WALK MODE

CHECk TIRE PRESSURE

Plastic wheels are rated to a
maximum tire inflation pressure of
30 pounds per square inch (psi) or
206.8 kilo pascal (kpa). The maximum
inflation pressure is embossed on the
wheel next to the valve stem.
30 psi can damage the wheel and/
or tire resulting in loss of control
and injury.
Aluminum wheels can have the tires
inflated to the pressure embossed on
the tire. However, we recommend 30
psi for a comfortable ride.
the maximum inflation pressure
embossed on the tire can damage
rim and or tire resulting in loss of
control and injury.

ADJUST TRACkING

If stroller pulls left or right when the
front wheel is in jog mode and
stroller is on flat terrain, adjust
tracking as outlined in the following
steps.
with a child or any occupant in the
stroller.
JOG MODE
SNAP
Inflating tires above
Inflating tires above
Do not roll test
1. Empty Stroller
Remove contents from low boy cargo
basket and pockets.
2. Check Tire Pressure
3. Set Stroller to Jog Mode
Slide swivel knob to right. Knob will
slide into downward position. Rotate
fork/wheel until it "snaps" into
forward position. See Choose Walk
or Jog Mode section.
4. Place Stroller On Level Ground
Find a stretch of level ground about
5 meters.
5. Align Rear Wheel Axles
Align stroller so rear wheel axles are
perpendicular to a straight line.
6. Test Alignment
Push stroller straight forward and
release to see if stroller veers right or
left. Repeat push test several times.
If stroller consistently pulls to left or
right, proceed to Fine Tune Tracking.

FINE TUNE TRACkING

If Stroller Pulls LEFT
5 mtrs
