TECHNICAL SPECIFICATIONS

Wheel nut torque
Wheel type
All
Tyre pressures (cold tyres)
Bus
Tyre Pressures
Variant
280S
280S
280S
350L - Maximum front
axle weight 1750 kilo-
grams (3868 pounds)
350L - Maximum front
axle weight 1850 kilo-
grams (4079 pounds)
370L
410EF/M2
410EF/M2
Transit (TT9) Vehicles Built From: 26-09-2011, Vehicles Built Up To: 31-12-2013
Wheels and Tyres
Front
Tyre Size
(lbf/in²)
185/75 R 16 C 3 (44)
195/70 R 15 C 3 (44)
205/65 R 16 C 2.8 (41)
215/75 R 16 C 3.5 (51)
215/75 R 16 C 3.8 (55)
215/75 R 16 C 3.8 (55)
185/75 R 16 C 4.7 (68)
195/75 R 16 C 4.6 (67)
162
Nm (Ib-ft)
200 (147.5)
Normal Load
Rear
bar bar
(lbf/in²)
3 (44)
3 (44)
2.8 (41)
4.8 (70)
4.8 (70)
4.8 (70)
4.1 (60)
3.7 (54)
Full Load
Front Rear
bar bar
(lbf/in²) (lbf/in²)
3.8 (55) 4.1 (60)
3.6 (52) 3.9 (57)
3.4 (49) 3.7 (54)
3.5 (51) 4.8 (70)
3.8 (55) 4.8 (70)
3.8 (55) 4.8 (70)
4.7 (68) 4.1 (60)
4.6 (67) 3.7 (54)
