 N_GPIO22 N_GPIO13 N_GPIO23 N_GPIO14 N_GPIO24 N_GPIO15 N_GPIO25 N_GPIO16 N_GPIO26 N_GPIO17 N_GPIO27 Parallel Port Header: JLPT1 The mainboard provides a 26-pin header for connection to an optional parallel port bracket. -
Page 27: Lvds Flat Panel Connector: Jlvds1
MS-9642 Mainboard LVDS Flat Panel Connector: JLVDS1 The LVDS (Low Voltage Differential Signal) connector provides a digital interface typically used with flat panels. After connecting an LVDS interfaced flat panel to the JLVDS1, be sure to check the panel datasheet and set the J1 LVDS Power Selection Jumper to a proper voltage. -
Page 28: Jumpers
Hardware Setup Jumpers LVDS Power Selection Jumper: J1 Use this jumper to specify the LVDS power. Signal Name VCC3 LCD_SRC (default VCC3) VCC5 COM Port Power Jumpers: JCOMP4, JCOMP5 These jumpers specify the operation voltage of the serial port COM4 & COM5. JCOMP4 +12V JCOMP5... -
Page 29: Slots
Slots PCI (Peripheral Component Interconnect) Express Slot PCI Express architecture provides a high performance I/O infrastructure for Desktop Platforms with transfer rates starting at 2.5 Giga transfers per second over a PCI Express x1 lane for Gigabit Ethernet, TV Tuners, 1394 controllers, and general pur- pose I/O. - Page 30 We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free U.S. Only (800) 833-8999 (603) 886-3900 FAX: (603) 886-4545 Website: http://www.globalamericaninc.com Support: Technical Support at Global American...
