- Page 1 2807660 User’s Manual Mini-ITX Motherboard Version 1.0...
- Page 2 Copyrights This document is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 General Description ........1 1.1 Major Features ............... 2 1.2 Specifications ................ 2 1.3 Board Dimensions..............4 Chapter 2 Unpacking ..........5 2.1 Opening the Delivery Package..........5 2.2 Inspection................5 Chapter 3 Hardware Installation ......7 3.1 Before Installation ..............7 3.2 Board Layout ................. -
Page 4: Safety Instructions
Safety Instructions Integrated circuits on computer boards are sensitive to static electricity. To avoid damaging chips from electrostatic discharge, observe the following precautions: Do not remove boards or integrated circuits from their anti-static packaging until you are ready to install them. Before handling a board or integrated circuit, touch an unpainted portion of the system unit chassis for a few seconds. -
Page 5: Chapter 1 General Description
Chapter 1 General Description The 2807660 series all-in-one mini ITX is designed to fit a high performance Pentium® M based processor and compatible for high-end computer system application with PCI bus architecture. It is made to meet today’s demanding pace, and keep complete compatibility with hardware and software designed for the IBM PC/AT. -
Page 6: Major Features
The mini ITX standard makes the 2807660 series work with the one slot PCI and one 6-pin Mini DIN connector for PS/2 mouse and keyboard. The onboard Flash ROM is used to make the BIOS update easier. The high precision Real Time Clock/calendar is built to support Y2K for accurate scheduling and storing configuration information. - Page 7 LVDS Panel: Supports 18-bit single channel/36-bit dual channel LVDS interface Ethernet: Three 10/100/1000 Based LAN Audio: AC97 5.1CH audio controller Serial ATA: Intel® ICH6-M controller and with 2 ports IDE: One 2.54-pitch 40-pin IDE connector Serial Port: 16C550 UART-compatible RS-232 x 2 serial ports with 16-byte FIFO USB: 6 USB ports, internal x 4 and external x 2 Keyboard: PS/2 6-pin Mini DIN...
-
Page 8: Board Dimensions
Board Dimensions... -
Page 9: Chapter 2 Unpacking
Chapter 2 Unpacking 2.1 Opening the Delivery Package The 2807660 is packed in an anti-static bag. The board has components that are easily damaged by static electricity. Do not remove the anti-static wrapping until proper precautions have been taken. Safety Instructions in front of this manual describe anti-static precautions and procedures. - Page 10 Cables Package Description IDE flat cable x 1 Serial port flat cable x 1 SATA cable x 1 I/O Bracket x 1 2 USB cable with bracket x 1 It is recommended that you keep all the parts of the delivery package intact and store them in a safe/dry place for any unforeseen event requiring the return shipment of the product.
-
Page 11: Chapter 3 Hardware Installation
Chapter 3 Hardware Installation This chapter provides the information on how to install the hardware using the 2807660. This chapter also contains information related to jumper settings of switch, and watchdog timer selection etc. Before Installation After confirming your package contents, you are now ready to install your hardware. -
Page 12: Board Layout
Board Layout Jumper List Jumper Default Setting Setting Page Clear CMOS: Normal Operation Open CPU Frequency Select: 400MHz FSB Open... -
Page 13: Connector List
Internal USB 3, 4 & 5, 6 Connectors VGA_COM1 15-pin VGA & 9-pin Serial Port 1 Connectors Configuring the CPU The 2807660 provides with Intel® Pentium® M/Celeron® M processor. JP4 is the frequently select jumper. JP4: CPU Frequency Select Options... -
Page 14: System Memory
System Memory The 2807660 provides two DDRII sockets at locations DIMM1/DIMM2. The maximum capacity of the onboard memory is 2GB. VGA Controller VGA: CRT Connector PIN Description PIN Description Green Blue DCC Data HSYNC VSYNC DCC CLK DVI1: DVI Connector... - Page 15 Signal Type Description TDC0, TDC0# DVI Data Channel 0 Output: These pins provide the DVI differential output for data channel 0 (Blue) TDC1, TDC1# DVI Data Channel 0 Output: These pins provide the DVI differential output for data channel 0 (Green) TDC2, TDC2# DVI Data Channel 0 Output: These pins provide...
- Page 16 LVDS2 Interface Connector PIN Description PIN Description +3.3V +3.3V LDDC_CLKL LCTLB_CLK_L LDDC_DATA_L LCTLB_DATA_L B_CLK- A_CLK- B_CLK+ A_CLK+ B_DATA0- A_DATA0- B_DATA0+ A_DATA0+ B_DATA1- A_DATA1- B_DATA1+ A_DATAP+ B_DATA2- A_DATA2- B_DATA2+ A_DATA2+ +12V +12V Signal Type Description LCTLB_CLK_L I2C Based control signal (Clock) for external SSC clock chip control LCTLB_DATAL I2C Based control signal (Data) for external SSC...
-
Page 17: Serial Ata Connector
Not used 3.10 Ethernet Connector Triple Marvell Gigabit Ethernet 10/100/1000 Base-TX controller by PCI Express. The 2807660 series provide three LED indicators on RJ-45 connectors to show LAN interface status. These messages will give you a guide for troubleshooting. Yellow LED indicates transmit and receive activity. -
Page 18: Usb Port
LAN 1/2/3 PIN Description LAN_LED1: Description Description L1_LED_LINKACT L2_LED_LINKACT_V L1_LED_LINK100 L2_LED_LINK1000 L1_LED_LINKACT_V L3_LED_LINKACT L1_LED_LINK1000 L3_LED_LINK100 L2_LEDLINKACT L3_LED_LINKACT_V L2_LED_LINK100 L3_LED_LINK1000 3.11 USB Port USB 1/2 Description Description +5V (fused) +5V (fused) USBP0- USBP1- USBP0+ USBP1+ USB2, USB3 Description Description 5VSB DATA_4+/DATA_6+ 5VSB DATA_3-/DATA_5- DATA_3-/DATA_5+... -
Page 19: Cmos Data Clear
3.12 CMOS Data Clear JP1: Clear CMOS Options Settings Normal Operation (default) Open Clear CMOS Short 3.13 Power and Fan Connectors PWR1: 24-pin ATX Power In Connector PIN Description PIN Description +3.3V +3.3V +3.3V -12V PS_ON PW_OK 5VSB +12V +12V +3.3V CHS_FAN1, CPU_FAN1, SYS_FAN1: Fan Power In Connector... -
Page 20: Keyboard/Mouse Connectors
3.14 Keyboard/Mouse Connectors KBMS1: PS/2 6-pin Mini DIN KB/MS Connector Description Keyboard Data Mouse Data Keyboard Clock Mouse Clock 3.15 System Front Panel Control Panel1: System Front Panel Control Description Function IDE1 Active LED HDD active# Reset System Reset LED Power button control signal System Power On Switch LED... -
Page 21: Speader
AUDIO1: Internal Audio for Chassis Description F_MIC1 F_MIC2 LOUTR LOUTL AUDIO2: External Audio Connector Blue Line In Green Line Out PINK MIC In 3.17 Speader CD1: CD-In from CD-ROM Description 3.18 IrDA Connector IR1: IrDA Connector Description Infrared transmitter output Infrared receiver input... -
Page 22: Gpio Function
3.19 GPIO Function GPIO1: GPIO Connector Description Description +3.3V GPIO bit 2 GPIO bit 3 GPIO bit 4 GPIO bit 5 GPIO bit 1 GPIO bit 0 GPIO bit 6 GPIO bit 7... - Page 23 We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free U.S. Only (800) 833-8999 (603) 886-3900 FAX: (603) 886-4545 Website: http://www.globalamericaninc.com Support: Technical Support at Global American...
