- Page 1 Dual/Quad Chip 4-Port Dedicated 5Gbps USB 3.0 PCIe Host Card User Manual Model: UGT-PCE430-2C/4C All brand names and trademarks are properties of their respective owners. www.vantecusa.com...
-
Page 2: Table Of Contents
1.3 Package Contents ..........4 Chapter 2: Getting Started ........5 2.1 Hardware Installation .......... 5 2.2 Driver Installation..........6 2.3 To verify the Hardware device ......8 2.4 To Uninstall Drivers ..........9 Chapter 3: Troubleshooting Tips ......10 UGT-PCE430-2C/4C Page 2... -
Page 3: Chapter 1: Introduction
USB 2.0 and USB 1.1 devices Supports data rates from 1.5Mbps to 5Gbps. Supports 4 downstream ports for all speeds Flexible LP4 or SATA power connector for receiving extra power from system power supply UGT-PCE430-2C/4C Page 3... -
Page 4: System Requirements
Windows XP, Vista, 7, 8, 8.1 (32/64 bit), Server 2003, 2008 R2, 2012, Linux 2.6.31 or later PCI Express x4, x8 or x16 slots 1.3 Package Contents 1 x Dual/Quad Chip 4-Port Dedicated 5Gbps USB 3.0 PCIe Host Card. 1 x Driver CD UGT-PCE430-2C/4C Page 4... -
Page 5: Chapter 2: Getting Started
4. Remove the slot bracket from an available PCI-Express x4 (x8, x16) slot. 5. To install the card, carefully align the card’s bus connector with the selected PCIe slot on the motherboard. Push the UGT-PCE430-2C/4C Page 5... -
Page 6: Driver Installation
You do not have to use the CD to start the manual installation process. 2.2 Driver Installation 1. Insert the provided CD into your disk drive. Browse to the folder “UGT-PCE430-2C_4C” for the setup program. 2. Run the Setup.exe program to start the installation program. UGT-PCE430-2C/4C Page 6... - Page 7 *Note: Actual image may varies 3. When the installation is done, select “Finish”. 4. Your device is now ready for use. UGT-PCE430-2C/4C Page 7...
-
Page 8: To Verify The Hardware Device
Start > Control Panel > Device Manager 2. Double click on the “Universal Serial Bus controllers” device and it will expand the subset showing “Renesas Electronics USB 3.0 Host Controller” and “Renesas Electronics USB 3.0 Root Hub” in the Device Manager. UGT-PCE430-2C/4C Page 8... -
Page 9: To Uninstall Drivers
1. Click on the “Programs and Features” tab in the Windows Control Panel. Start > Control Panel > Programs and Features 2. Entry “Uninstall or change a program” page, and double click “Renesas Electronics USB 3.0 Host Controller Driver” to process driver uninstallation procedure. UGT-PCE430-2C/4C Page 9... -
Page 10: Chapter 3: Troubleshooting Tips
PCI Express slot correctly. Please clean slot contact with a dry cloth and try another PCIe x4 slot. This PCIe x4 card will also fit into the PCIe x8 or x16 slot. Getting a yellow exclamation point on controller UGT-PCE430-2C/4C Page 10... - Page 11 Is it possible to connect current USB 1.1 or 2.0 devices to the USB 3.0 PCI Express card? Yes it will work. Device will not be running at USB 3.0 speed, but at USB 2.0/1.1 speed. UGT-PCE430-2C/4C Page 11...
