BOB Gear Revolution SE Owner's Instruction Manual

Hide thumbs Also See for Revolution SE:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
®
BOB Gear
by Britax (03) 9288-7288
www.britax.com.au
99 Derby Road, Sunshine, Victoria 3020
REVOLUTION STROLLER
SE, CE and STROLLER STRIDES , FLEX, PRO
ENGLISH
Owner's Instruction Manual
TAKE TIME
READ AND UNDERSTAND THESE
INSTRUCTIONS COMPLETELY!
Before attempting to assemble or use your
new stroller, read and understand these
assembly and use instructions completely,
as well as the warnings at the beginning
and throughout this document, to ensure
proper assembly and operation.
If you are unclear on any point, contact
BRITAX CUSTOMER SERVICE
1300 303 330
For more information, please visit www.britax.com.au
OMB15/B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Revolution SE and is the answer not in the manual?

Questions and answers

Related Manuals for BOB Gear Revolution SE

Summary of Contents for BOB Gear Revolution SE

  • Page 1 ® BOB Gear by Britax (03) 9288-7288 www.britax.com.au 99 Derby Road, Sunshine, Victoria 3020 REVOLUTION STROLLER SE, CE and STROLLER STRIDES , FLEX, PRO ENGLISH Owner’s Instruction Manual TAKE TIME READ AND UNDERSTAND THESE INSTRUCTIONS COMPLETELY! Before attempting to assemble or use your...

  • Page 2: Warnings

    WARNINGS FAILURE TO FOLLOW THESE WARNINGS AND ASSEMBLY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. • Never pull stroller backward up Retain for future reference. Read all stairs. Doing so could damage the instructions carefully before assembly suspension system, leading to frame and use of this stroller.
  • Page 3 • Never leave child in the stroller unattended with or without the SAFETY WARNING parking brake set. • The sun is very strong. DO NOT • Never load or unload the stroller without the parking brake set. LEAVE YOUR CHILD EXPOSED TO • The maximum weight capacity of THE SUN.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS WARNINGS Page 2 TABLE OF CONTENTS Page 4 STROLLER ANATOMY Page 5 AGE RECOMMENDATIONS Page 6 STROLLER ASSEMBLY Page 6 Unpack Stroller Page 6 Wheels Page 6 Adjust Quick Release Page 7 Rear Wheel Installation Page 7 Removing Rear Wheel Page 8 Front Wheel Secondary Retention Devices...

  • Page 5: Stroller Anatomy

    STROLLER ANATOMY REVOLUTION STROLLER SE, CE and STROLLER STRIDES Hand Brake (PRO model only) Adjustable Canopy Handlebar (FLEX & PRO Models) Handlebar Release Lever Seat Harness Shock Release Knob Swivel Knob Swing Arm Tracking Knob Drum Brake (PRO model only) Low Boy Quick Release Lever...

  • Page 6: Age Recommendations

    AGE RECOMMENDATIONS WHEELS Before attempting to install wheels, BOB recommends that your child read and understand warnings and should be at least 8 weeks old before instructions completely. riding in a BOB stroller without a BOB Infant Car Seat Adapter and Using your stroller compatible infant car seat.

  • Page 7: Adjust Quick Release

    2. Rotate Quick Release Lever ADJUST QUICk RELEASE Rotate the quick release lever so it The rear wheels are correctly curves away from the dropout. clamped in place by the force generated when the quick release Tension Adjusting Nut lever is closed and the cam action pulls the axle against the dropout, securing it in place.

  • Page 8: Removing Rear Wheel

    To TIGHTEN tension adjusting nut, If the quick release lever cannot turn clockwise. be rotated to the FULLY CLOSED position, rotate the lever to the FULLY OPEN position and turn the FULLY CLOSED tension adjusting nut a quarter turn counterclockwise. Repeat the closing process.

  • Page 9: Front Wheel Secondary Retention Devices

    Using your stroller with an FRONT WHEEL SECONDARY improperly adjusted and tightened RETENTION DEvICES wheel quick release can allow the wheel to vibrate, wobble or Your stroller fork utilizes secondary become detached from the stroller. wheel retention devices designed to This can result in serious injury or help keep the wheel from death.

  • Page 10: Removing Front Wheel

    Rotate the lever to the FULLY Tension Adjusting Nut OPEN position and turn the tension adjusting nut a quarter turn clockwise and repeat the closing process. If the quick release lever cannot Quick Release Lever be rotated to the FULLY CLOSED 4.

  • Page 11: Unfold Stroller

    UNFOLD STROLLER Care must be taken when folding and unfolding the stroller to prevent finger entrapment or injury. To avoid injuries, never fold or unfold stroller with other individuals or children within reach of stroller. 1. Open the wrist strap 3.

  • Page 12: Stroller Adjustments

    Handlebar 8. Make It Smaller 5. Lift Red Frame Release Handle Take off the front and rear wheels to Using a short, quick tug, lift red frame make it even smaller. See Removing release handle up. Keep tires on Rear Wheel and Removing Front ground as stroller collapses toward Wheel sections.

  • Page 13: Check Tire Pressure

    1. Empty Stroller WALK MODE JOG MODE Remove contents from low boy cargo basket and pockets. 2. Check Tire Pressure 3. Set Stroller to Jog Mode SNAP Slide swivel knob to right. Knob will slide into downward position. Rotate fork/wheel until it “snaps” into CHECk TIRE PRESSURE forward position.

  • Page 14: Select Shock Setting

    If your stroller pulls LEFT, turn tracking knob counterclockwise up to 2. Set Shock Setting To Position 2 Depress shock release knob and one half turn. simultaneously pull toward back of stroller, sliding knob into position 2. Knob will “snap” into place when in correct position.

  • Page 15: Secure Child In Seat

    is not designed as a stopping SECURE CHILD IN SEAT brake. The brake should not be used to slow or stop the stroller The maximum because doing so could cause the weight capacity of the stroller is 25 stroller to stop abruptly, resulting kgs (occupant plus luggage in loss of control.

  • Page 16: Attach Wrist Strap

    ATTACH WRIST STRAP The wrist strap is designed to help prevent the stroller from rolling away should you lose your grip on the stroller. When using the stroller, make sure the strap is securely looped over Crotch Strap Buckle your wrist. 4.

  • Page 17: Position Canopy

    POSITION CANOPY Seat Recline Buckle 1. Extend Canopy Rotate canopy away from handlebar for additional shade. Seat Recline Strap 2. Return To Upright Position To raise seat, lift seat back with one 2. Retract Canopy hand and pull recline strap down with Push canopy toward handlebar.

  • Page 18: Adjustable Handle (Flex & Pro Model)

    Attaching BOB accessories is simple HANDBRAkE SYSTEM and easy with this push button, lock (PRO MODELS) and release design. The accessory adapter also allows for many accessories to remain attached when Brake Lever the stroller is folded. See Stroller Accessories section of this manual for more information on all available accessories.

  • Page 19: Establish Correct Function

    ESTABLISH CORRECT FUNCTION loosen the cable, loosen lock ring and turn the barrel adjuster in a For the hand brake system to work clockwise direction. Secure the barrel correctly, it is critical that it be adjuster by tightening the lock ring adjusted properly.

  • Page 20: Rear Wheel Installation (Pro Model)

    REAR WHEEL INSTALLATION (PRO MODEL) Follow steps 1 and 2 from (REAR WHEEL INSTALLATION) section on page 7. 3. Insert Rear Wheel Stub Axle Insert the rear wheel’s stub axle into NOTE: Ensure that all brake cable the hole in the rear wheel attachment ends are properly located in the rel- bracket.

  • Page 21: Removing Rear Wheel (Pro Model)

    Rear Wheel Retention Button IMPORTANT: Ensure there is a click upon fully inserting the wheel. If no click is heard, there is a possibility that the wheel is not secure in the attachment bracket and it may fall off during operation. REMOvING REAR WHEEL (PRO MODEL) Follow steps 1 and 2 from...

  • Page 22: Care And Maintenance

    CARGO The stroller is equipped with two small seat pockets for your child, a seat back pocket and a low boy cargo basket under the stroller. Adding weight to the seat back changes the center of gravity of the stroller, and increases the possibility that it might tip over backwards, resulting in injury.
  • Page 23 WEATHER SHIELD The Weather Shield’s water resistant design helps to protect your child from rain and wind while still allowing a view of the world. INFANT CAR SEAT ADAPTER The BOB Infant Car Seat Adapter allows you to easily attach the Britax or Safe N Sound infant car seat model to a BOB Stroller utilizing the BOB Accessory Adapter feature.
  • Page 24 BOB, BOB Strollers, Stroller Strides, Revolution, BOB Gear and the BOB device are the property of Britax Childcare Holding Limited (UK) ® BOB Gear by Britax BRITAX CHILDCARE PTY, LTD. A Britax international company. (Incorporated in Victoria) A.B.N.55 006 773 600...
