- Page 1 User’s Manual Version 1.1 2807632...
- Page 2 Copyrights This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.
-
Page 3: Trademarks
If a problem arises with your system and no solution can be obtained from the user’s manual, please contact your place of purchase or local distributor. Alternatively, please try the following help resources for further guidance. Visit the Global American, Inc. website http://www.globalamericaninc.com Contact our technical staff at: support@globalamericaninc.com... -
Page 4: Safety Instructions
Safety Instructions Always read the safety instructions carefully. Keep this User’s Manual for future reference. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. The openings on the enclosure are for air convection hence protects the equip- ment from overheating. -
Page 5: Fcc-B Radio Frequency Interference Statement
Shielded interface cables and A.C. power cord, if any, must be used in order to comply with the emission limits. VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU RESEAU. 2807632 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:... -
Page 6: Table Of Contents
CONTENTS Copyright Notice ....................... ii Trademarks ........................ii Revision History ....................... ii Technical Support ......................ii Safety Instructions ......................iii FCC-B Radio Frequency Interference Statement ............iv WEEE (Waste Electrical and Electronic Equipment) Statement ........v Chapter 1. Getting Started ..................1-1 Mainboard Specifications .................. - Page 7 2 8 0 7 6 3 2 M ainboard Mainboard Specifications Processor Support - VIA C 7 1G Hz / 21 x21mm nano B G A2 pac kage - T DP max 1. 2G Hz @ 12W - S upports V R M mobile (down to 0. 7V) - T hermal des ign m argin up to 100 c Tc ase - 3D ins truc tions SSE / SSE 2 / SSE3 - S ec urity F eatures R G N / AE S / S HA-1...
-
Page 8: Chapter 1. Getting Started
Getting Started Connectors Back Panel - 1 PS/2 m ouse port - 1 PS/2 keyboard port - 2 serial ports (COMA and COMB) - 2 USB 2.0 ports - 1 LAN jack (10/100/1000) by VT6103LG - 3 flexible audio jacks - 1 S-video port - 1 DVI port - 1 VGA oort... -
Page 9: Mainboard Layout
Top : COMA VT8237 R P lu s Bottom: COMB JCI 1 J BAT 1 SATA1 S ATA2 T:MIC-In M:Line- In BATT BIOS B:SS Out VI A J FP2 V T1618 J FP1 PCI 1 CN700T (2807632) v1.X ITX Mainboard... -
Page 10: Packing Checklist
Getting Started Packing Checklist Driver/Utility CD SATA Cable Mainboard Standard Cable for Power Cable User’s Guide IDE Devices * The pictures are for ref- erence only. Your packing c on tent s may vary d e- pending on the model you purchased. -
Page 11: Chapter 2. Hardware Setup
Hardware Setup Chapter 2 Hardware Setup This chapter provides you with the information about hardware setup procedures. While doing the installation, be careful in holding the components and follow the installation procedures. For some components, if you install in the wrong orientation, the components will not work properly. -
Page 12: Quick Components Guide
2 8 0 7 6 3 2 M ainboard Quick Components Guide ATXPWR, p.2-4 DDRII DIMM, SYSFAN1, p.2-9 p.2-3 Back Panel , p.2-5 J3/J4/J5, p.2-11 IDE1, p.2-7 SATA1~2, p.2-8 F_AUDIO, p.2-9 PCI Slot, p.2-13 JFP2, p.2-10 JFP1, p.2-10 J9, p.2-11 JCI1, p.2-10 CD_IN, p.2-9 JBAT1, p.2-12... -
Page 13: Memory
Hardware Setup Memory The mainboard provides one 240-pin non-ECC DDRII DIMM and supports up to 1GB system memory. DDRII 240-pin, 1.8V 56x2=112 pin 64x2=128 pin Installing DDRII Modules 1. The memory module has only one notch on the center and will only fit in the right orientation. -
Page 14: Power Supply
2 8 0 7 6 3 2 M ainboard Power Supply ATX 20-Pin Power Connector: ATXPWR This connector allows you to connect to an ATX power supply. ATXPWR Pin Definition SIGNAL SIGNAL 3.3V 3.3V 3.3V -12V PS_ON ATXPWR PW_OK 5V_SB... -
Page 15: Back Panel
Hardware Setup Back Panel VGA Port Serial Port M ou se L-In L-Out S-Video Serial Port USB Ports DVI Port Keyboard M ouse/Keyboard Connector The standard PS/2 mouse/keyboard DIN connector is for a PS/2 mouse/keyboard. ® ® VGA Connector The DB15-pin female connector is provided for VGA monitors. Digital Panel Connector The DVI (Digital Visual Interface) connector allows you to connect an LCD monitor. - Page 16 2 8 0 7 6 3 2 M ainboard USB Connectors The OHCI (Open Host Controller Interface) Universal Serial Bus root is for attaching USB devices such as keyboard, mouse, or other USB-compatible devices. Serial Port Connector The serial port is a 16550A high speed communications port that sends/ receives 16 bytes FIFOs.
-
Page 17: Connectors
Hardware Setup Connectors ATA133 Hard Disk Connectors: IDE1 The mainboard has a 32-bit Enhanced PCI IDE and Ultra DMA 66/100/133 controller that provides PIO mode 0~4, Bus Master, and Ultra DMA 66/100/133 function. You can connect hard disk drives, CD-ROM and other IDE devices. The Ultra ATA133 interface boosts data transfer rates between the computer and the hard drive up to 133 megabytes (MB) per second. -
Page 18: Serial Ata Connectors: Sata1~Sata2
2 8 0 7 6 3 2 M ainboard Serial ATA Connectors: SATA1~SATA2 SATA1~SATA2 are high-speed Serial ATA interface ports. Each supports 1 genera- tion serial ATA data rates of 150MB/s and is fully compliant with Serial ATA 1.0 specifications. Each Serial ATA connector can connect to 1 hard disk device. SATA1~ SATA2 Pin Definition SIGNAL SIGNAL... -
Page 19: Fan Power Connectors: Sysfan1
Hardware Setup Fan Power Connector: SYSFAN1 The fan power connector supports system cooling fan with +12V. W hen connecting the wire to the connector, always note that the red wire is the positive and should be connected to the +12V, the black wire is Ground and should be connected to GND. -
Page 20: Front Panel Connectors: Jfp1, Jfp2
2 8 0 7 6 3 2 M ainboard Front Panel Connectors: JFP1, JFP2 The mainboard provides two front panel connectors for electrical connection to the front panel switches and LEDs. The JFP1 is compliant with Intel Front Panel I/ ®... -
Page 21: Front Usb Connectors: J3,J4,J5
Hardware Setup Front USB Connectors: J3,J4,J5 The mainboard provides three standard USB 2.0 pin headers. USB 2.0 technology increases data transfer rate up to a maximum throughput of 480Mbps, which is 40 times faster than USB 1.1, and is ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like. -
Page 22: Jumpers
2 8 0 7 6 3 2 M ainboard Jumpers Clear CMOS Jumper: JBAT1 There is a CMOS RAM onboard that has a power supply from external battery to keep the data of system configuration. W ith the CMOS RAM, the system can automatically boot OS every time it is turned on. -
Page 23: Slots
Hardware Setup Slot PCI (Peripheral Component Interconnect) Slot The PCI slot supports LAN cards, SCSI cards, USB cards, and other add-on cards that comply with PCI specifications. At 32 bits and 33 MHz, it yields a throughput rate of 133 MBps. PCI Slot PCI Interrupt Request Routing The IRQ, acronym of interrupt request line and pronounced I-R-Q, are hardware lines... - Page 24 Any advice or comments about our products and service, or anything we can help you with please don’t hesitate to contact with us. We will do our best to support you for your products, projects and business. Global American Inc. Address: 17 Hampshire Drive...
