FRONT WHEEL SECONDARY
RETENTION DEvICES
Your stroller fork utilizes secondary
wheel retention devices designed to
help keep the wheel from
disengaging from the fork if the quick
release is incorrectly adjusted and
tightened. The wheel can still remain
loose and wobbly even with the
secondary retention device working if
the quick release has not been
properly tightened and adjusted. The
secondary retention devices are
backup systems and are not intended
as a substitute for a properly
adjusted quick release. The
secondary retention devices on your
stroller are the integral type that are
formed into the outer faces of the
fork dropouts.
(Secondary Retention Devices)
retention devices serve as a backup
for a critical adjustment. The
secondary retention devices can
reduce the risk of the wheel
disengaging from the fork if the
quick release is not adjusted and
tightened correctly.
Secondary retention devices are
not a substitute for correct quick
release adjustment and tightening.
Dropouts
The secondary
Using your stroller with an
improperly adjusted and tightened
wheel quick release can allow
the wheel to vibrate, wobble or
become detached from the stroller.
This can result in serious injury or
death.

FRONT WHEEL INSTALLATION

1. Rotate Quick Release Lever
Rotate quick release lever so that it
curves away from the wheel. This
places it in the FULLY OPEN position.
Quick Release Lever
FULLY OPEN
2. Insert Front Wheel
When facing the front of the stroller,
insert the wheel between the fork
dropouts so that the axle firmly con-
tacts the top of the slots of the fork
dropouts.
Dropout
3. Adjust Quick Release Lever
To adjust the quick release, hold
the quick release cam lever in the
FULLY OPEN position with your right
hand as shown. Tighten the tension
adjusting nut with your left hand
until it is finger tight against the fork
dropout.
FULLY CLOSED
