PCI-DAS-TC User's Guide
Table 3. Thermocouple measurements (not including CJC errors)
TC Range
Type
J 0 to 750 °C
K
200 to 1250 °C
E
200 to 900 °C
T
200 to 350 °C
R 0 to 1450 °C
S 0 to 1450 °C
B 0 to 1700 °C

Miscellaneous

Averaging
Calibration
Processor reset
Watchdog timer
Temperature units
Interrupts
Interrupt enable
Interrupt sources

Crystal oscillator

Frequency
Frequency accuracy

CIO-STA-TC adapter

CJC type
Configuration
Channels

Calibration error

@ 25 °C
25 °C to +105 °C
Accuracy (Worst Case)
±0.5 °C
±1.4 °C
±1.1 °C
±0.9 °C
±2.3 °C
±2.3 °C
±3.0 °C
Table 4. Miscellaneous specifications
Moving average, 1 to 16 samples, software-selectable
Calibration is performed with each channel scan to remove offset and gain error. CJC
channel is also measured with each calibration.
On power-up, watchdog timeout, or software command. Processor boots within one
second of reset. Active low.
1.6 seconds nominal. Processor generates watchdog disable signal after boot-up.
Programmable for conversion to C or F
INTA# mapped to IRQn by PCIBIOS at boot time
Programmable
Dual port RAM when the processor mailbox has data.
Table 5. Crystal oscillator specifications
32 MHz
100 ppm
Table 6. CIO-STA-TC adapter specifications
AD592CN
CJC centered in an isothermal block on which the screw terminals have been mounted.
16 (plus CJC output)
Table 7. Calibration error specifications
0.3 °C typical, 0.5 °C maximum
0.5 °C typical, 1.0 °C maximum
16
Resolution
@ 50 Hz @ 60 Hz
0.05 °C 0.05 °C
0.04 °C 0.05 °C
0.03 °C 0.04 °C
0.03 °C 0.04 °C
0.06 °C 0.07 °C
0.06 °C 0.08 °C
0.07 °C 0.08 °C
Specifications
@ 400 Hz
0.40 °C
0.40°C
0.25 °C
0.25 °C
0.44 °C
0.52 °C
0.54 °C
