Summary of Contents for Zte MF28B
-
Page 2: Inserting Sim Card
Open the protective cover of the SIM port shown below and insert the SIM card. Power Switch Note: Please power off the MF28B router and remove the external power adapter before removing or inserting the SIM card. If not, the router or SIM card may be damaged. - Page 3 Appearance USB Port WPS Button LED Indicators SIM Port Interface Indicator Description SIM Port Where the SIM card is inserted. LED Indicators To indicate the status of the device. To connect with an external storage device or USB Port USB shared printer. Contains RJ45 interfaces (LAN1/WAN, and Interface LAN2 ~ LAN4), power switch, reset switch,...
-
Page 4: Interface Description
Interface Description For Ethernet connections or ADSL/cable 1 LAN1/WAN modem connection. 2 LAN2~LAN4 For Ethernet connections. 3 ON/OFF To turn the router ON or OFF. To restore the router to the factory default 4 Reset Switch settings by holding for 7 seconds. 5 Power Socket To connect to the external power supply. -
Page 5: Led Indicator
LED Indicator Indicator State Description Blue Registered to LTE network 1 Mobile Network Green Registered to 4G network Not Registered Mobile network connection Always ON established 2 Mobile Network Mobile network connection is connection Blinking establishing status Mobile network connection not established Signal strength is very good or Always ON... -
Page 6: Connecting To The Internet Via Wi-Fi
Scan for available wireless networks using the normal Wi-Fi application of your Wi-Fi device. Select the SSID of your MF28B router, and connect to it (The default SSID and Wi-Fi password can be found on the label found on the MF28B router box). Wait approximately 30 seconds for the connection to establish. - Page 7 Opera (10.0 or later), Safari (4.0 or later) or Chrome (10.0 or later). When the login page appears as follows, input the password (The default password is admin). Please refer to your MF28B User Manual for configuration options and instructions.
