- Page 1 Cinema DUAL Series Cinema Duo Series User's Guide First Edition: March 2006 Model: W812xx...
- Page 2 User's Guide NOTICE Specifications and information found in this guide are subject to change without notice. Any changes therefore will be incorporated in future editions. The manufacturer assumes no responsibility for errors or omissions in this document. TRADEMARKS Windows™ XP is the trademark of Microsoft Corporation. Intel®...
- Page 3 User's Guide Standards The following standards are adopted throughout this guide: Notebook in boldface (with or without capitalization) refers to the notebook computer that you have purchased. Boldface type is also used to highlight important information in this document. Whenever extra caution is called for, the information will be boxed in a dark frame preceded by "Note:"...
- Page 4 User's Guide This page is left blank intentionally. Page IV...
-
Page 5: Table Of Contents
User’s Guide Contents CONTENTS CHAPTER 1 BEFORE YOU BEGIN ..........1-1 ..............1-1 HECKING ECEIVED ............... 1-2 XAMINING OMPUTER ................1-6 HREE OWER ................1-7 TATUS ..................1-8 OWER UTTON ............... 1-9 HREE YSTEM UTTONS PCI E ......1-10 TTENTION XPRESS EDIA LOTS ................. - Page 6 Contents User's Guide This page is left blank intentionally. Page VI...
-
Page 7: Chapter 1 Before You Begin
User's Guide Before You Begin Chapter 1 Before You Begin Please read this section before you start using your computer. Checking What You Received Your notebook package should contain the following items: • The Notebook. • AC Adapter. • AC Power Cord. •... -
Page 8: Examining Your Computer
Before You Begin User's Guide Examining Your Computer Before you start using your computer, you need to get acquainted with your notebook's main features and interfaces: Panoramic View LCD Latch Three Power LEDs LCD Screen Speaker (Underneath) Speaker (Underneath) Three System Buttons Power Button Five Status LEDs Keyboard... -
Page 9: Front View
User's Guide Before You Begin Front View LCD Latch Rear View DC-In Jack Kensington Lock RJ11 Fax/Modem Connector Battery Pack RJ45 LAN Connector S-Video Connector Page 1-3... -
Page 10: Left View
Before You Begin User's Guide Left View PCI Express Slot Ventilation Holes Two USB Connectors IEEE1394 Connector Media Slot Ventilation Holes VGA Connector Right View ODD Drive Headphone Jack (SPDIF) Volume Dial Eject Button Emergency Hole Microphone Jack Audio Line-In Jack Two USB Connectors Page 1-4... -
Page 11: Bottom View
User's Guide Before You Begin Bottom View HDD Door Ventilation Holes Compartment Door for Memory & Mini-PCI Ventilation Holes Express Modules Two Battery Latches Compartment Door for Heatsink & CPU Battery Pack Stereo Jack: Mono Jack: Your headphone jet should Your microphone jet should have this type of connector have this type of connector... -
Page 12: The Three Power Leds
Before You Begin User's Guide 1.3 The Three Power LEDs The Power On LED Below is how the LED would behave in different situations: System is powered off, or in Hibernate mode. System is in full operation. Blinking System is in Standby mode. The Wireless LAN/ Bluetooth®... -
Page 13: The Five Status Leds
User's Guide Before You Begin The Five Status LEDs The Caps Lock LED The LED would be lit when the keyboard is in Caps Lock mode. In this mode, all characters you type are in uppercase. The Num Lock LED This LED would be lit when the keyboard is in Num Lock mode. -
Page 14: The Power Button
Before You Begin User's Guide The Power Button The Power Button This Power Button is programmable by user. For detail on how to program this button, please refer to the Power Options of Control Panel in Windows System. Note: The Power Button is located on the top right side of keyboard. For exact location, please refer to the Panoramic View diagram in Chapter 1.2. -
Page 15: The Three System Buttons
User's Guide Before You Begin The Three System Buttons Wireless LAN/ Bluetooth® Button Press this button to power on and power off the Wireless LAN and Bluetooth® modules. Powering on the Wireless LAN and Bluetooth® by pressing this button does not automatically activate Wireless LAN and Bluetooth® functions. -
Page 16: Attention O Npci Express Card And Media Slots
Before You Begin User's Guide Attention On PCI Express Card And Media Slots PCI Express Card Slot Door is now inserted into the system unit. Media Slot Door is now inserted into the system unit. Arrow on topside of PCI Express Card Slot Door. - Page 17 User's Guide Before You Begin • When no card (SD/ MMC/ MS/ MS-Pro Cards) is inserted into the media slot, make sure this slot is covered by the “media slot door” as supplied together with this notebook. The purpose of this “media slot door” is to prevent foreign matters from entering into the system unit through this slot, when no card is inserted.
-
Page 18: Technical Warning
Before You Begin User's Guide Technical Warning This compartment door is sealed and not meant to be opened by notebook end- users. Warning: This sealed compartment door as indicated above is designed to be opened by qualified technicians only. Therefore, you are requested not to open this compartment door. -
Page 19: Operating Temperature
User's Guide Before You Begin Operating Temperature Operating Temperature : 10ºC to 35ºC. Page 1-13... -
Page 20: The
Before You Begin User's Guide 1.10 The <Fn> Key The <Fn> Function Key is located near the bottom-left corner of the keyboard. This key is used together with other keys to activate certain pre-defined functions. To activate these functions, press and hold down <Fn> together with the keys described below: Wireless LAN/ Bluetooth Switch Press this key combination (Fn+F2) to power on and power off the Wireless LAN and Bluetooth®...Key - Page 21 User's Guide Before You Begin CD Previous Track Press this key combination (Fn+F11) to skip to the previous CD disc track. CD Next Track Press this key combination (Fn+F12) to skip to the next CD disc track. Note: The proper way to activate Wireless LAN, and Bluetooth® is as below: 1) Press the key combination (Fn+F2) to power on Wireless LAN, and Bluetooth®.
- Page 22 Before You Begin User's Guide This page is left blank intentionally. Page 1-16...
-
Page 23: Chapter 2 Battery
User's Guide Battery Chapter 2 Battery Battery Pack Your notebook is equipped with a high-energy rechargeable Lithium Ion (Li-Ion) battery pack. Battery life will vary depending on the product configuration, product model, applications loaded on the product, power management settings of the product, and the product features used by the customer. -
Page 24: Questions And Answers
Battery User's Guide Questions And Answers I can feel a mild heat next to the battery pack. Is it normal? The battery will generate heat during recharging and discharging. There is a protection circuit inside the notebook to prevent overheating. User needs not to worry. -
Page 25: Battery Maintenance
User's Guide Battery 2.4 Battery Maintenance To maintain the battery pack's maximum capacity, you should occasionally let the notebook deplete its battery power completely before recharging. To carry out a complete depletion of the battery, disconnect the AC adapter and let your notebook consume the remaining battery power. -
Page 26: Reducing Power Consumption
Battery User's Guide Reducing Power Consumption Although your notebook (together with the operating system) is capable of power conservation, there are measures you can take to reduce the power consumption: • Use the AC power whenever possible. • Lower the intensity of the LCD backlight. A very bright screen translates to higher power usage. -
Page 27: Removing The Battery Pack
User's Guide Battery Removing The Battery Pack This battery pack can easily be removed and replaced. Make sure that the computer is properly shutdown before changing the battery pack. If you would like to change the battery pack while power is on, make sure this battery pack is not the only electrical source to the system unit. - Page 28 Battery User's Guide This page is left blank intentionally. Page 2-6...
-
Page 29: Chapter 3 Memory
User's Guide Memory Chapter 3 Memory Your notebook is equipped with a configurable memory unit. The industry standard JEDEC DDR2 S.O.DIMM memory module sockets are available for memory upgrade to 2048MB. The table below illustrates all the possible ways system memory can be configured. -
Page 30: Removing Memory Modules
Memory User's Guide Removing Memory Modules Below is the procedure on how to remove the memory modules. • Make sure the system is properly shutdown. • Flip the system upside down. • Remove the battery pack as shown in Chapter 2. Memory Modules •... - Page 31 User's Guide Memory • Press the spring-locks sideways as shown by #1. • The second memory module would pop up as shown by #2. • Remove the second memory module as shown by #3. To insert the memory modules, reverse the steps above. Page 3-3...
- Page 32 Memory User's Guide This page is left blank intentionally. Page 3-4...
-
Page 33: Chapter 4 Mini-Pci Express Module
User's Guide Mini-PCI Express Module Chapter 4 Mini-PCI Express Module Depending on model, your notebook may be equipped with an optional Mini-PCI Express module. The Mini-PCI Express module supports wireless LAN function. Removing Mini-PCI Express Module Below is the procedure on how to remove the Mini-PCI Express module. •... - Page 34 Mini-PCI Express Module User's Guide This page is left blank intentionally. Page 4-2...
-
Page 35: Chapter 5 The Hard Disk Drive
User's Guide The Hard Disk Drive Chapter 5 The Hard Disk Drive Your notebook is equipped with an industry standard 2.5”/9.5mm hard disk drive. 5.1 Removing The Hard Disk Drive Below is the procedure on how to remove the hard disk drive. •... - Page 36 The Hard Disk Drive User's Guide This page is left blank intentionally. Page 5-2...
-
Page 37: Appendix A- Agency Regulatory Notices
User’s Guide Appendix A Appendix A- Agency Regulatory Notices Safety Instructions CAUTION: Please read these safety instructions carefully. CAUTION: Please keep this User's Manual for future reference. CAUTION: Please disconnect this equipment from AC outlet before cleaning. DO NOT use liquid or sprayed detergent for cleaning. Use a clean moistened cloth. - Page 38 Appendix A User's Guide CAUTION: Verify the voltage of the power source before connecting the unit to any power outlet. WARNING: DO NOT step on or place anything over the power cord. CAUTION: All cautions and warnings on the equipment should be noted. WARNING: If the equipment is not used for a long period of time, disconnect the equipment from the power source to avoid damage from power...
- Page 39 User’s Guide Appendix A CAUTION: DO NOT LEAVE THE EQUIPMENT IN TEMPERATURES BELOW -20ºC(-4ºF) OR ABOVE 60ºC(140ºF). IT MAY CAUSE DAMAGE TO THE EQUIPMENT. WARNING: Never install modem/telephone wiring during a lightning storm. WARNING: Never install modem/telephone jacks in wet locations unless the jack is specially designed for wet locations.
- Page 40 Appendix A User's Guide WARNING: THE CD-ROM/DVD-ROM IN THIS NOTEBOOK EMPLOYS A LASER SYSTEM. a. To ensure proper use of this product, please read the relevant instructions carefully and retain for future reference. b. Should the unit ever require maintenance, contact your local dealer. c.
- Page 41 User’s Guide Appendix A WARNING: Handle the battery pack very carefully. Avoid touching the metal leads on the connector of the battery case. CAUTION: Use only approved AC Adapter with your notebook. Using the wrong type of AC Adapter may cause serious damage to your notebook. CAUTION: The AC Adapter can accept a line voltage ranging from 100V to 240V and is compatible with most international power sources.
-
Page 42: Federal Communications Commission Notice
Appendix A User's Guide Agency Notice Federal Communications Commission Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 43 User’s Guide Appendix A • If this device is going to be operated in 5.15 ~5.25GHz frequency range, then it is restricted in indoor environment only. USA and Canada Safety Requirements And Notices The FCC with its action in ET Docket 93-62 has adopted a safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC certified equipment.
-
Page 44: Canadian Notice
Appendix A User's Guide Use On Aircraft Caution Caution: Regulations of the FCC and FAA prohibit airborne operation of radio-frequency wireless devices because their signals could interfere with critical aircraft instruments. Canadian Notice This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. - Page 45 User’s Guide Appendix A For devices with built-in wireless equipment, the following additional standards apply: • ETSI301489-17: General Emissions for Radio Equipment • EN60950: Safety • ETSI300328-2: Technical Requirements for Radio Equipment CE Caution : Due to the fact that the frequencies used by 802.11b/802.11g wireless LAN devices may not yet be harmonized in all countries, 802.11b/802.11g products are designed for use only in specific countries or regions, and are not allowed to be operated in countries or regions other than those of designated use.
-
Page 46: Japanese Notice
Appendix A User's Guide Maximum allowable EIRP 802.11b wireless LAN cards in the mainland departments of France not shown in the table above are as follows: (See the ART website at www.art- telecom.fr for information on the French overseas territories.) Frequency Ranges (MHz) Indoors Outdoors... - Page 47 User’s Guide Appendix A U.S. Regulations Governing the Use of Modems This equipment complies with Part 68 of the FCC Rules. On this equipment is a label that contains, among other information, the FCC registration number and Ringer Equivalence Number (REN) for this equipment. You must, upon request, provide this information to your telephone company.
- Page 48 Appendix A User's Guide This modem is also suitable for connection to Private Automatic Branch Exchange (PABX), which return secondary proceeding indication. If this modem is to be used with a PBX which has extension wiring owned by BT, connection of the modem the PBX can only be carried out by BT; or by the authorized maintainer of the PBX unless the authorized maintainer has been given 14 days written notice that the connection is to be made by another person;...
