Gericom SuperSonic Force 17120-M660SU User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SuperSonic Force 17120-M660SU and is the answer not in the manual?

Questions and answers

Related Manuals for Gericom SuperSonic Force 17120-M660SU

Summary of Contents for Gericom SuperSonic Force 17120-M660SU

  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 8: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety uninterrupted power supply. If you are unsure of your local power specifications, consult Warning your service representative or local power company.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 11: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.

  • Page 14: Lcd Screen Care

    Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...

  • Page 15: Table Of Contents

    Preface Contents Notice .................I Function Keys ..............1-12 FCC Statement .............II System Map: Front & Rear Views .......1-13 Instructions for Care and Operation ......IV System Map: Left View ..........1-14 Power Safety .............. VI System Map: Right View ..........1-15 Battery Precautions ...........VII System Map: Bottom View ..........1-16 Cleaning ..............
  • Page 16 Preface Application Quick Buttons ..........2-11 Recharging the Battery with the AC/DC Adapter ..3-12 Recording Audio ............2-12 Proper handling of the Battery Pack ......3-13 Audio Features .............2-14 Battery FAQ ..............3-14 Adding a Printer ............2-15 Drivers & Utilities USB Printer ..............2-15 Parallel Printer ............2-15 What to Install ..............4-1 Module Driver Installation ..........4-1 Power Management...
  • Page 17 Preface Bluetooth ..............4-7 Boot Menu ..............5-11 PC Camera ..............4-7 Exit Menu ..............5-12 Fingerprint Module .............4-7 Upgrading The Computer BIOS Utilities Overview ................6-1 Overview ................5-1 When Not to Upgrade ..........6-2 The Power-On Self Test (POST) ........5-2 Removing the Battery ............6-3 Failing the POST ............5-3 Upgrading the Hard Disk Drive ........6-4 Fatal Errors ..............5-3 Upgrading the Optical (CD/DVD) Device ....6-6...
  • Page 18 Preface PC Camera Hot Key Buttons ........7-16 Non DDC CRT Monitors (for Win Vista Only) ... B-8 Fingerprint Reader Module ..........7-17 NVIDIA Video Driver Controls Fingerprint Reader Driver Installation .....7-17 NVIDIA Video Driver Installation ....... C-1 Troubleshooting NVIDIA Control Panel ..........C-2 Overview ................8-1 Attaching Other Displays ..........
  • Page 19 Preface Power Management ............D-5 (Model A Computers) ..........E-12 Power ................D-5 VIA S3Tray Plus Utility ..........E-12 Battery ................D-5 VIA S3 Display Control Panels ........E-13 Environmental Spec ............D-5 Display Devices (VIA) ..........E-14 Dimensions ..............D-5 Display Modes (VIA) ..........
  • Page 20 Preface Hibernate Mode vs. Shutdown ........E-29 Quick Button Utility ........... E-40 Stand by Mode vs. Hibernate Mode ......E-29 802.11 b/g USB WLAN Module ........ E-41 Stand by ..............E-30 802.11 b/g WLAN Driver Installation ......E-41 Hibernate ..............E-30 Bluetooth Module ............

  • Page 21: Quick Start Guide

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 22: Model Differences

    Quick Start Guide Model Differences This notebook series includes three different model types. The models differ as indicated in the table below. Feature Model A Model B Model C VIA VN896 Integrated Video System NVIDIA GeForce Go 7300 (G72M-V) Discrete Video System Video Adapter (Internal On Chip) (External On Board)

  • Page 23: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...

  • Page 24: Not Included

    Quick Start Guide Not Included Operating Systems (e.g. Windows Vista/Windows XP) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...

  • Page 25: System Software

    Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the following operating systems are sup- ported.

  • Page 26: System Startup

    Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.

  • Page 27: System Map: Lcd Panel Open Models A & B

    Quick Start Guide System Map: LCD Panel Open Models A & B Optional Built-In PC Camera Speakers Wireless Device Power Button Operation Aboard Hot Key Buttons Aircraft Hot Key Buttons (Record Audio & PC Camera Zoom) The use of any portable Keyboard electronic transmission de- vices aboard aircraft is usu-...

  • Page 28: System Map: Lcd Panel Open Model C

    Quick Start Guide System Map: LCD Panel Open Model C Optional Built-In PC Cam- Wireless Device Speakers Operation Aboard Power Button Aircraft Hot Key Buttons Keyboard The use of any portable TouchPad and Buttons electronic transmission de- vices aboard aircraft is usu- Built-In Microphone ally prohibited.
  • Page 29 Quick Start Guide LED Indicators The LED indicators display helpful information about the current status of the computer. Icon Color Description Green Number Lock Activated Green Caps Lock Activated Green Scroll Lock Activated Green The Computer is On Blinking Green The Computer is in Sleep Mode Orange The AC/DC Adapter is Plugged In &...
  • Page 30 Quick Start Guide Hot Key Buttons These buttons give instant access to the functions indicated in the table below. The Application and zoom hot key functions depend on whether or not a PC Camera module is installed. Note that Model C does not sup- port the Audio Record and Zoom (or Application Quick Buttons 2 &...

  • Page 31: Keyboard

    Quick Start Guide Keyboard The keyboard has a numerical keypad for easy numeric data input, and features function keys to allow you to change operational features instantly (see Figure 1 - 4). Note that Model C computers have a Numeric keypad to the right of the main keyboard.

  • Page 32: Function Keys

    Quick Start Guide Function Keys The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. Function Function Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F8 Decrease LCD Brightness Fn + F1 TouchPad Toggle Fn + F9...

  • Page 33: System Map: Front & Rear Views

    Quick Start Guide System Map: Front & Rear Views LED Indicators Models A & B 1 * USB Port DC-In Jack Battery LCD Latches Models A & B (Model C Only) Model C Model C Figure 1 - 5 - Front & Rear Views System Map: Front &...

  • Page 34: System Map: Left View

    Quick Start Guide System Map: Left View Figure 1 - 6 - Left View Models A & B Security Lock Slot Optical Device Drive Bay (see page RJ-11 Modem Jack Model C S/PDIF-Out Jack Microphone-In Jack Headphone-Out Jack Recording Line-In Jack (see page Changing DVD Regional Codes CD Emergency Eject Go to the Control Panel and double-click Device Manager...

  • Page 35: System Map: Right View

    Quick Start Guide System Map: Right View Figure 1 - 7 - Right View Models A & B ExpressCard Slot (see page 7-in-1 Card Reader 2 * USB 2.0 Ports Model C RJ-45 LAN Jack External Monitor Port ExpressCard Slot The ExpressCard Slot accepts either ExpressCard/34 or ExpressCard/54 formats.

  • Page 36: System Map: Bottom View

    Quick Start Guide System Map: Bottom View Figure 1 - 8 - Bottom View Vent/Fan Intake/Outlet Battery Models A & B Hard Disk Bay Cover The CPU is not a user ser- CPU/RAM Bay Cover viceable part. Opening this compartment, or accessing the CPU in any way, may vi- olate your warranty.

  • Page 37: Windows Vista Start Menu & Control Panel

    Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 38: Video Features

    Quick Start Guide Video Features This computer features two different (either VIA for Model A or NVIDIA for Models B & C) video options. You will be provided with an appropriate driver on the Device Drivers & Utilities + User’s Manual CD-ROM. You can switch display devices, and configure display options, from the Display Settings control panel (in Per- sonalization) in Windows Vista.
  • Page 39 Quick Start Guide Figure 1 - 10 - Display Settings Video Features 1 - 19...

  • Page 40: Power Options

    Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 17) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.

  • Page 41: Features & Components

    Features & Components Chapter 2: Features & Components Overview Model C Computers Note that Model C com- Read this chapter to learn more about the following main features and components puters do not support of the computer: the audio record or cam- era zoom hot keys func- •...

  • Page 42: Hard Disk Drive

    Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives (see “Storage” on page D - 3) with a height of 9.5 mm.

  • Page 43: Optical (Cd/Dvd) Device

    Features & Components Optical (CD/DVD) Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page D - 3). The Adjustment optical device is usually labeled “Drive D:”...

  • Page 44: Handling Cds Or Dvds

    Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.

  • Page 45: Dvd Regional Codes

    Features & Components DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...

  • Page 46: 7-In-1 Card Reader

    Features & Components 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).

  • Page 47: Expresscard Slot

    Features & Components ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which require a larger interface slot, e.g. rubber cover provided in CompactFlash card reader.

  • Page 48: Touchpad And Buttons/Mouse

    Features & Components TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. If you are using an ex- ternal mouse your op- Once you have installed the TouchPad driver (see...

  • Page 49: Function Keys/Hot Keys

    Features & Components Function Keys/Hot Keys The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn Hot Key Program key is held down. visual Model A & B Computers indicators will only be displayed (and the audio In addition to the basic function key combinations visual indicators are available (for record function will only...
  • Page 50 Features & Components Keys/Button Function Keys/Button Function PC Camera Models Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F10 A & B Only Power Toggle TouchPad WLAN Module Models Models Fn + F1 Fn + F11 Toggle A & B Only Power Toggle A &...

  • Page 51: Application Quick Buttons

    Features & Components Application Quick Buttons Note that the application quick button utility is designed to allow use of the hot key Application.exe buttons in absence of the optional PC Camera (the quick button utility will only appear if no PC Camera is installed). You will need to install the Quick Button You will need to locate Utility (see page 6) to enable the functions.

  • Page 52: Recording Audio

    Features & Components Recording Audio (Models A & B only) Model C Computers audio record hot key button allows you to record audio from either the built- in microphone, or from a microphone connected to the microphone-in jack. To Note that Model C com- record on the computer, setup the audio recording options in Windows as follows puters do not support the audio record or cam-...
  • Page 53 Features & Components Figure 2 - 8 Audio Setup for Recording (Windows Vista) Right-click Recording Audio 2 - 13...

  • Page 54: Audio Features

    Features & Components Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the VIA Audio Deck icon in the taskbar, or on the Adjustment desktop (this will bring up the VIA Audio Deck menu). The volume may also be The sound volume level adjusted by means of the Fn + F5/F6 key combination.

  • Page 55: Adding A Printer

    Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- USB Printer...
  • Page 56 Features & Components 2 - 16...

  • Page 57: Power Management

    Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.

  • Page 58: The Power Sources

    Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-in jack at the rear of the computer.

  • Page 59: Turning On The Computer

    Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shut Down er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate hot- ways shut your comput- er down by choosing the key button when it is pressed for less than 4 seconds (pressing and holding the power...

  • Page 60: Power Plans

    Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
  • Page 61 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance for maximum performance when the computer is pow- ered from an AC power source.

  • Page 62: Power-Saving States

    Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where Power Button you left off. Sleep is the default power-saving state in Windows Vista. The Power Button Earlier versions of Windows used Stand By and Hibernate as system power-saving in the Start Menu (in Classic View use the states.

  • Page 63: Hibernate

    Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.

  • Page 64: Configuring The Power Buttons

    Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Protection It is recommended that you enable a password on wake up in order to protect your data.

  • Page 65: Resuming Operation

    Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status Icon Color To Resume send the computer to...

  • Page 66: Battery Information

    Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power When the battery is criti- Your computer’s battery power is dependent upon many factors, including the pro- cally low, immediately grams you are running, and peripheral devices attached.

  • Page 67: Conserving Battery Power

    Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that Windows Mobility this may have an affect on computer performance. Center • Lower the brightness level of the LCD display. The system will decrease LCD Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.

  • Page 68: Battery Life

    Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...

  • Page 69: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.

  • Page 70: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
  • Page 71 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 8 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
  • Page 72 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.

  • Page 73: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual CD- of the computer’s subsystems. The system takes ad- ROM (Win Vista OR WinXP) contains the drivers and vantage of some newer hardware components for utilities necessary for the proper operation of the com-...

  • Page 74: Driver Installation

    Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the CD-ROM and click Install Vista Drivers (button).

  • Page 75: Manual Driver Installation

    Drivers & Utilities Manual Driver Installation If you wish to install the drivers manually, click the Exit button to quit the Drivers Installer application, and then browse to the executable file in the location listed in the table below and follow the installation procedure for each driver.

  • Page 76: Updating/Reinstalling Individual Drivers

    Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control (Win Vista) If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue or this go to the Control Panel in the Windows OS and Allow, and follow the installation procedure as direct- double-click the Programs and Features icon (Pro-...

  • Page 77: Driver Installation Procedure

    Drivers & Utilities Driver Installation Procedure Modem 1. Click 3.Install Modem Driver > Yes. Video (VIA - Model A) 2. Click OK. 1. Click 1.Install Video Driver > Yes. 3. The modem is ready for dial-up configuration. 2. Click Next > Next. 3.

  • Page 78: Cardreader

    Drivers & Utilities CardReader Hot Key Utility (Model C Computers) 1. Click 5.Install CardReader Driver > Yes. 1. Click 7.Install Hotkey Utility > Yes. 2. Click Next > Next. 2. Click Next. 3. Click Finish to restart the computer. 3. Click Finish to restart the computer. TouchPad Quick Button Utility 1.

  • Page 79: Wireless Lan

    Drivers & Utilities Wireless LAN See the introduction in “802.11 b/g USB WLAN Mod- ule” on page 7 - 2, and check the installation proce- Adding/Removing a PC Camera dure. Note that the Quick Button and PC Camera drivers can- not co-exist.
  • Page 80 Drivers & Utilities 4 - 8 Driver Installation...

  • Page 81: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to The Setup utility malfunction. To correct If your computer has never been set up, or you are making important changes to the mistakes, return to Set- up and restore the Set- system (e.g.

  • Page 82: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...

  • Page 83: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 84: Setup Screens

    BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with five (5) menu headings. When you Setup menus select a heading, a new screen appears. Scroll through the features listed on each shown in this section are screen to make changes to Setup.

  • Page 85: Main Menu

    BIOS Utilities Main Menu Figure 5 - 2 PhoenixBIOS Setup Utility Main Menu Main Main Advanced Security Boot Exit Item Specific Help System Time: [22:11:05] System Date: [05/12/2007] IDE Channel 0 Master [Optiarc CD-RW CRX880A-(PM] <Tab>, <Shift Tab>, or IDE Channel 2 Master [FUJITSU MHV2100BH PL-(S1)] <Enter>...

  • Page 86: Ide Channel 0/2 Master (Main Menu)

    BIOS Utilities IDE Channel 0/2 Master (Main Menu) Pressing Enter opens the sub-menu to show the configuration of either a DVD/CD Device or HDD on the computer’s IDE Channels. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory: (Main Menu) This item contains information on the system memory, and is not user configurable.

  • Page 87: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 PhoenixBIOS Setup Utility Advanced Menu Main Advanced Advanced Security Boot Exit Item Specific Help Installed O/S: [WinXP/Vista] Select the operating Boot-time Diagnostic Screen: [Enabled] system installed Legacy USB Support: [Enabled] on your system which Reset Configuration Data: [No] you will use most...

  • Page 88: Boot-Time Diagnostic Screen: (Advanced Menu)

    BIOS Utilities Boot-time Diagnostic Screen: (Advanced Menu) Use this menu item to enable/disable the Boot-time Diagnostic Screen (see “The Power-On Self Test (POST)” on page 5 - Legacy USB Support: (Advanced Menu) Choose “Enabled” if you intend to use USB devices in systems which do not nor- mally support USB functionality (e.g.

  • Page 89: Security Menu

    BIOS Utilities Security Menu Figure 5 - 4 PhoenixBIOS Setup Utility Security Menu Security Main Advanced S S e e c c u u r r i i t t y y Exit Item Specific Help Supervisor Password Is: Clear Supervisor Password Set Supervisor Password [E E n n t t e e r r ]...

  • Page 90: Password On Boot: (Security Menu)

    BIOS Utilities Password on boot: (Security Menu) Specify whether or not a password should be entered to boot the computer. If “En- abled” is selected, only users who enter a correct password can boot the system (see Password Warning the warning in the sidebar). The default setting is “Disabled”. If you set a boot pass- word (Password on boot Note: To clear existing passwords press Enter and type the existing password, then...

  • Page 91: Boot Menu

    BIOS Utilities Boot Menu Figure 5 - 5 PhoenixBIOS Setup Utility Boot Menu Main Advanced Security Exit Boot Item Specific Help Boot priority order: IDE 0: Optiarc CD-RW CRX880A-(PM) Keys used to view or IDE 4: FUJITSU MHV2100BH PL-(S1) configure devices: USB FDC: Up and Down arrows USB KEY:...

  • Page 92: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 6 PhoenixBIOS Setup Utility Exit Menu Main Advanced Security Boot Exit Exit Item Specific Help Exit Saving Changes Exit System Setup and Exit Discarding Changes save your changes to Load Setup Defaults CMOS. Discard Changes Save Changes Help...

  • Page 93: Upgrading The Computer

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- lined to make the desired upgrades. If you have any trouble or problems you can con- Warranty Warning tact your service representative for further help. Before you begin you will need: Please check with your service representative...

  • Page 94: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake upgrade proce- • Your system is still under warranty or a service contract dures, make sure that •...

  • Page 95: Removing The Battery

    Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Turn the computer off, and turn it over. Please check with your Slide the latch in the direction of the arrow.

  • Page 96: Upgrading The Hard Disk Drive

    Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page D - 3). Follow your Warning operating system’s installation instructions, and install all necessary drivers and util- ities (see...
  • Page 97 Upgrading The Computer Grip the tab and slide the hard disk in the direction of arrow Models A & B Model C Figure 6 - 3 HDD Slide Lift the hard disk up in the direction of arrow Remove the screws &...

  • Page 98: Upgrading The Optical (Cd/Dvd) Device

    Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn off the computer, and turn it over and remove the battery. Remove the HDD bay cover screws (Models A & B)/ (Model C). Remove the HDD bay cover Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Reverse the process to install the new device.

  • Page 99: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO- DIMM) DDRII (DDR2) type memory modules (see “Memory” on page D - 2 details of supported module types). The total memory size is automatically detected by the POST routine once you turn on your computer.
  • Page 100 Upgrading The Computer Remove the bay cover Figure 6 - 7 CPU/RAM Bay Cover Removed Models Model C A & B Contact Warning Be careful not to touch Gently pull the two release latches on the sides of the memory socket in the the metal pins on the direction indicated by the arrows ( &...
  • Page 101 Upgrading The Computer The RAM module will pop-up, and you can remove it. Figure 6 - 9 RAM Module Removal Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot.

  • Page 102: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a fast- Warranty er/new one you will need to contact your customer service representative. We rec- ommend that you do not do this yourself, since if it is done incorrectly you may The CPU is not a user damage the processor or mainboard.

  • Page 103: Modules & Options

    Modules & Options Chapter 7: Modules & Options Wireless Device Overview Operation Aboard This chapter contains information on the following modules, which may come with Aircraft your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.

  • Page 104: 802.11 B/G Usb Wlan Module

    Modules & Options 802.11 b/g USB WLAN Module If you have included an 802.11b/g USB WLAN module in your purchase option, Wireless Device you will have the appropriate software provided for your module. Operation Aboard Aircraft Before installing the 802.11b/g USB WLAN driver, make sure that the Wireless LAN module is on.

  • Page 105: Connecting To A Wireless Network

    Modules & Options Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then click Connect to a network (or right- click the icon , and then click Connect to a network). Figure 7 - 1 Taskbar Menus Click icon...
  • Page 106 Modules & Options Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network).
  • Page 107 Modules & Options To disconnect from the wireless network you can click the taskbar wireless icon , and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). Security Enabled Networks You should try to make...

  • Page 108: Windows Mobility Center

    Modules & Options Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).

  • Page 109: Bluetooth Module

    Modules & Options Bluetooth Module Before installing the Bluetooth driver, make sure that the optional Bluetooth mod- Wireless Device ule is on. Use the Fn + F12 key combination (see “Function Keys” on page 1 - Operation Aboard to toggle power to the Bluetooth module. Make sure you install the drivers in the Aircraft order indicated in Table 4 - 1, on page 4 -...
  • Page 110 Modules & Options User Guides & Help View BlueSoleil User Guides from the Help Menu (or press the F1 key) in the IVT Cor- poration BlueSoleil - Main Window control panel. Click the Help menu select Contents and Index. Look through Getting Started or select the ap- propriate User Guide...

  • Page 111: Pc Camera Module

    Modules & Options PC Camera Module Before installing the PC Camera driver, make sure that the optional PC Camera is on. Use the Fn + F10 key combination (see “Function Keys” on page 1 - 12) to Taking Still Pictures toggle power to the PC Camera module.

  • Page 112: Pc Camera Driver Installation

    Modules & Options PC Camera Driver Installation 1. Make sure the module is powered on (click Cancel if you see a “ New Hardware Found ” message ) , and then insert the Device Drivers & Utilities PC Camera Power + User’s Manual CD-ROM into the CD/DVD drive.

  • Page 113: Pc Camera Audio Setup

    Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
  • Page 114 Modules & Options Figure 7 - 8 Audio Setup for PC Camera Right-click 7 - 12 PC Camera Module...

  • Page 115: Bisoncap

    Modules & Options BisonCap BisonCap is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space Run the BisonCap application from the Start > Programs/All Programs > Bison- You may pre-allocate the Cam menu (it is recommended that you set the capture file before the capture file size for the capture file...

  • Page 116: Eliminating Screen Flicker

    Modules & Options Eliminating Screen Flicker If you find that the video screen in the BisonCap application is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select “Video Capture Filter...”. Click either 50Hz or 60Hz under Frequency in Property Page (tab).

  • Page 117: Pc Camera Hot Key Buttons

    Modules & Options PC Camera Hot Key Buttons (Model A & B Computers) You can use the PC Camera hot key buttons (the quick button utility must NOT be Snapshot Folder installed - see “Quick Button Utility” on page 4 - to run the BisonCap The Snapshot folder’s program, to take still pictures and to zoom the camera in and out (if you have in-...

  • Page 118: Fingerprint Reader Module

    Modules & Options Fingerprint Reader Module (Optional for Model B & C Computers) Help & Manual If you have included the fingerprint reader in your purchase option (Optional for Model B & C computers only) you will need to install the driver as per the instruc- Right-click the taskbar icon tions below.
  • Page 119 Modules & Options User Enrollment Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon On the first run of the program you will be asked to click the button to accept the license, and then click OK.
  • Page 120 Modules & Options Click the button above any of the fingers to begin the enrollment process for that finger. 10. Swipe the finger three times to enroll that finger. Fingerprint 11. Repeat the process for all the fingers you wish to enroll (see sidebar), and then Enrollment click Next.
  • Page 121 Modules & Options the Control Center etc. from the Protector Suite QL item in the Programs/All Programs menu. Figure 7 - 13 Control Center & Biomenu 17. See “Help & Manual” on page 7 - 17 for further details. 18. If you swipe your finger over the reader at any time you can access the Biomenu to lock the computer, register websites, open the Control Center and access the Help menu.
  • Page 122 Modules & Options 7 - 20...

  • Page 123: Troubleshooting

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 124: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 125: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.

  • Page 126: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.

  • Page 127: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 128 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 129: Problems And Possible Solutions

    Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 130 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
  • Page 131 Troubleshooting Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact your password. service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
  • Page 132 Troubleshooting Problem Possible Cause - Solution The CD/DVD tray will The CD/DVD is not correctly placed in the tray. Gently try to remove the disc using the eject hole not open when there is (see “Loading Discs” on page 2 - a disc in the tray.
  • Page 133 Troubleshooting Problem Possible Cause - Solution Wireless LAN/ The modules are off. Check the LED indicator and/or function key indicator to see if the Bluetooth modules WLAN/Bluetooth module is on or off (see “LED Indicators” on page 1 - 9). If the LED indicator is cannot be detected.

  • Page 134: Non Ddc Crt Monitors (For Win Vista Only)

    Troubleshooting Non DDC CRT Monitors (for Win Vista Only) If you are experiencing screen flicker problems (in Windows Vista ONLY) when using an older CRT (Non DDC) as your external display, you can install an updated driver to fix this problem. Follow the steps below: Uninstall the Original Driver Detach any connected external CRT.

  • Page 135: Screen Resolution Error

    Troubleshooting Screen Resolution Error If you are experiencing either screen resolution reduction, or screen flickering after resuming from Sleep in Windows Vista only (for NVIDIA Models B & C only) then follow the instructions below to fix this problem. This error arises in compliance with Windows Vista policy, which triggers TMM (Transient Multi-Manger) when the notebook lid (S3) is closed.
  • Page 136 Troubleshooting Double-click Task Scheduler Library > Microsoft > Windows. Click MobilePC to open the control panel. Right-click TMM and select Disable. Figure 8 - 2 - TMM Disable Close all the control panels. 8 - 14 Screen Resolution Error...

  • Page 137: Interface (Ports & Jacks)

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...

  • Page 138: Notebook Ports And Jacks

    Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.
  • Page 139 Interface (Ports & Jacks) Item Description RJ-11 Modem Jack This port connects to the built-in modem. You may plug the telephone line directly into this RJ-11 telephone connection. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. RJ-45 LAN Jack This port supports LAN (Network) functions.
  • Page 140 Interface (Ports & Jacks) A - 4...

  • Page 141: Via Video Driver Controls

    VIA Video Driver Controls Appendix B: VIA Video Driver Controls (Model A Computers) The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - VIA Video Driver Installation Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - Insert the Device Drivers &...

  • Page 142: B - 2 Advanced Video Controls

    VIA Video Driver Controls Advanced Video Controls This section is about making adjustments for the LCD, and switching display devic- Function Key es. The basic settings for configuring the LCD are outlined in “Video Features” on Combination page 1 - You can use the Fn + F7 key combination to Video Driver Controls...

  • Page 143: Attaching Other Displays

    VIA Video Driver Controls Attaching Other Displays Besides the built-in LCD, you can also use an external monitor (CRT)/flat panel dis- play as your display device. Connect it to the external monitor port on the right of the computer, and follow the instructions below: Windows Vista Attach your external display to the external monitor port and turn it on.
  • Page 144 VIA Video Driver Controls External displays may also be configured from S3Display tab in Advanced Display Settings : Attach the external display to the external monitor port and turn it on. Click Advanced Settings in the Display Settings control panel (see “Video Features”...

  • Page 145: Display Modes

    VIA Video Driver Controls Display Modes Single Display Only one of your attached displays is used. Mirrored This display mode simply shows an exact copy of the Primary display desktop on the Secondary display(s). Extended Desktop An Extended desktop allows the desktop to span the displays to act as a large work area, thus creating a lot more screen area for display.
  • Page 146 VIA Video Driver Controls Using Windows Vista to Enable Extended Mode Attach your external display to the external monitor port, and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Display Settings Windows Mobility Center control panel (Mobile PC >...
  • Page 147 VIA Video Driver Controls Using Display Settings to Enable Extended Mode Attach your external display to the external monitor port, and turn it on. Open the Display Settings control panel (see “Video Features” on page 1 - 18). Click the monitor icon (e.g. ), and make sure you have checked “Extend my Windows desktop onto this monitor.”...

  • Page 148: Non Ddc Crt Monitors (For Win Vista Only

    VIA Video Driver Controls Non DDC CRT Monitors (for Win Vista Only) If you are experiencing screen flicker problems (in Windows Vista ONLY) when us- ing an older CRT (Non DDC) as your external display, you can install an updated driver to fix this problem.

  • Page 149: Nvidia Video Driver Controls

    NVIDIA Video Driver Controls Appendix C: NVIDIA Video Driver Controls (Model B & C Computers) The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Resolution Error NVIDIA Video Driver Installation If you are experiencing screen resolution prob-...

  • Page 150: C - 2 Nvidia Control Panel

    NVIDIA Video Driver Controls NVIDIA Control Panel More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Open the Display Settings (see page 18) control panel. To access the Ge- Click Advanced Settings (button). Force control Click GeForce Go 7300 (tab).
  • Page 151 NVIDIA Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and tools which allows quick access to features such as display configuration, 3D Set- tings and Help menus etc. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.
  • Page 152 NVIDIA Video Driver Controls The Help menus provide index and search features, and direct links to the NVIDIA website etc. Figure C - 3 Help Menus C - 4 NVIDIA Control Panel...

  • Page 153: Attaching Other Displays

    NVIDIA Video Driver Controls Attaching Other Displays Configuring an External Display in Windows Vista Display Devices Attach your external display to the external monitor port and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Besides built-in Windows Mobility Center control panel (Mobile PC >...
  • Page 154 NVIDIA Video Driver Controls Configuring an External Display using the NVIDIA Control Panel Attach your external display to the external monitor port and turn it on. Go to NVIDIA Control Panel (see “NVIDIA Control Panel” on page B - Function Key Click Display, and then click Change Display configuration.

  • Page 155: Display Modes

    NVIDIA Video Driver Controls Display Modes Single Display Mode Only one of your displays is used. Clone Mode Clone Mode simply shows an exact copy of the Primary display desktop on the other display(s). This mode will drive multiple displays with the same content. Dualview Mode Dualview Mode treats both connected displays as separate devices, and they act as a virtual desktop resulting in a large workspace.
  • Page 156 NVIDIA Video Driver Controls Using New Display Detected to Enable Extended Mode Attach your external display to the external monitor port and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Windows Mobility Center control panel (Mobile PC >...
  • Page 157 NVIDIA Video Driver Controls Using Display Settings to Enable Extended Mode Attach your external display to the external monitor port and turn it on. Click Start, and click Control Panel (or point to Settings and click Control Display Settings Panel). Extended Desktop Click Adjust screen resolution under the Appearance and Personalization menu (or double-click Personalization >...
  • Page 158 NVIDIA Video Driver Controls C - 10...

  • Page 159: Specifications

    Specifications Appendix D: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, delayed or updated due to the manufacturer's release schedule. Check with your service center for details.

  • Page 160: Processor

    Specifications Feature Specification Processor Intel® Core™2 Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package 4MB On-die L2 Cache & 667MHz FSB T7200/ T7400/ T7600 2.0/ 2.16/ 2.33 GHz Intel® Core™2 Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package 2MB On-die L2 Cache &...

  • Page 161: Lcd

    Specifications Feature Specification Models A & B Model C 15.4" WXGA (1280 * 800) TFT LCD 17.0" WXGA (1440 * 900) TFT LCD 15.4‘” WSXGA+ (1680 * 1050) TFT LCD 17.1" WSXGA+ (1680 * 1050) (for Model B Computers Only) 17.1"...

  • Page 162: Audio

    Specifications Feature Specification Audio Integrated AZALIA Compliant Interface (HDA) 3D Stereo Enhanced Sound System Sound-Blaster PRO™ Compatible 2 * Built-In Speakers Built-In Microphone Keyboard & Winkey Keyboard Built-In TouchPad with Scrolling Function Pointing Device Interface Three USB 2.0 Ports One External Monitor Port One RJ-11 Modem Jack One Headphone-Out Jack One RJ-45 LAN Jack...

  • Page 163: Power

    Specifications Feature Specification Power Supports ACPI 2.0 and PCI Bus Power Battery Low Suspend Management Management 1.1 Compliant Supports Wake on LAN Power Models A & B Model C Full Range AC/DC Adapter AC input 100 - 240V, Full Range AC/DC Adapter AC input 100 - 240V, 50 - 60Hz, DC Output 19V, 3.42A (65 Watts) OR 50 - 60Hz, DC Output 19V, 4.74A (90 Watts) 18.5V, 3.5A (65 Watts)
  • Page 164 Specifications D - 6...

  • Page 165: Windows Xp Information

    Windows XP Information Appendix E: Windows XP Information This Appendix contains information (including control panel information, driver in- Model C Computers stallation etc.) for users of the Windows XP OS. Note that Model C com- puters do not support the audio record or cam- era zoom hot keys func- tions.

  • Page 166: E - 2 Dvd Regional Codes

    Windows XP Information DVD Regional Codes Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialogue box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code.

  • Page 167: Windows Xp Start Menu & Control Panel

    Windows XP Information Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 168: E - 4 Touchpad And Buttons/Mouse

    Windows XP Information TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. Once you have installed the TouchPad driver (see “TouchPad”...

  • Page 169: Function Keys/Hot Keys

    Windows XP Information Function Keys/Hot Keys The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key Application Note is held down. Table 2 - 2, on page 2 - 10 gives details of function key combinations, hot key buttons and visual indicators (for Model A &...

  • Page 170: Application Quick Buttons

    Windows XP Information Application Quick Buttons Note that the application quick button utility is designed to allow use of the hot key Application.exe buttons in absence of the optional PC Camera (the quick button utility will only ap- pear if no PC Camera is installed). You will need to install the Quick Button Util- You will need to locate ity (see “Quick Button Utility”...

  • Page 171: Recording Audio

    Windows XP Information Recording Audio (Model A & B Computers) audio record hot key button allows you to record audio from either the built-in microphone, or from a microphone connected to the microphone-in jack. To record on the computer, setup the audio recording options in Windows as follows (see Figure E - 5 on page E - Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double-...
  • Page 172 Windows XP Information Figure E - 5 Audio Setup for Recording (Windows XP) E - 8 Recording Audio...

  • Page 173: Audio Features

    Windows XP Information Audio Features You can configure the audio options on your computer from the Sounds and Audio Sound Volume Devices Windows control panel, or from the VIA Audio Deck icon in the Adjustment taskbar, or on the desktop (this will bring up the VIA Audio Deck menu). The vol- ume may also be adjusted by means of the Fn + F5/F6 key combination.

  • Page 174: Video Features

    Windows XP Information Video Features This computer features two different video (either VIA for Model A or NVIDIA for Model B & C Computers) options (see “Video Adapter” on page D - 3 for details). You will be provided with an appropriate driver on the Device Drivers &...

  • Page 175: Advanced Video Controls

    Windows XP Information Advanced Video Controls This section is about making adjustments for the LCD, and switching display devic- Function Key Combination You can use the Fn + Video Driver Controls F7 key combination to The video interface lets you change the screen resolution and color output to what- toggle through the dis- ever is most comfortable/efficient for you.

  • Page 176: E - 12 Via Video Driver Controls

    Windows XP Information VIA Video Driver Controls (Model A Computers) VIA S3Tray Plus Utility The S3Tray Plus utility will appear in the taskbar when the video driver is installed. Click/Right-click the icon to bring up the menu below. From this menu you will also be able to make display adjustments, access the Display Properties control panel, Figure E - 8 check video memory information etc.

  • Page 177: Via S3 Display Control Panels

    Windows XP Information VIA S3 Display Control Panels Right-click the S3Tray Plus utility in the taskbar to bring up the menu for the individual control panels, or access the menus from the Advanced tab in the Display Help Menus Properties control panel. Right-click on almost any item in the tabs to bring up the “What’s...

  • Page 178: Display Devices (Via

    Windows XP Information Display Devices (VIA) Besides the built-in LCD, you can also use an external monitor (CRT)/flat panel dis- S3Tray Plus Utility play as your display device. Connect it to the external monitor port on the right of the computer.

  • Page 179: Display Modes (Via

    Windows XP Information Display Modes (VIA) Single Display Playing DVD Videos Only one of your attached displays is used. If you want to play a DVD video in a multiple Multiple Monitors monitor mode, then This display mode simply shows an exact copy of the Primary display desktop on choose EITHER the Secondary display(s).

  • Page 180: To Enable Extended Desktop (Display Properties

    Windows XP Information To Enable Extended Desktop (Display Properties) 1. Attach the external display to the external monitor port and turn it on. 2. Go to the Display Properties control panel (see “Video Features” on page E - Display Settings and click Settings (tab).

  • Page 181: Nvidia Video Driver Controls

    Windows XP Information NVIDIA Video Driver Controls (Model B & C Computers) Taskbar Icon More advanced video configuration options are provided in the GeForce Go 7300 control panel tab. Click the NVIDIA task- bar icon then click Open the Display Properties (see “Video Features”...

  • Page 182: Additional Properties (Nvidia

    Windows XP Information Additional Properties (NVIDIA) The items listed in the Additional Properties window allow you to configure your display(s). If the items do not display, you can either click the Additional Properties button, or the icon . Figure E - 13 Additional Properties Click pin icon to push pin in...
  • Page 183 Windows XP Information You may make changes to the Display Settings, Color Correction, Video Overlay, Resolutions, Refresh Rates and Screen Rotation by clicking the appropriate tab and adjusting the setting. Help Menus Right-click on many of the items in the tabs to bring up the “What’s This?”...

  • Page 184: Nvidia Nview Desktop Manager

    Windows XP Information NVIDIA nView Desktop Manager The nView Desktop Manager allows quick access to control panels for features such as Desktop Management, Profiles, Hot Keys etc. The Control panel may be ac- nView Desktop Manager from cessed as follows. Additional 1.

  • Page 185: Display Devices (Nvidia

    Windows XP Information Display Devices (NVIDIA) Besides the built-in LCD, you can also use an external monitor/flat panel display as Function Key your display device. The following are the display options: Combination The built-in LCD. You can use the Fn + An external monitor connected to the external monitor port.

  • Page 186: Display Modes (Nvidia

    Windows XP Information Display Modes (NVIDIA) Single Display Mode Only one of your displays is used. Clone Mode Clone Mode simply shows an exact copy of the Primary display desktop on the other display(s). This mode will drive multiple displays with the same content and each display device can be configured independently. Dualview Mode Dualview Mode treats both connected displays as separate devices (unlike Horizontal/Vertical Span mode) act- ing as a virtual desktop, resulting in a large workspace.

  • Page 187: Attaching Other Displays (Nvidia

    Windows XP Information Attaching Other Displays (NVIDIA) Connect any external display to the external monitor port on the right of the computer. Detect Displays Attach your external display to the external monitor port and turn it on. Click Detect Displays Go to Additional Properties in the GeForce Go 7300 control panel tab.

  • Page 188: E - 24 Power Management Features

    Windows XP Information Power Management Features To conserve power, especially when using the battery, your computer uses the ACPI OS Note power management system. Power management conserves power by controlling in- dividual components of the computer (the monitor and hard disk drive) or the whole Power management functions...

  • Page 189: The Power Sources

    Windows XP Information The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/DC adapter will damage the computer and its components.

  • Page 190: E - 26 Turning On The Computer

    Windows XP Information Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shutdown er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Stand by/Hibernate/ ways shut your comput- er down by choosing the Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and...

  • Page 191: Power Schemes

    Windows XP Information Power Schemes You can set your computer to conserve power through individual components by Resuming means of Power Schemes. You can also adjust the settings for each scheme to set Operation the monitor to turn off after a specified time, and the computer's hard disk motor to turn off if the hard disk drive has not been accessed for a specified period of time (if Press a key on the key- the system reads or writes data, the hard disk motor will be turned back on).
  • Page 192 Windows XP Information Each Windows Power Scheme will also adjust the processor performance of your machine in order to save pow- er. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.

  • Page 193: Hibernate Mode Vs. Shutdown

    Windows XP Information System Power Options You can use the system power options to stop the computer’s operation and restart Stand by/Hibernate where you left off. This system features Stand by and Hibernate sleep mode levels or Shutdown Error (Hibernate mode will need to be enabled by clicking the option in the Hibernate tab in the Power Options control panel - see “Hibernate”...

  • Page 194: Stand By

    Windows XP Information Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle System Resume at its slowest speed.

  • Page 195: Configuring The Power Button

    Windows XP Information Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hiber- Sleep Button nate mode. In Stand by mode, the LED will blink green. In Hibernate mode the LED will be off (battery) or orange (AC/DC adapter).

  • Page 196: Battery Information

    Windows XP Information Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery New Battery Warning Always completely discharge, then fully charge, a new battery (see “Battery FAQ” When the battery is criti- on page E - 35 for instructions on how to do this).

  • Page 197: Recharging The Battery With The Ac/Dc Adapter

    Windows XP Information Battery life may be shortened through improper maintenance. To optimize the life and improve its perfor- mance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you need to remove the battery for any reason, “Removing the Battery”...

  • Page 198: Proper Handling Of The Battery Pack

    Windows XP Information Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.

  • Page 199: Battery Faq

    Windows XP Information Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t Caution turn off the computer by yourself even when you see a message that indicates the bat- Danger of explosion if tery is critically low, just let the computer use up all of the battery power and shut battery is incorrectly re-...

  • Page 200: E - 36 Driver Installation

    Windows XP Information Driver Installation Check the driver installation order from Table E-E - (all the drivers must be installed in this order) This section covers driver and utility installation instruc- which is the same as that listed in the Drivers tions for Windows XP Home &...
  • Page 201 Windows XP Information Installation Methods (Win XP) If you wish to install the drivers manually, click the Exit button to quit the Drivers Installer application, and then browse to the executable file in the location listed in the table below and follow the installation procedure for each driver.

  • Page 202: Updating/Reinstalling Individual Drivers

    Windows XP Information Updating/Reinstalling Individual Drivers If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do this go Windows XP Service Pack 2 to the Control Panel in the Windows OS and double- Make sure you install Windows XP Service Pack 2 (or a click the Add/Remove Programs item.

  • Page 203: Service Pack Information

    Windows XP Information New Hardware Found Video If you see the message “New Hardware Found” VIA (Model A) (Found New Hardware Wizard) during the installa- 1. Click 2.Install Video Driver > Yes. tion procedure (other than when outlined in the driver 2.

  • Page 204: Audio

    Windows XP Information Audio Hot Key Utility (Model A & B Computers) 1. Click 4.Install Audio Driver > Yes. 1. Click 8.Install Hotkey Utility > Yes. 2. Click Next > Next > Next. 2. Click Next > Install. 3. Click Finish to restart the computer. 3.

  • Page 205: 802.11 B/G Usb Wlan Module

    Windows XP Information 802.11 b/g USB WLAN Module If you have included an 802.11b/g USB WLAN module in your purchase option, you Wireless Device will have the appropriate software provided for your module. Operation Aboard Aircraft Before installing the 802.11b/g USB WLAN driver, make sure that the Wireless LAN module is on.
  • Page 206 Windows XP Information Network Connection Use the Windows Net- work Connections con- trol panel access available wireless net- works (Start > Settings > Network Connections or Start > Connect To > Show all Connections). Figure E - 25 Wireless Network Control Panels E - 42 802.11 b/g USB WLAN Module...

  • Page 207: Bluetooth Module

    Windows XP Information Bluetooth Module Before installing the Bluetooth driver, make sure that the optional Bluetooth module Wireless Device is on. Use the Fn + F12 key combination (see “Function Keys” on page 1 - 12) to Operation Aboard toggle power to the Bluetooth module. Make sure you install the drivers in the or- Aircraft der indicated in Table 4 - 1, on page 4 -...
  • Page 208 Windows XP Information User Guide View the BlueSoleil User Guides (Contents and In- dex) from the Help menu (or press the F1 key) in Corporation BlueSoleil - Main Win- dow control panel. Click BlueSoleil User Guides in the Contents tab, and click to select the appro- priate User Guide from the panel on the right.
  • Page 209 Windows XP Information Bluetooth Local Area Connection Icon If you want to display the Local Area Connection icon for the Bluetooth connection in the taskbar, set it up as follows: Disconnecting Access the Network Connections control panel in Windows (Start > Settings > In order to have the taskbar Network Connections OR Start >...
  • Page 210 Windows XP Information Use the Fn + F12 key combination to turn on the Bluetooth module. Run the IVT Corporation BlueSoleil program from the desktop icon or Start menu. The connection status will then be displayed. Figure E - 28 - Bluetooth Connected To disconnect click File from the IVT Corporation BlueSoleil - Main Window, and select Exit (the Local Area Connection will then display “A network cable is unplugged”).

  • Page 211: Pc Camera Module

    Windows XP Information PC Camera Module Before installing the PC Camera driver, make sure that the optional PC Camera is on. Use the Fn + F10 key combination (see “Function Keys” on page 1 - 12) to Taking Still Pictures toggle power to the PC Camera module.

  • Page 212: Pc Camera Driver Installation

    Windows XP Information PC Camera Driver Installation 1. Make sure the module is powered on (click Cancel if you see a “ New Hard- ware Found ” message ) , and then insert the Device Drivers & Utilities + Stand by/Hibernate or Shutdown Error User’s Manual CD-ROM into the CD/DVD drive.

  • Page 213: Pc Camera Audio Setup

    Windows XP Information PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows (see Figure E - 30 on page E - 50). Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double- click the Sounds &...
  • Page 214 Windows XP Information Figure E - 30 Audio Setup (Windows XP) E - 50 PC Camera Module...

  • Page 215: Bisoncap

    Windows XP Information BisonCap BisonCap is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space Run the BisonCap application from the Start > Programs/All Programs > Bison- You may pre-allocate the Cam menu (it is recommended that you set the capture file before the capture file size for the capture file...

  • Page 216: Eliminating Screen Flicker

    Windows XP Information Eliminating Screen Flicker If you find that the video screen in the BisonCap application is flickering, you can try to adjust the setting in the Video Capture Filter options. 1.Run the BisonCap program. 2.Go to Options and scroll down to select “Video Capture Filter...”. 3.Click either 50Hz or 60Hz under Frequency in Property Page (tab).

  • Page 217: Pc Camera Hot Key Buttons

    Windows XP Information PC Camera Hot Key Buttons (Model A & B Computers) You can use the PC Camera hot key buttons (the quick button utility must not be in- Snapshot Folder stalled - see “Quick Button Utility” on page E - to run the BisonCap The Snapshot folder’s program, to take still pictures and to zoom the camera in and out (if you have installed...

  • Page 218: Fingerprint Reader

    Windows XP Information Fingerprint Reader (Optional for Model B & C Computers) Help & Manual If you have included the fingerprint reader in your purchase option (for Model B and C computers only) you will need to install the driver as per the instructions below. Right-click the taskbar icon to bring up the menu to Make sure you have administrator’s rights to your computer, and have a Windows...

  • Page 219: User Enrollment

    Windows XP Information User Enrollment Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon On the first run of the program you will be asked to click the button to accept the license, and then click OK. Click Next and select “Enrollment to the hard disk”, and click Finish.
  • Page 220 Windows XP Information 10. Click Finish > Close. 11. Right-click the taskbar icon to bring up the menu that allows you to Edit Fingerprints, start Control Center, access the Help menu etc. You can also run the Control Center etc. from the Protector Suite QL item in the Programs/All Programs menu.

Table of Contents
