Summary of Contents for Global American 2807960

  • Page 1 2807960 User’s Manual Mini-ITX Motherboard with Socket M Version 1.0...
  • Page 2 Copyrights This document is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.
  • Page 3: Table Of Contents

    Table of Contents Chapter 1 General Description ........1 1.1 Major Features ............... 2 1.2 Specifications ................ 3 1.3 Board Dimensions..............4 Chapter 2 Inpacking ...........5 2.1 Opening the Delivery Package..........5 2.2 Inspection................5 Chapter 3 Hardware Installation ......7 3.1 Before Installation ..............7 3.2 Board Layout .................
  • Page 4: Safety Instructions

    Safety Instructions Integrated circuits on computer boards are sensitive to static electricity. To avoid damaging chips from electrostatic discharge, observe the following precautions: Do not remove boards or integrated circuits from their anti-static packaging until you are ready to install them. Before handling a board or integrated circuit, touch an unpainted portion of the system unit chassis for a few seconds.
  • Page 6: Chapter 1 General Description

    Core™ 2 Duo/Core™ Duo/Core™ Solo processor 1.66~2.33GHz. Its onboard ATA/33/66/100 to IDE drive interface architecture allows the 2807960 to support data transfers of 33, 66 or 100MB/sec. to one IDE drive connection. The Intel® ICH7-M serial ATA controller with two ports supporting transfer rates up to 150MB/sec.
  • Page 7: Major Features

    To ensure the reliability in an unmanned or standalone system , the watchdog timer (WDT) onboard 2807960 is designed with software that does not need the arithmetical functions of a real-time clock chip. If any program causes unexpected halts to the system, the onboard WDT will automatically reset the CPU or generate an interrupt to resolve such condition.
  • Page 8: Specifications

    AC97 3D audio controller Intel® ICH7-M Serial ATA controller Fast PCI ATA/33/66/100 IDE controller CF, x1 PCI-E slot, SPDIF, 6 COM, 8 USB2.0 TV-Out function Hardware Monitor function Specifications CPU: Intel® Core™ 2 Duo/Core™ Duo/Core™ Solo processor 1.66~2.33GHz Celeron® M: 410, 420, 430, 440, 450 Core™...
  • Page 9: Board Dimensions

    Watchdog Timer: Software programmable time-out intervals from 1~255 sec. CMOS: Battery backup Hardware Monitor: Winbond W83627EHG Board Size: 17.0(L) x 17.0(W) cm Board Dimensions...
  • Page 10: Chapter 2 Inpacking

    Chapter 2 Unpacking Opening the Delivery Package The 2807960 is packed in an anti-static bag. The board has components that are easily damaged by static electricity. Do not remove the anti-static wrapping until proper precautions have been taken. Safety Instructions in front of this manual describe anti-static precautions and procedures.
  • Page 11 Cables Package Description SATA cable x 1 SATA power cable x 1 Keyboard/Mouse transfer cable x 1 COM flat cable x 2 Two USB flat cable with bracket x 1 IDE flat cable x 1 Floppy flat cable x 1 Parallel port cable x 1 It is recommended that you keep all the parts of the delivery package intact and store them in a safe/dry place for any unforeseen event...
  • Page 12: Chapter 3 Hardware Installation

    Chapter 3 Hardware Installation This chapter provides the information on how to install the hardware using the 2807960. This chapter also contains information related to jumper settings of switch, and watchdog timer selection etc. Before Installation After confirming your package contents, you are now ready to install your hardware.
  • Page 13: Board Layout

    Board Layout Top Side...
  • Page 14: Jumper List

    Solder Side Jumper List Jumper Default Setting Setting Page CF Use Master/Slave Select: Slave Open Clear CMOS: Normal Operation Open JP23 COM 3/COM 4 Use RS-232 or Open RS-422/485 Select: RS-232 JP24 Open JP25 Panel Voltage Select: +3.3V Short 2-3 JP26 FSB Frequency Select: 667MHz Open...
  • Page 15: Connector List

    PCI-E Slot DVI Connector J2/J3 RS-422/485 Connector LPT1 Parallel Port PCI1 Standard PCI Slot Configuring the CPU The 2807960 provides with Intel® Core™ 2 Duo/Core™ Duo/Core™ Solo processor 1.66~2.33GHz. User don’t need to adjust the frequently and check speed of processor.
  • Page 16: System Memory

    Short 667MHz FSB (default) Open System Memory The 2807960 provides one SO-DDRII socket at locations CN15. The maximum capacity of the onboard memory is 1GB. VGA Controller The 2807960 provides two connection methods of a VGA device. CN4A offers a single standard CRT connector and JP18/JP19 are the LVDS interface connectors onboard reserved for flat panel installation.
  • Page 17: Pin Description

    NOTE: LVDS cable should be produced very carefully. Y0- & Y0+ have to be fabricated in twister pair (Y1- & Y1+, Y2- & Y2+ and so on) otherwise the signal won’t be stable. Please set the proper voltage of your panel using JP25 before proceeding on installing it. NOTE: If use JP18 only, it just supports 16-bit single channel LVDS panel;...
  • Page 18: Pci E-Ide Drive Connector

    PCI E-IDE Drive Connector CN11 is a standard 44-pin 2.0-pitch connector daisy-chain driver connector serves the PCI E-IDE drive provisions onboard the 2807960. A maximum of two ATA/33/66/100 IDE drives can be connected to the 2807960 via CN11. CN11: IDE Connector...
  • Page 19: Serial Ata Connector

    Serial ATA Connector You can connect the Serial ATA device that provides you high speeds transfer rates (150MB/sec.). If you wish to use RAID function, please note that these two serial ATA connectors just support RAID0 and only compatible with WIN XP. CN7/CN9: Serial ATA Connector Description SATATXP...
  • Page 20: Floppy Disk Drive Connector

    3.10 Floppy Disk Drive Connector The 2807960 uses a standard 34-pin header connector, CN12, for floppy disk drive connection. A total of two FDD drives may be connected to CN12 at any given time. CN12: Floppy Connector Description Description DRVDEN0...
  • Page 21: Parallel Connector

    Busy Paper Empty Printer Select 3.12 Serial Port Connectors The 2807960 offers NS16C550 compatible UARTs with Read/ Receive 16-byte FIFO serial ports and five internal 10-pin headers and two RS-422/485 connectors. CN4A: COM 1 Connector (DB9) PIN Description PIN Description...
  • Page 22 JP12~JP16: COM 2~COM 6 Connector (5x2 Header) PIN Description PIN Description +12V J2/J3: RS-422/485 Connector (3x2 Header, COM 3/COM 4) PIN Description PIN Description NOTE: The terminal resistance of RX & TX is set at 180 Ω JP23/JP24: COM 3/COM 4 use RS-232 or RS-422/485 Select Options Settings RS-232 (default)
  • Page 23: Ethernet Connector

    R/C GND JP9: Wake On LAN Description Wake On LAN 3.14 USB Connector The 2807960 provides two 8-pin connectors, at location JP10/JP11, for four USB ports, and four external USB2.0 ports at CN5B/CN6B. CN5B/CN6B: External USB2.0 Connector Description Description USBD0-/USB2-...
  • Page 24: Cmos Data Clear

    PIN Description PIN Description +3.3V +3.3V +3.3V -12V PS_ON Power OK 5VSB +12V JP3/JP4: Fan Power In Connector Description +12V Fan In 1/Fan In 2 Connector JP3/JP4 onboard 2807960 is a 3-pin fan power output connector. And 2807960 supports +12V Fan only.
  • Page 25: Keyboard/Mouse Connectors

    JP2: 6-pin Keyboard/Mouse Connector Description Keyboard Data Mouse Data Keyboard Clock Mouse Clock 3.18 System Front Panel Control The 2807960 has front panel control at location CN13 that indicates the power-on status. CN13: System Front Panel Control PIN Description Description Speaker HDD LED...
  • Page 26: Irda Function

    Connector CN13 Orientation HDD LED Speaker Button Reset PWR LED Button 3.19 IrDA Function JP27 is a 5-pin internal IR communication connector for connection of an IrDA device. JP27: IrDA Connector Description IRRX IRTX 3.20 Watchdog Timer Once the Enable cycle is active a Refresh cycle is requested before the time-out period.
  • Page 27: Tv-Out Function

    User can also use AL, 00H’s defined time for reset purposes, e.g.00H for Disable, 01H = 1sec, 02H=2sec….FFH=255sec. 3.21 TV-Out Function The 2807960 can support TV-out function whose input could be up to 800 x 600 graphics resolutions. World Wide Video standards are supported including NTSC-M (North America, Taiwan), NTSC-J (Japan), PAL-b, D, G, H, I (Europe, Asia), PAL-M (Brazil), PAL-N (Uruguay, Paraguay) and PAL-NC (Argentina).
  • Page 28: Audio Connectors

    3.22 Audio Connectors The 2807960 has an onboard AC97 3D audio controoler. The following tables list the pin assignments of the Line In/Audio Out connector. CN3: SPDIF Connector PIN Description SPDIF CN8: MIC In/Line Out Connector PIN Description PIN Description...
  • Page 29 Description Description +3.3V IDE_PDA2 IDE_PDA1 IDE_PDA0 IDE_PDD0 IDE_PDD1 IDE_PDD2 IDE_PDD11 IDE_PDD12 IDE_PDD13 IDE_PDD14 IDE_PDD15 IDE_PDCS3# IDE_PDIOR# IDE_PDIOW# +3.3V INT_IRQ15 +3.3V +3.3V RESET# IDE_PDIORDY CF_PDERQ CF_REGB IDE_ACTP# DETECT IDE_PDD8 IDE_PDD9 IDE_PDD10 Inserting a CompactFlash card into the adapter is not a difficult task. The socket and card are both keyed and there is only one direction for the card to be completely inserted.
  • Page 30: Expansion Slot

    3.24 Expansion Slot The 2807960 offers one Type III mini PCI slot at CN16, one x1 PCI-E slot at CON1, one standard PCI slot at PCI1. 3.25 8-bit I/O Function The 2807960 offers one 8-bit input/output port by parallel port.
  • Page 31 dx, port al, 80h dx, al ;;-------------------- ;;ROR cx, 08h al, 1 call delay dx, al loop ;;ROL push cx, 08h al, 1 dx, al call delay loop ;;-------------------- ;;-------------------- ;;ROR cx, 08h al, 1 call delay dx, al loop ;;ROL push cx, 08h...
  • Page 32 ;;-------------------- ;;-------------------- ;;ROR cx, 08h al, 1 call delay dx, al loop ;;ROL push cx, 08h al, 1 dx, al call delay loop ;;-------------------- ;;-------------------- ;;ROR cx, 08h al, 1 call delay dx, al loop ;;ROL push cx, 08h al, 1 dx, al call delay loop...
  • Page 33 ;;-------------------- ;;-------------------- ;;ROR cx, 08h al, 1 call delay dx, al loop ;;ROL push cx, 08h al, 1 dx, al call delay loop ;;-------------------- ;flash LED 3 time cx, 01h al, 0ffh dx, al call delay al,0h dx, al call delay loop ah, 4ch ;go back to dos...
  • Page 34 We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free U.S. Only (800) 833-8999 (603) 886-3900 FAX: (603) 886-4545 Website: http://www.globalamericaninc.com Support: Technical Support at Global American...
