Summary of Contents for Ford TourneoConnect

  • Page 1 FordT ourneoConnect Feel the difference FordTransitConnect Owner's handbook...
  • Page 2 This publication, or part thereof, may not be reproduced nor translated without our approval. Errors and omissions excepted. © Ford Motor Company 2007 All rights reserved. Part number: 8T1J-19A321-DA (CG3526en) 11/2007 20071108144749...

  • Page 3: Table Of Contents

    Table of contents Introduction Coded keys........30 Arming the engine immobiliser..31 About this handbook......5 Disarming the engine Symbols glossary......5 immobiliser........31 Parts and accessories......5 Alarm Quick start Principle of operation.....32 Quick start..........6 Arming the alarm......32 Disarming the alarm......32 Child safety Child seats........12 Steering wheel Booster cushions......13 Adjusting the steering wheel..33...
  • Page 4 Table of contents Electric exterior mirrors....48 Map pockets........77 Interior mirror........48 Seat back trays........77 Rear quarter windows....49 Auxiliary input (AUX IN) socket..77 Instruments Starting the engine Gauges..........50 General information......78 Warning lamps and indicators..51 Ignition switch........78 Audible warnings and Starting a petrol engine....78 indicators........54 Starting a diesel engine....80 Switching off the engine....80...
  • Page 5 Table of contents Parking aid Towing the vehicle on four wheels.........103 Principle of operation.....90 Using the parking aid......90 Maintenance General information......104 Load carrying Opening and closing the General information......91 bonnet.........105 Roof racks and load carriers..91 Engine compartment overview - Cargo nets........92 1.8L Duratec-DOHC (Zetec)..106 Engine compartment overview - 1.8L Duratorq-TDDi (Lynx)
  • Page 6 Table of contents Changing a road wheel....117 Appendices Tyre care.........123 Type approvals......159 Using winter tyres......124 Type approvals......162 Using snow chains......124 Technical specifications....124 Vehicle identification Vehicle identification plate....127 Vehicle identification number (VIN)..........127 Load apportioning valve (LAV) plate..........127 Technical specific- ations Technical specifications....128 Telephone General information......135 Telephone setup......135...

  • Page 7: Introduction

    SYMBOLS GLOSSARY for your vehicle. We recommend that you ask your Ford Dealer for advice on parts and accessories suitable for Symbols in this handbook your vehicle. WARNING...

  • Page 8: Quick Start

    Quick start QUICK START Instrument panel overview Left-hand drive E74266...
  • Page 9 Quick start Right-hand drive E74267 Lighting controls. See Lighting (page 37). Direction indicators. See Lighting (page 37). Horn. Instrument cluster. See Convenience features (page 73). Information display. See Trip computer (page 55).
  • Page 10 Quick start Wiper lever. See Wipers and washers (page 35). Air vents. See Climate control (page 56). Hazard warning flasher switch. See Lighting (page 37). Audio or navigation unit. See separate handbook. Climate controls. See Climate control (page 56). Heated windscreen and heated rear window switches. See Climate control (page 56).
  • Page 11 Quick start Locking and unlocking the Locking and unlocking the doors with the key doors with the remote control E87379 Unlock Lock Luggage compartment lid unlock Transit Connect E74800 Press button A once to unlock the Unlock front doors only. Lock Press button A twice to unlock all doors and the luggage compartment...
  • Page 12 Quick start Note: The anti-theft alarm system Direction indicators can also be armed independently from the double locking system by turning the door key to the lock position. See Locking and unlocking (page 25). Adjusting the steering wheel WARNING Never adjust the steering wheel when the vehicle is moving.
  • Page 13 Quick start • Turn the ignition to position II. See Climate control (page 56). • Hold the button A pressed for at least three seconds until the time Engine idle speed after in the display flashes. starting • To advance the minutes, press The engine may idle at a higher the button A.

  • Page 14: Child Safety

    Child safety CHILD SEATS WARNINGS If your vehicle has been involved in an accident, have the child restraints checked by properly trained technicians. Note: Mandatory use of child restraints varies from country to country. A choice of ECE approved child restraints which have been specifically tested and approved for your vehicle are available from your...

  • Page 15: Booster Cushions

    Child safety Child safety seat WARNINGS Secure children that weigh more than 15 kilogrammes but are less than 150 centimetres tall in a booster seat or a booster cushion. Booster seat E68920 Secure children that weigh between 13 and 18 kilogrammes in a child safety seat in the rear seat.

  • Page 16: Child Seat Positioning

    Child safety Booster cushion CHILD SEAT POSITIONING WARNING When using a forward facing child seat on a rear seat, always remove the head restraint from that seat. Note: When using a child restraint on a front seat, it may prove difficult to tighten the lap section of the seat belt without slack remaining.

  • Page 17: Child Safety

    Child safety ISOFIX child restraints Seating positions Mass group categories Up to 10 Up to 13 9 - 18 kg 15 - 25 22 - 36 Second row ISOFIX seats Second row ISOFIX C, D, E A, B, B1, classes* C, D X Not suitable for children in this mass group.

  • Page 18: Isofix Anchor Points

    Tourneo Connect bottom of the seat. When made available by your Ford Dealer, the two WARNINGS lower anchor points may be found Ford does not recommend the...
  • Page 19 Child safety E75772 The anchor point is identified by a pictogram. The tether strap should be routed beneath the raised head restraint to the anchor point. Remove the anchor point cover and attach the strap. After installing the child safety seat, tighten the tether strap according to the manufacturer s instructions.

  • Page 20: Child Safety Locks

    Child safety CHILD SAFETY LOCKS Tourneo Connect WARNING You cannot open the doors from inside if you have put the child safety locks on. Note: Child safety locks are only fitted to sliding doors. E75766 Lock Unlock...

  • Page 21: Occupant Protection

    Occupant protection Note: You will hear a loud bang and PRINCIPLE OF see a cloud of harmless powdery OPERATION residue if an airbag deploys. This is normal. Airbags Note: Only wipe airbag covers with WARNINGS a damp cloth. Do not modify the front of your Driver and front passenger vehicle in any way.
  • Page 22 Occupant protection Seat belts Side airbags WARNINGS Wear a seat belt and keep sufficient distance between yourself and the steering wheel. Only when you use the seat belt properly, can it hold you in a position to achieve its optimum effect. See Sitting in the correct position (page 65).

  • Page 23: Fastening The Seat Belts

    Occupant protection Rear seat belts FASTENING THE SEAT BELTS E75564 WARNING In order to ensure that the centre belt works properly, the E66541 rear seatback must be correctly engaged. WARNING Insert the tongue into the buckle Make sure that each seat belt uses until a distinct click is heard, the correct buckle.

  • Page 24: Seat Belt Height Adjustment

    Occupant protection SEAT BELT HEIGHT USING SEAT BELTS ADJUSTMENT DURING PREGNANCY Front seat belt E68587 WARNING Position the seat belt correctly for your safety and that of your unborn child. Do not use only the lap E68901 strap or the shoulder strap. Rear seat belt Position the lap strap comfortably across your hips and low beneath...

  • Page 25: Keys And Remote Controls

    Keys and remote controls 1. Turn the ignition key from position GENERAL INFORMATION 0 to position II eight times within ON RADIO FREQUENCIES 10 seconds. The ignition must end in position II and remain in this CAUTION position. The door locks will cycle to indicate that it is now possible The radio frequency used by to programme new remote...
  • Page 26 Keys and remote controls • Carefully prise out the battery with the flat object. Fit the new battery between the contacts with the + sign facing downwards. Reassemble the transmitter unit in reverse order. E68726 • Carefully seperate the transmitter unit from the key using a flat object (e.g.

  • Page 27: Locks

    Locks LOCKING AND UNLOCKING Central locking Note: You can unlock the doors and luggage compartment lid with the key. This needs to be used if the remote control system is not functioning. E74799 Note: Unlocking the luggage Locking and unlocking compartment lid with a key will only unlock that door.
  • Page 28 Locks Locking and unlocking the Double locking the doors doors with the key with the key Turn the key to the unlock position and then the lock position within three seconds to double lock the doors. Locking and unlocking the doors with the remote control E87379...
  • Page 29 Locks Note: The anti-theft alarm system Sliding door can also be armed independently from the double locking system by turning the door key to the lock position. Locking and unlocking the doors from inside Front doors E74706 Lock Unlock Opening the doors E74704 Sliding door Lock all doors...
  • Page 30 Locks Right-hand rear door E74705 Outside Inside E74707 Outside Double rear doors Inside WARNING Left-hand rear door Close the rear doors properly to prevent them from opening while you are driving. Driving with the rear doors open is extremely dangerous as exhaust fumes can be drawn into the vehicle s interior.
  • Page 31 Locks Opening the doors through 180 and 250 degrees E66517 Outside Inside E74709 Push the yellow button located on the door. The check arms will automatically re-engage when the doors are closed. Luggage compartment lid WARNING Close the luggage compartment lid properly to prevent it opening while you are driving.

  • Page 32: Engine Immobiliser

    If you lose a key, you can obtain a If coding is not completed correctly, replacement from your Ford Dealer. the indicator light flashes after the If possible, provide them with the key ignition is switched on with the newly...

  • Page 33: Arming The Engine Immobiliser

    Engine immobiliser • Insert the second key in the The indicator in the instrument cluster ignition switch and turn to position will come on for approximately three seconds and then go out. If the indicator stays on for one minute or •...

  • Page 34: Alarm

    Alarm PRINCIPLE OF OPERATION The perimeter alarm is a deterrent against unauthorised access to your vehicle through the doors and the bonnet. It also protects the audio unit. Triggering the alarm Once armed, the alarm is triggered in any of the following ways: •...

  • Page 35: Steering Wheel

    Steering wheel Volume ADJUSTING THE STEERING WHEEL E70361 Volume up: Pull the VOL+ switch towards the steering wheel. Volume down: Pull the VOL switch towards the steering wheel. Seek E70358 WARNING Never adjust the steering wheel when the vehicle is moving. Release the locking lever to adjust the height of the steering wheel and its distance from the driver.

  • Page 36: Steering Wheel

    Steering wheel Mode E70363 Briefly press the button on the side: • In radio mode, this will locate the next pre-set radio station. • In CD mode, this will select the next CD if a CD changer is fitted. • In all modes to abort a traffic message during broadcasting.

  • Page 37: Wipers And Washers

    Wipers and washers WINDSCREEN WIPERS WARNING Do not operate the windscreen washer for more than 10 seconds or when the reservoir is empty. REAR WINDOW WIPER AND WASHERS Intermittent wipe E65995 Single wipe Intermittent wiping E65996 Normal wiping Washer High speed wiping WARNING Do not operate the rear window WINDSCREEN WASHERS...

  • Page 38: Checking The Wiper Blades

    Wipers and washers Pull the lever fully towards the steering wheel and hold it to operate the washer. CHECKING THE WIPER BLADES E93784 E66644 Run the tip of your fingers over the edge of the blade to check for roughness. Clean the wiper blade lips with water applied with a soft sponge.

  • Page 39: Lighting

    Lighting LIGHTING CONTROL FRONT FOG LAMPS Lighting control positions WARNING Only use the front fog lamps when visibility is considerably restricted by fog, snow or rain. E65986 Side and tail lamps E65988 Headlamps REAR FOG LAMPS Front fog lamps WARNING Main and dipped beam Only use the rear fog lamps when visibility is restricted to less...

  • Page 40: Headlamp Levelling

    Lighting Vehicles with front fog lamps E93510 E65989 Raise beams Lower beams HEADLAMP LEVELLING Recommended headlamp All vehicles levelling switch positions You can adjust the level of the Note: Higher control positions (+1) headlamp beams according to the may be necessary when towing a vehicle load.
  • Page 41 Lighting Tourneo Connect Load Control position Persons Load in luggage K200/ K220 K230 K210 compartment Front Rear /0.5 max. /1.5 /2.5 max. /2.5 /2.5 See Vehicle identification (page 127). Long wheelbase. Short wheelbase.

  • Page 42: Direction Indicators

    Lighting If you set the switch to position B, the DIRECTION INDICATORS courtesy lamp will come on when you unlock or open a door or the tailgate. If you leave a door open with the ignition switch off, the courtesy lamp will go off automatically after some time to prevent the vehicle battery from discharging.

  • Page 43: Changing A Bulb

    Lighting Headlamp CHANGING A BULB Direction indicator WARNINGS Switch the lights and the ignition off. Let the bulb cool down before removing it. CAUTIONS Do not touch the glass of the bulb. Only fit bulbs of the correct specification. See Bulb specification chart (page 45).
  • Page 44 Lighting 1. Turn the cover anti-clockwise and remove it. E76061 2. Remove the bulb and the bulb holder. 3. Remove the bulb. E76062 Side repeaters 2. Disconnect the electrical connector. 3. Release the clip and remove the bulb. Side lamp E76063 1.
  • Page 45 Lighting Front fog lamps E76066 Tail and brake lamp Direction indicator Reversing lamp E76064 Fog lamp Note: You cannot separate the fog 1. Remove the wing nuts. lamp bulb from the bulb holder. 2. Remove the rear lamp and unclip Note: You can access the lamp from the bulb holder.
  • Page 46 Lighting Central high mounted brake 1. Remove the lens. lamp 2. Remove the bulb. Vehicles with a tailgate E71075 1. Open the lens. 2. Gently press the bulb into the bulb holder, turn it anti-clockwise and remove it. E76067 1. Remove the screws. 2.

  • Page 47: Bulb Specification Chart

    Lighting Interior lamp Rear Front E76070 1. Carefully prise out the lamp. 2. Remove the bulb. Reading lamps E76068 E76069 1. Carefully prise out the lamp. 2. Remove the bulb. BULB SPECIFICATION CHART Lamp Specification Power (watt) Front direction indicator PY21W Headlamp main and dipped 55/60...
  • Page 48 Lighting Lamp Specification Power (watt) Brake and tail lamp P21/5W 21/5 Rear fog lamp P21W Reversing lamp P21W Central high mounted brake lamp W16W Number plate lamp (vehicles with double rear doors) Number plate lamp (vehicles with R10W a tailgate) Interior lamp Festoon Reading lamp...

  • Page 49: Windows And Mirrors

    Windows and mirrors ELECTRIC WINDOWS EXTERIOR MIRRORS WARNING Do not operate the electric windows unless they are free from obstruction. Note: If you operate the switches often during a short period of time, the system might become inoperable for a certain time to prevent damage due to overheating.

  • Page 50: Electric Exterior Mirrors

    Windows and mirrors E71281 E71274 The electric exterior mirrors are fitted Make sure that you fully engage the with a heating element that will mirror in its support when returning defrost or demist the mirror glass. it to its original position. See Climate control (page 56).

  • Page 51: Rear Quarter Windows

    Windows and mirrors REAR QUARTER WINDOWS E66498 Pull the lever outwards to open the window. Press the lever in the middle to engage it in its catch. Pull the lever in the middle to close the window. Push it backwards until it engages in its catch.

  • Page 52: Instruments

    Instruments GAUGES E74268 Engine coolant temperature gauge Tachometer Speedometer Fuel gauge Select and reset button Clock, odometer and tripmeter Digital clock set button CAUTION Engine coolant temperature Do not restart the engine until the gauge cause of overheating has been Shows the temperature of the engine resolved.

  • Page 53: Warning Lamps And Indicators

    Instruments ABS warning lamp If the needle moves towards the red section, the engine is overheating. If it illuminates when driving, Stop the engine, switch the ignition this indicates a malfunction. off and determine the cause once Have the system checked the engine has cooled down.

  • Page 54: Ignition Warning Lamp

    Instruments Ignition warning lamp If the brake system warning lamp comes on with the ABS warning WARNING lamp, this indicates a malfunction. Stop your vehicle as soon as it is safe If the charging system drive belt to do so and have this checked on the diesel engines is loose, before continuing you journey.

  • Page 55: Oil Pressure Warning Lamp

    Instruments Oil pressure warning lamp Soot overload warning lamp CAUTION It will illuminate when a Do not resume your journey if the regeneration is due. See oil pressure warning lamp comes E95449 Diesel particulate filter on despite the oil level being correct. (DPF) (page 80).

  • Page 56: Audible Warnings And Indicators

    Instruments AUDIBLE WARNINGS AND INDICATORS Lights on A warning tone will sound if the driver's door is opened when the lights are on and the ignition is switched off.

  • Page 57: Information Displays

    Information displays TRIP COMPUTER Odometer Registers the total mileage of the vehicle. To switch between odometer and tripmeter, briefly press the select and reset button. Tripmeter Registers the mileage of individual journeys. To reset, press and hold the select and reset button.

  • Page 58: Climate Control

    Climate control Air is directed through the evaporator PRINCIPLE OF where it is cooled. Humidity is OPERATION extracted from the air to help keep the windows free of mist. The Outside air resulting condensation is directed to the outside of the vehicle and it is Keep the air intakes forward of the therefore normal if you see a small windscreen free from obstruction...

  • Page 59: Manual Climate Control

    Climate control Note: The heated windows operate only when the engine is running. Heated windscreen E74670 Heated rear window E74671 E75470 The indicator in the switch will illuminate when the system is on. Press the switch again to switch off. Temperature control It will switch off automatically after a short time.

  • Page 60: Climate Control

    Climate control Rapid heating of vehicle interior E74662 E74660 Ventilation Face level Face level and footwell Footwell Footwell and windscreen Windscreen Recirculated air E74663 Set the air distribution control to position A or B. Set the blower to any position. Open the air vents to suit individual requirements.

  • Page 61: Air Conditioning

    Climate control Cooling with outside air E74664 If necessary, switch the heated windows on. See Heated E74667 windows and mirrors (page 56). Switch the air conditioning on. Air conditioning Cooling the interior quickly Switching the air conditioning on and off Note: For the air conditioning to operate the engine must be running.

  • Page 62: Auxiliary Heater

    Climate control Set the air distribution control to AUXILIARY HEATER position E and select outside air. General information When the temperature is above 4 °C, the air conditioning will switch on WARNINGS automatically. Make sure the blower Do not operate the is on.
  • Page 63 Climate control • Make sure the coolant level is Before activating or programming the between the MAX and MIN heater, prepare the following marks on the reservoir to prevent settings: air locks. See Engine coolant • Set the vehicle heater check (page 109).
  • Page 64 Climate control Setting the heating duration Switching off the heater Press the heating symbol button. The heater will operate for an additional three minutes, and then stop. The display will then show the clock time. Timed heating mode E71348 CAUTION The recommended setting is 30 minutes.
  • Page 65 Climate control Continuous heater operation Programming the pre-set heating start times E71350 E71351 WARNING Press button A repeatedly, until the The heater will continue to symbol (1, 2 or 3) for the desired operate after the ignition is pre-set time is displayed. Press switched off.
  • Page 66 Climate control Activating and deactivating pre-set start times E71352 Press button A repeatedly, until the symbol (1, 2 or 3) for the desired pre-set time is displayed. Press button C. The ON symbol will appear in the display. To deactivate a pre-set time, press button C again.

  • Page 67: Seats

    Seats • keep sufficient distance between SITTING IN THE yourself and the steering wheel. CORRECT POSITION We recommend a minimum of 254 millimetres (10 inches) between your breastbone and the airbag cover. • hold the steering wheel with your arms slightly bent. •...
  • Page 68 Seats Moving the seats Adjusting the height of the backwards and forwards seat E74818 E74816 WARNING Rock the seat backwards and forwards after releasing the lever to make sure that it is fully engaged in its catch. Adjusting the lumbar support E80778 E74817...

  • Page 69: Adjusting The Armrest

    Seats Adjusting the angle of the WARNINGS seatback Do not place objects on the seatback when the vehicle is moving. Transit Connect E74819 Adjusting the armrest E74821 E74820 Folding the front passenger seat WARNINGS Make sure that the seats and the seatbacks are secure and fully engaged in their catches.
  • Page 70 Seats E74823 1. Pull the release strap and fold the seat cushion forwards. 2. Fold the head restraint forwards. 3. Pull the release lever. 4. Fold the seatback forwards. 5. Pull the release lever. E74827 6. Push the seatback down. Tourneo Connect Remove the head restraint.

  • Page 71: Head Restraints

    Seats E81077 1. Pull the release strap and fold the seat cushion forwards. 2. Pull the release lever. 3. Fold the seatback forwards. E81584 4. Pull the release lever. Adjusting the head restraint 5. Push the seatback down. WARNING HEAD RESTRAINTS Raise rear head restraint when the rear seat is occupied by a passenger or a child restraint.

  • Page 72: Folding The Entire Seat Forwards

    Seats Third row WARNINGS Make sure that the seats and the seatbacks are secure and fully engaged in their catches. Make sure the red indicator is not showing when you engage the seat rear legs and the third row seatback catches. Do not place objects on a folded seat.
  • Page 73 Seats E74846 1. Fully lower the head restraints. 2. Pull the levers on the side of the E74833 seatback. 1. Remove the centre head restraint. 3. Fold the seatback forwards. 2. Fully lower the outer head 4. Pull the locking levers up. restraints.

  • Page 74: Heated Seats

    Seats Third row The heated seats will reach their maximum temperature after five or six minutes. They will go off automatically. E74849 1. Push the release levers down. 2. Fold the seat down. 3. Raise the seatback. HEATED SEATS CAUTION Start the engine to use the heated seats.

  • Page 75: Convenience Features

    Convenience features CLOCK Version 1 E83530 Press button A to show the time. CIGAR LIGHTER E74265 Toggle and reset button To set the time • Turn the ignition to position II. • Hold the button A pressed for at least three seconds until the time E74675 in the display flashes.

  • Page 76: Ashtray

    12 volt appliances that have a power 12 volt appliances that have a maximum current rating of 10 maximum current rating of 10 Amperes. Use only Ford accessory Amperes. Use only Ford accessory connectors or connectors specified connectors or connectors specified for use with SAE standard sockets.

  • Page 77: Glove Box

    Convenience features Seat back trays STORAGE COMPARTMENTS WARNING Do not use the trays when the Front storage tray vehicle is moving. Make sure that you secure the trays in the lowered position before setting off. E74680 Overhead storage compartment E72630 GLOVE BOX E74681 WARNING...

  • Page 78: Convenience Features

    Convenience features Sun visor straps Door bins E74682 E74684 A strap on the sun visors is provided Door bins are incorporated into the for storing paperwork. front doors. Instrument panel storage Seat storage E74683 The storage area on the top of the E74685 instrument panel can me used to store paperwork.

  • Page 79: Map Pockets

    Convenience features MAP POCKETS E72630 E74686 AUXILIARY INPUT (AUX IN) SOCKET E80718 SEAT BACK TRAYS E94008 See separate audio instructions. WARNING Do not use the trays when the vehicle is moving. Make sure that you secure the trays in the lowered position before setting off.

  • Page 80: Starting The Engine

    Starting the engine Position I GENERAL INFORMATION Steering unlocked. Ignition and all General points on starting main electrical circuits are disabled. The ignition key should not be left in If the battery has been disconnected this position for too long to avoid the vehicle may exhibit some unusual discharging the battery.

  • Page 81: Starting The Engine

    Starting the engine Vehicles with manual Vehicles with automatic transmission transmission Note: Do not touch the accelerator 1. Select park or neutral. pedal. 2. Fully depress the accelerator pedal and hold it there. 1. Fully depress the clutch pedal. 3. Fully depress the brake pedal. 2.

  • Page 82: Starting A Diesel Engine

    Starting the engine STARTING A DIESEL SWITCHING OFF THE ENGINE ENGINE Cold or hot engine Vehicles with a turbocharger All vehicles CAUTION Note: When the temperature is Do not switch the engine off below -15ºC (5ºF), you may need to when it is running at high speed.
  • Page 83 Starting the engine Regeneration This process may have to be repeated. The warning lamp will go WARNING out when the regeneration process is successful. Do not park or idle your vehicle over dry leaves or dry grass or other combustible material. The regeneration process requires very high exhaust gas temperatures and the exhaust will radiate a...

  • Page 84: Fuel And Refuelling

    Fuel and refuelling SAFETY PRECAUTIONS WARNING Do not mix diesel with oil, petrol WARNINGS or other liquids. This could cause Stop refuelling after the fuel a chemical reaction. nozzle stops the second time. Additional fuel will fill the expansion CAUTION space in the fuel tank which could Do not add kerosene, paraffin or lead to fuel overflowing.

  • Page 85: Fuel Filler Flap

    Fuel and refuelling Parking WARNING Do not park your vehicle over dry leaves or dry grass. The exhaust will continue to radiate a considerable amount of heat after you have switched the engine off. This is a potential fire hazard. FUEL FILLER FLAP E75775 All vehicles...

  • Page 86: Fuel Consumption

    Your Ford dealer can give you advice on improving your fuel consumption. TECHNICAL SPECIFICATIONS Tourneo Connect Fuel consumption figures Extra-...

  • Page 87: Fuel And Refuelling

    Fuel and refuelling Extra- CO2 emis- Urban Combined urban sions Variant l/100 km l/100 km l/100 km g/km (mpg) (mpg) (mpg) 1.8 l Duratorq-TDCi Turbo diesel (90 PS, 7.8 (36.2) 5.6 (50.4) 6.5 (43.5) 1590 Kg), Stage IV, Axle ratio: 4.06 1.8 l Duratorq-TDCi Turbo diesel (90 PS, 7.9 (35.8)

  • Page 88: Transmission

    Transmission MANUAL TRANSMISSION CAUTION Do not engage reverse gear when the vehicle is moving. This can cause damage to the transmission. Note: Fully depress the clutch pedal and wait for three seconds before you select first gear. Selecting reverse gear E72455...

  • Page 89: Brakes

    Brakes Wet brake discs result in reduced PRINCIPLE OF braking efficiency. Dab the brake OPERATION pedal when driving from a car wash to remove the film of water. Dual circuit braking system WARNING The ABS does not relieve you of your responsibility to drive with due care and attention.

  • Page 90: Parking Brake

    Brakes Parking on a hill The ABS will not eliminate the dangers inherent when: If you have to park facing uphill, select • you drive too close to the vehicle first gear and turn the front wheels in front of you. away from the kerb.

  • Page 91: Traction Control

    Traction control PRINCIPLE OF OPERATION The traction control system improves traction when one wheel starts to spin at vehicle speeds up to 40 km/h (25 mph). If a wheel starts to spin, the traction control system varies the pressure to the brake of that wheel until is stops spinning.

  • Page 92: Parking Aid

    If you use a high pressure spray The system is switched off to wash your vehicle, only spray automatically if a Ford approved the sensors briefly from a distance trailer tow module is attached to the not less than 20 centimetres (8 vehicle.

  • Page 93: Load Carrying

    Load carrying GENERAL INFORMATION ROOF RACKS AND LOAD CARRIERS WARNINGS Roof rack Use load securing straps to an approved standard, e.g. DIN. WARNINGS Make sure that you secure all If you use a roof rack, the fuel loose items properly. consumption of your vehicle will Place luggage and other loads be higher and you may experience...

  • Page 94: Cargo Nets

    Load carrying CARGO NETS CAUTIONS Do not exceed the maximum permissible cargo net load of 9.5 kilogrammes. Make sure that the telescopic bars are securely positioned in the trim panels. E81954 The 3 telescopic bars can be moved to allow up to 5 cargo net positions.

  • Page 95: Towing

    Towing Change down a gear before you TOWING A TRAILER reach a steep downhill gradient. WARNINGS Do not exceed the maximum vehicle and trailer weight stated on the vehicle identification plate. See Vehicle identification (page 127). ST vehicles are not approved for trailer towing.

  • Page 96: Driving Hints

    Driving hints RUNNING-IN Tyres WARNING New tyres need to be run-in for approximately 500 kilometres (300 miles). During this time, you may experience different driving characteristics. Brakes and clutch WARNING Avoid heavy use of the brakes and clutch if possible for the first 150 kilometres (100 miles) in town and for the first 1 500 kilometres (1 000 miles) on motorways.

  • Page 97: Emergency Equipment

    Emergency equipment FIRST AID KIT Right-hand drive E75779 Left-hand drive E75780 WARNING TRIANGLE E93405...

  • Page 98: Status After A Collision

    Status after a collision The switch is located above the trim FUEL CUT-OFF SWITCH panel near the base of the front door pillar on the right-hand side of the Vehicles with a petrol vehicle. The button will be raised engine when the switch is activated.

  • Page 99: Fuses

    Fuses FUSE BOX LOCATIONS WARNING Have MAXI fuses (Fuses 1–9 in the auxiliary fuse box) replaced by a properly trained technician. To remove the lid, release the clip and the hinge on the sides and lift the lid off. When replacing the lid, press down on both sides of the hinge (positions 1 and 2) to ensure it is closed properly.

  • Page 100: Changing A Fuse

    Fuses E75784 E75787 Right-hand drive Fuse chart label Fuses CHANGING A FUSE WARNINGS Do not modify the electrical system of your vehicle in any E75786 way. Have repairs to the electrical 1. Press the sides inwards and allow system and the replacement of the glove box to pivot relays and high current fuses carried downwards.

  • Page 101: Fuse Labels

    Fuses Note: You can identify a blown fuse Symbols on the fuse label by a break in the filament. See Owner s handbook Note: All fuses, except high current fuses, are a push fit. Airbag Note: A fuse puller is located in the engine compartment fuse box.
  • Page 102 Fuses Heated seats Central locking Rear auxiliary power socket Cooling fan A/C switch, heated Cigar lighter, front auxiliary power socket windscreen, fuel fired heater Heater blower motor Horn Ignition overload, central Engine management fuse box Glow plug heater I + II, fuel Fuel pump (diesel) fired heater Ignition switch...

  • Page 103: Fuse Specification Chart

    Fuses FUSE SPECIFICATION CHART Engine compartment fuse box Fuse Ampere Circuits protected rating Fuel pump motor (vehicles with a diesel engine) Glow plug heater II (vehicles with a diesel engine) HEGO sensors (vehicles with a petrol engine) Air conditioning clutch solenoid Central fuse box Fuse Ampere...

  • Page 104: Vehicle Recovery

    Vehicle recovery Transit Connect TOWING POINTS Left-hand drive Front towing eye E76186 E76183 Right-hand drive Rear towing eye E76184 E93106 Tourneo Connect Mount for rear towing eye E76185...

  • Page 105: Towing The Vehicle On Four Wheels

    Vehicle recovery Vehicles with automatic The towing eye must always be carried in the vehicle. transmission Insert your finger into the hole on the CAUTIONS underside of the cover and prise off Do not tow your vehicle faster the cover. Install the towing eye. than 50 km/h (30 mph) or further CAUTION than 50 kilometres (30 miles).

  • Page 106: Maintenance

    • Brake fluid level. See Brake and and resale value. There is a large clutch fluid check (page 109). network of Ford Authorised Repairers that are there to help you with their • Washer fluid level. See Washer professional servicing expertise. We fluid check (page 110).

  • Page 107: Opening And Closing The Bonnet

    Opening the bonnet WARNING To prevent damage to, or loss of the key, remove the key immediately after opening and swivel the Ford badge back. Note: On vehicles with the key free system, use the spare key to open the bonnet. E78143...

  • Page 108: Engine Compartment Overview - 1.8L Duratec-Dohc (Zetec)

    Maintenance ENGINE COMPARTMENT OVERVIEW - 1.8L DURATEC- DOHC (ZETEC) E75515 Power steering fluid reservoir : See Power steering fluid check (page 110). Engine oil filler cap : See Engine oil check (page 108). Brake and clutch fluid reservoir : See Brake and clutch fluid check (page 109).

  • Page 109: Engine Compartment Overview - 1.8L Duratorq-Tddi (Lynx) Diesel/1.8L Duratorq-Tdci (Lynx) Diesel

    Maintenance ENGINE COMPARTMENT OVERVIEW - 1.8L DURATORQ-TDDI (LYNX) DIESEL/1.8L DURATORQ- TDCI (LYNX) DIESEL E75516 Power steering fluid reservoir : See Power steering fluid check (page 110). : See Engine oil check (page 108). Engine oil filler cap Brake and clutch fluid reservoir : See Brake and clutch fluid check (page 109).

  • Page 110: Engine Oil Dipstick - 1.8L Duratec-Dohc (Zetec)

    Maintenance ENGINE OIL DIPSTICK - ENGINE OIL CHECK 1.8L DURATEC-DOHC CAUTION (ZETEC) Do not use oil additives or other engine treatments. Under certain conditions, they could damage the engine. Note: The oil consumption of new engines reaches its normal level after approximately 5 000 kilometres (3 E95526 000 miles).

  • Page 111: Engine Coolant Check

    Do not top up further than the MAX mark. the engine to cool down. Unscrew the cap slowly. Any Top up with fluid that meets the Ford specification. See Technical pressure will escape slowly as you unscrew the cap. specifications (page 111).

  • Page 112: Power Steering Fluid Check

    Topping up Do not top up further than the Remove the filler cap. MAX mark. CAUTION Top up with fluid that meets the Ford Do not top up further than the specification. See Technical MAX mark. specifications (page 111). Top up with fluid that meets the Ford specification.

  • Page 113: Technical Specifications

    WSA-M2C-195-A Power Steering Fluid Motorcraft SuperPlus Coolant WSS-M97B44-D Antifreeze Ford or Motorcraft Super Brake fluid ESD-M6C57-A DOT 4 Brake Fluid CAUTION Do not use oils which do not meet the specifications or requirements. Use of unsuitable oil may lead to engine damage which is not covered by the Ford Warranty.
  • Page 114 Maintenance Capacity in litres Variant Item (gallons) Windscreen washer 4.3 (1.0) system Fuel tank 60 (13.2) Cooling system incl. 1.8 l Duratec 6.5 (1.4) heating 1.8 l Duratorq-TDdi/ Cooling system incl. 7.0 (1.5) Duratorq-TDCi heating 1.8 l Duratec Engine oil - with filter 4.25 (0.9) 1.8 l Duratorq-TDdi/ Engine oil - with filter...

  • Page 115: Vehicle Care

    Vehicle care Cleaning the rear window CLEANING THE EXTERIOR CAUTION Do not scrape the inside of the WARNING rear window or use abrasives or If you use a car wash with a chemical solvents to clean it. waxing cycle, make sure that you remove the wax from the Use a clean, lint free cloth or a damp windscreen.

  • Page 116: Cleaning The Interior

    Seat belts A choice of products is available from your Ford Dealer. Read and follow WARNINGS the manufacturer s instructions. Do not use abrasives, or chemical solvents to clean them.

  • Page 117: Vehicle Battery

    Vehicle battery To connect the booster BATTERY CARE cables The battery requires very little maintenance. The fluid level is checked regularly during the routine service inspections. USING BOOSTER CABLES CAUTIONS Connect batteries with only the same nominal voltage. Always use booster cables with insulated clamps and adequate size cable.

  • Page 118: Changing The Vehicle Battery

    Vehicle battery 4. Connect the negative (-) terminal CHANGING THE VEHICLE of vehicle B to the engine block BATTERY or the engine mount of vehicle A (cable 2). Vehicles with a petrol engine CAUTIONS Do not connect to the negative If the battery has been disconnected (–) terminal of the flat battery.

  • Page 119: Wheels And Tyres

    Wheels and tyres Vehicle jack GENERAL INFORMATION WARNINGS CAUTIONS The vehicle jack supplied with Use only approved wheel and your vehicle should only be used tyre sizes. Using other sizes when changing a wheel in could damage the vehicle and will emergency situations.

  • Page 120: Jacking And Lifting Points

    Wheels and tyres Right-hand drive Tourneo Connect E76134 Your jack and wheelbrace are E76182 located in the left-hand sidewall of Your jack and wheelbrace are the load area. located in the bag behind the driver s Jacking and lifting points seat.

  • Page 121: Wheels And Tyres

    Wheels and tyres E93301 Emergency use only Maintenance Small arrow-shaped marks on the sills A show the location of the jacking points. E93302...

  • Page 122: Spare Wheel

    Wheels and tyres Spare wheel E76071 Lower the spare wheel by inserting E76072 the hexagonal end of the wheelbrace Detach the first cable by unscrewing into the guide hole. Turn the and sliding back the cap. Turn the wheelbrace anticlockwise until the nipple at the end of the cable through wheel rests on the ground and there 90 degrees.
  • Page 123 Wheels and tyres WARNINGS Make sure that the vehicle is on firm, level ground with the wheels pointing straight ahead. Switch off the ignition and apply the parking brake. If your vehicle has a manual transmission, select first or reverse gear. If it has an automatic E76137 transmission, select park.

  • Page 124: Installing A Road Wheel

    Wheels and tyres 6. Remove the wheel nuts and the wheel. Installing a road wheel WARNING Use only approved wheel and tyre sizes. Using other sizes could damage the vehicle and will make the National Type Approval invalid. See Technical specifications (page 124).

  • Page 125: Tyre Care

    Wheels and tyres Tyre pressure 7. Install the hub cap or cover using the ball of your hand. Tyre pressures should be checked WARNING when the tyres are cold, before commencing a journey. The pressure Have the wheel nuts checked for your spare tyre should be set to for tightness and the tyre the highest value given for your...

  • Page 126: Using Winter Tyres

    Wheels and tyres USING WINTER TYRES WARNINGS Do not use snow chains on CAUTION snow-free roads. Do not fit snow chains to Make sure that you use the 205/55 R 16 tyres. correct wheel nuts for the type of wheel the winter tyres are fitted to. CAUTION If winter tyres are used, make sure If your vehicle is fitted with wheel...
  • Page 127 Wheels and tyres Short wheelbase Tyre pressures Normal load Full load Front Rear Front Rear Variant Tyre size (lbf/in²) (lbf/in²) (lbf/in²) (lbf/in²) T200 195/65 R 15 2.2 (32) 2.5 (36) 2.3 (33) 3.0 (44) T220 195/65 R 15 2.2 (32) 2.5 (36) 2.4 (35) 3.4 (49)
  • Page 128 Wheels and tyres Normal load Full load Front Rear Front Rear Variant Tyre size (lbf/in²) (lbf/in²) (lbf/in²) (lbf/in²) K200 195/65 R 15 2.2 (32) 2.5 (36) 2.2 (32) 3.0 (44) K210 (500 Kg) 195/65 R 15 2.2 (32) 2.2 (32) 2.2 (32) 2.8 (41) K210 (625 Kg)

  • Page 129: Vehicle Identification

    Vehicle identification VEHICLE IDENTIFICATION VEHICLE IDENTIFICATION PLATE NUMBER (VIN) E93897 The vehicle identification number is E85610 stamped into the floor panel in front of the right-hand seat. It is also Vehicle identification number shown on the left-hand side of the Gross vehicle weight instrument panel.

  • Page 130: Technical Specifications

    Technical specifications TECHNICAL SPECIFICATIONS Vehicle dimensions Short wheelbase E76188...
  • Page 131 Technical specifications Item Dimension description Dimension in mm (inches) Overall length 4278 (168.4) Overall width - incl. exterior mirrors 2044 (80.5) Overall height 1824 (71.8) Wheelbase 2665 (104.9) Track - Front 1505 (59.3) Track - Rear 1552 (61.1)
  • Page 132 Technical specifications Long wheelbase E76189 Item Dimension description Dimension in mm (inches) Overall length 4525 (178.1) Overall width - incl. exterior mirrors 2044 (80.5)
  • Page 133 Technical specifications Item Dimension description Dimension in mm (inches) 1982−2102 Overall height (78.0-82.8) Wheelbase 2912 (114.6) Track - Front 1505 (59.3) Track - Rear 1552 (61.1) Towing equipment dimensions E76190...
  • Page 134 920 (36.2) Centre of towball – centre 1. attachment point 413.3 (16.3) Centre of towball – centre 2. attachment point 566.3 (22.3) All measurements refer to towing equipment officially released by Ford. Vehicle weight Transit Connect Short wheelbase Permiss- Permiss-...
  • Page 135 Technical specifications Long wheelbase Permiss- Permiss- Payload ible Kerb ible roof Engine Payload variant gross weight rack weight load 1.8 l Duratec (115 PS) 2080 1380 1.8 l Duratorq- TDdi 2260 1435 (75 PS) 1.8 l Duratorq- TDCi 2340 1440 (90 PS) Tourneo Connect Short wheelbase...
  • Page 136 Technical specifications Permiss- Permiss- Payload ible Kerb ible roof Engine Payload variant gross weight rack weight load 1.8 l Duratorq- TDCi 2340 1540 (90 PS) Individual markets may have additional payloads available. Please refer to the VIN plate or the vehicle documents for details.

  • Page 137: Telephone

    Telephone Note: The mobile phone does not GENERAL INFORMATION switch off immediately after the ignition key is turned off: the power This section describes the functions down delay is preset to 10 minutes. and features of the Bluetooth mobile The time period can be adjusted to phone and voice control system.

  • Page 138: Making A Phone An Active Phone

    Telephone 2. Push the phone downwards until Phone a click is heard. Mobile Home Office E87688 Note: The connection to the system will be displayed on your phone. Making a phone an active phone Phonebook When using the system for the first After start up access to the time, no phone is connected to the phonebook can be delayed for up to...

  • Page 139: Bluetooth Setup

    2. The private mode must not be with your vehicle it must be bonded activated on the Bluetooth phone. to the vehicle telephone system. 3. Search for audio device. 4. Select Ford Audio. 5. The Bluetooth PIN number 0000 must be entered on the phone keypad.

  • Page 140: Telephone Controls

    Bluetooth. Mode button This is referred to as a SIS file and will be available via the Ford website. Incoming calls can be accepted by Please consult your dealer for full pressing the MODE button once or details.

  • Page 141: Using The Telephone - Vehicles Without: Navigation System

    Telephone Voice and accept/reject button Mode button only E87664 On vehicles without a VOICE button, E87662 the MODE button on the remote Voice button control is used to activate or switch off the voice control. Accept/Reject button Note: You will not be able to use the The VOICE button is used to activate MODE button to activate the voice or switch off the Voice control.
  • Page 142 Telephone Making a call Press and hold 0 to enter a + digit. Dialling a number Ending a call Calls can be ended by either: You can access your phone address book either with the phone docked • pressing one of the following in the cradle or via Bluetooth.
  • Page 143 Telephone 2. Press the call accept button again Accepting a second incoming to display the last dialled number. call 3. Press the call accept button a Second incoming calls can be third time to dial the number. accepted by either: •...

  • Page 144: Using The Telephone - Travel Pilot Ex

    Telephone Using the audio unit menu USING THE TELEPHONE - TRAVEL PILOT EX 1. Press the PHONE or call accept button. This chapter describes the phone 2. Press the MENU button on the functions of the Navigation System audio unit. TravelPilot EX.

  • Page 145: Voice Control

    Telephone Handling an incoming call Dialling a number - Bluetooth phone Accepting an incoming call Using the Bluetooth phone, phone Incoming calls can be accepted by numbers can be dialled using voice either: control, refer to the Voice control chapter. •...
  • Page 146 Telephone Accepting a second incoming 1. Press the PHONE button on the call audio unit. 2. Select the DEBOND option in the Second incoming calls can be menu. accepted by either: 3. Select the phone from the list by • Pressing the accept button.

  • Page 147: Voice Control

    Voice control Note: The voice control system is PRINCIPLE OF language specific. If you require the OPERATION system to operate in another language please consult your dealer. Voice recognition enables operation of the audio system without the need System response to divert your attention from the road As you work through a voice session ahead in order to change settings, or...

  • Page 148: Using Voice Control

    Voice control • Store up to 20 name tags per 1) Only when the mobile phone is function. fitted with Bluetooth and voice control • The average recording time for each name tag is approximately Start communicating with the 2-3 seconds. system Before you can start talking to the USING VOICE CONTROL...
  • Page 149 Voice control Overview The overview below shows the available voice commands for operating your CD player. The following lists will give further information about the complete command menu. "CD" "HELP" "DISC" "TRACK" a) Can only be used with a CD changer. b) Can be used as a shortcut.
  • Page 150 Voice control Steps User says System answer "TRACK NUMBER PLEASE" "TRACK" "<a number between 1 and "TRACK <number>" 99>" a) Can be used as a shortcut. Overview Radio The overview below shows the The radio voice commands support available voice commands for the functionality of the radio and allow operating your radio.
  • Page 151 Voice control Steps User says System answer "RADIO" "RADIO" "AM" "FREQUENCY PLEASE" "FM" "FREQUENCY PLEASE" "<frequency>" "TUNE <frequency>" Store name If you have tuned a radio station, you can store it with a name in the directory. Steps User says System answer "RADIO"...
  • Page 152 Voice control Delete name This function allows you to delete a stored radio station. Steps User says System answer "RADIO" "RADIO" "DELETE NAME" "NAME PLEASE" "<name>" "DELETE <name>" "CONFIRM YES OR NO" "YES" "DELETED" "NO" "COMMAND CANCELLED" Play directory This function allows you to let the system tell you all of the stored radio stations.

  • Page 153: Telephone Commands

    Voice control Overview TELEPHONE COMMANDS The overview below shows the Phone available voice commands of the phone system. The following lists will Your phone system allows you to give further information about the create an additional phonebook. The complete command menu. stored entries can be dialled by voice control.

  • Page 154: Create A Phonebook

    Voice control Create a phonebook New entries can be stored with the "STORE NAME" command. This Store name feature can be used to dial a number by calling up the name instead of the full phone number. Steps User says System answer "PHONE"...

  • Page 155: Phone Functions

    Voice control Play directory Use this function to let the system tell you all stored entries. Steps User says System answer "PHONE" "PHONE" "PLAY DIRECTORY" "PLAY DIRECTORY" Delete directory This function allows you to delete all entries in one go. Steps User says System answer...
  • Page 156 Voice control b) Only when the mobile phone is fitted with Bluetooth and voice control (dependant on the mobile phone). Dial number Phone numbers can be dialled after giving the name tag voice command. Steps User says System answer "PHONE" "PHONE"...

  • Page 157: Main Settings

    Voice control Redial This function allows you to redial the last dialled phone number. Steps User says System answer "PHONE" "PHONE" "REDIAL" "REDIAL" "CONFIRM YES OR NO" "YES" "DIALLING" "NO" "COMMAND CANCELLED" a) Can be used as a shortcut. Note: DTMF can only be used during DTMF (Tone dialling) an ongoing call.

  • Page 158: Navigation System Commands

    Voice control Steps User says System answer "REJECT CALLS" "REJECT CALLS" Overview NAVIGATION SYSTEM The overview below shows the COMMANDS available voice commands for operating your climate control Please refer to your separate system. The following lists will give Navigation handbook for details of further information about the the command menus.
  • Page 159 Voice control This function allows you to adjust the fan speed. Steps User says System answer "CLIMATE" "CLIMATE" "FAN SPEED PLEASE" "‘FAN" "MINIMUM" "FAN MINIMUM" "<a number between 1 and 7>" "FAN <number>" "MAXIMUM" "FAN MAXIMUM" a) Can be used as a shortcut. On vehicles fitted with an English language module the "FAN"...
  • Page 160 Voice control Steps User says System answer "MINIMUM" "TEMPERATURE MINIMUM" "<a number between 15 and 29 °C with 0.5 increments>" or "TEMPERATURE <number>" "<a number between 59 and 84 °F>" "MAXIMUM" "TEMPERATURE MAXIMUM" a) Can be used as a shortcut. Auto mode Steps User says...

  • Page 161: Type Approvals

    Appendices If the type approval of your remote TYPE APPROVALS control is inspected, refer to the following table. Remote control Note: We recommend that you use the remote control only in the countries listed. E72068...
  • Page 162 Appendices Engine immobiliser If the type approval of your engine immobiliser is inspected, refer to the following table.
  • Page 163 Appendices E74865...

  • Page 164: Type Approvals

    /declaration_of_conformity The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Ford Motor Company is under license. Other trademarks and trade names are those of their respective owners. Nokia Corporation Keilalahdentie 4,...
  • Page 165 Index Bluetooth setup......137 Compatibility of phones....138 Handling of phones......137 Requirements for Bluetooth See: Climate control......56 connection........137 About this handbook......5 Bonnet lock See: Opening and closing the See: Brakes...........87 bonnet..........105 ABS driving hints Booster cables See: Hints on driving with ABS...87 See: Using booster cables....115 Accessories Booster cushions......13...
  • Page 166 Index Changing a road wheel....117 Coolant check Installing a road wheel.......122 See: Engine coolant check....109 Cup holders........74 Jacking and lifting points....118 Locking wheel nuts......117 Seat back trays........75 Removing a road wheel....120 Spare wheel........120 Stowing the wheel......123 Diesel particulate filter (DPF)..80 Vehicle jack...........117 Changing the remote control Regeneration........81...
  • Page 167 Index First aid kit.........95 Gearbox Left-hand drive........95 See: Transmission.......86 General information on radio Right-hand drive........95 Front fog lamps.......37 frequencies........23 Front seats........65 Glove box.........75 Adjusting the angle of the seatback..........67 Adjusting the armrest......67 Handbrake Adjusting the height of the seat..66 Adjusting the lumbar support....66 See: Parking brake......88 Headlamp levelling......38 Folding the front passenger seat..67...
  • Page 168 Index Manual climate control....57 Air conditioning........59 Air distribution control......57 Jump starting Blower............57 See: Using booster cables....115 Defrosting and demisting the windscreen........58 Rapid heating of vehicle interior..58 Recirculated air........58 Keys and remote controls.....23 Temperature control......57 Ventilation..........58 Manual transmission.......86 Selecting reverse gear.......86 Lighting control........37 Map pockets........77 Main and dipped beam.......37...
  • Page 169 Index Parking brake........88 Running-in........94 Applying the parking brake....88 Brakes and clutch........94 Parking on a hill........88 Engine............94 Releasing the parking brake....88 Tyres............94 Parts and accessories......5 Power steering fluid check...110 Topping up...........110 Programming the remote Safety precautions......82 control..........23 Seat back trays........77 Seat belt height adjustment..22 Front seat belt........22 Rear seat belt........22 Quick start..........6...
  • Page 170 Index Transmission........86 Trip computer........55 Odometer..........55 Technical specifications....128 Tripmeter..........55 Technical specifications....128 Type approvals......159, 162 Telephone commands....151 Bluetooth/voice recognition system Create a phonebook......152 - declaration of conformity...162 Main settings........155 Tyre care.........123 Phone...........151 Tyre pressure........123 Phone functions.........153 Tyres Telephone controls.......138 See: Wheels and tyres.......117 Ending or rejecting calls....138 Remote control........138 Telephone setup......135...
  • Page 171 Index See: Climate control......56 Vents See: Air vents........56 See: Vehicle identification number (VIN)..........127 Voice control........145 Principle of operation......145 Warning lamps and indicators..51 ABS warning lamp........51 Airbag warning lamp......51 Brake system warning lamp....51 Direction indicator........52 Engine warning lamp......52 Ignition warning lamp......52 Low fuel level warning lamp....52 Main beam indicator......52 Multi-function warning lamp....52...
  • Page 174 Feel the difference...

This manual is also suitable for:

TransitconnectTourneo connectTransit connect

Table of Contents
